Operating Instructions & Parts Manual
Model
23221, 23222
23227
23301
23501
23991
U.S. Patent No's.
5,341,723 • 5,946,912
!
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
AdveRTenCIA
!
• Leer, comprender, y seguir las instrucciónes antes
de utilizar el aparato.
• El manual de instrucciónes y la información de
seguridad deben estar comunicado en lengua del
operador antes del uso.
• No seguir estas indicaciónes puede causar daños
personales o materiales.
Read this manual and follow all the Safety Rules and Operating Instructions before using this product.
Hydraulic Truck Jack
Models 23221 & 23222
Capacity
22 Ton
22/35 Ton
30 Ton
50 Ton
100 Ton
Models 23227, 23301, 23501 & 23991
WARNING
!
To avoid crushing and related injuries:
neveR work on, under or around a
load supported only by a hydraulic
jack. ALWAYS use adequately rated
jack stands.
SFA Companies
http://www.omegalift.com
Printed in Taiwan
23221-M2 rev 06/08
Advertisement
Table of Contents
Related Manuals for Omega 23221
Summary of Contents for Omega 23221
- Page 1 U.S. Patent No's. 5,341,723 • 5,946,912 Models 23221 & 23222 This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
-
Page 2: Safety And General Information
SAFeTY and GeneRAL InFORMATIOn Save these instructions. For your safety, read, understand, and follow the information provided with and on this jack before using. The owner and operator of this equipment shall have an understanding of this jack and safe operating procedures before attempting to use. -
Page 3: Specifications
50 Ton 22-7/8" x 13-3/4" 23991 100 Ton 26" x 15-3/4" Handle Handle Position Release Adapter Holder (for 23221 & 23222 only) Handle Sleeve Wheel Figure 1 - Typical Truck Jack Nomenclature (23222 shown) Min. Max. Hyd. Height Height Range 9-7/8"... -
Page 4: Operation
WARNING • Study, understand, and follow all printed materials provided with/on this product before use. • do not exceed rated capacity. • This is a lifting device only! • Immediately after lifting, support the load with a pair of appropriately rated jack stands. •... -
Page 5: Maintenance
MAInTenAnCe Important: Use only good grade hydraulic jack oil. Avoid mixing different types of fluid and NEVER use brake fluid, turbine oil, transmission fluid, motor oil or glycerin. Improper fluid can cause premature failure of the jack and the potential for sudden and immediate loss of load. We recommend Mobil DTE 13M or equivalent. Adding/ Changing Oil For best performance and longest life, replace the complete fluid supply at least once per year. - Page 6 Air Hose A20060-0007 Lift Control Valve A20060-0016 Air Coupler, Male, 1/4 NPT A07-3-3300-307 Release Valve Cable Figure 2 - Replacement Parts Illustration for Model 23221 & 23222 Item Part No. 13, (33) 11 12 Description A09-6-1701-105 Release Valve 554-7-0062-007 Oil Seal...
- Page 7 Replacement Parts for model 23227: Item Part No. Description A07-4-2100-108 Handle Assy. A22-3-1100-209 Extension Screw A22-6-1218-109 Collar A22-6-1213-109 Retaining Ring A22-6-1211-105 Retaining Ring A22-6-1219-101 Collor A22-6-1217-208 Fixing Ring A22-3-1220-209 Piston Rod Assy. A22-6-1802-108 Cover 522-2-0260-030 Extension Spring 324-4-1900-208 Filler Screw A22-6-1808-100 Retaining Ring A20-4-1500-106...
- Page 8 Replacement Parts for model 23301: Item Part No. Description A07-4-2100-108 Handle Assembly 506-9-0264-106 Handle Grip 421-6-2202-209 Knob 601-4-0040-034 Spring Pin 653-1-0100-014 Bolt 605-3-0100-203 Washer, Lock A07-6-1301-105 Handle Sleeve A30-6-3220-100 Cover Plate 609-1-0050-109 Screw A07-4-3400-509 Wheel 611-3-0130-101 Washer 667-5-0127-005 C-clip A27010-0001 Air Motor A270-01004-0420 Washer A270-01014-0000 Gasket...
- Page 9 Replacement Parts for model 23501: Item Part No. Description A07-4-2100-108 Handle Assembly 506-9-0264-106 Handle Grip 421-6-2202-209 Knob 601-4-0040-034 Spring Pin 653-1-0100-014 Bolt 605-3-0100-203 Washer, Lock A07-6-1301-105 Handle Sleeve A30-6-3220-106 Cover Plate 609-1-0050-109 Screw A22-4-3400-106 Wheel 511-3-0202-046 Washer 667-5-0180-009 C-clip A27010-0001 Air Motor A270-01004-0420 Washer A270-01014-0000 Gasket...
- Page 10 Replacement Parts for model 23991: Item Part No. Description A07-4-2100-108 Handle Assembly 506-9-0264-106 Handle Grip 421-6-2202-209 Knob 601-4-0040-034 Spring Pin 653-1-0100-014 Bolt 605-3-0100-203 Washer, Lock A07-6-1301-105 Handle Sleeve A99-6-3220-101 Cover Plate 609-1-0050-109 Screw A99-4-3400-202 Wheel 511-3-0202-046 Washer 667-5-0180-009 C-clip A27010-0001 Air Motor A270-01004-0420 Washer A270-01014-0000 Gasket...
-
Page 11: One-Year Limited Warranty
For a period of one (1) year from date of purchase, SFA Companies will repair or replace, at its option, without charge, any of its products which fails due to a defect in material or workmanship under normal usage. This limited warranty is a consumer's exclusive remedy. - Page 12 note Page Contact: SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153, U.S.A. Tel:(888)332-6419 Fax:(816)891-6599 E-Mail:sales@omegalift.com Omega Website: http://www.omegalift.com...
