Page 1 of 17
Hodge Clemco Ltd
Auto MZ Filter Units
Owners Manual
TSOM 535
Date of Issue: 13.07.04
Hodge Clemco Ltd
Orgreave Drive, Sheffield
South Yorkshire. S13 9NR
Tel:0114 254 0600
Fax: 0114 2540250
Email:sales@hodgeclemco.co.uk
www.hodgeclemco.co.uk
TS OM535 Date of Issue 13.07.04
Hodge Clemco Ltd
Advertisement
Related Manuals for Clemco Enviraclean Systems M Z Series
Summary of Contents for Clemco Enviraclean Systems M Z Series
- Page 1 Page 1 of 17 Hodge Clemco Ltd Auto MZ Filter Units Owners Manual TSOM 535 Date of Issue: 13.07.04 Hodge Clemco Ltd Orgreave Drive, Sheffield South Yorkshire. S13 9NR Tel:0114 254 0600 Fax: 0114 2540250 Email:sales@hodgeclemco.co.uk www.hodgeclemco.co.uk TS OM535 Date of Issue 13.07.04...
- Page 2 6. Electrical controller (separate item) 7. Fan 8. Dirty air inlet 9. Cleaned air outlet from silencer 10. Top discharge air silencer * 11. Quick release dust collection bin *Note other silencer configurations available TS OM535 Date of Issue 13.07.04 Hodge Clemco Ltd...
- Page 3 If the unit is supplied in one piece, then transport upright and lift as shown below. Note that the silencer is supplied loose and two eye- bolts are fitted to the unit before despatch Two or four may be used for lifting. TS OM535 Date of Issue 13.07.04 Hodge Clemco Ltd...
- Page 4 Normally Auto M units are supplied with a combined fan and shaker controller. Important: this controller must not be mounted directly onto the filter unit because of vibration during the cleaning cycle. Typically it would be mounted on an adjacent wall. TS OM535 Date of Issue: 13.07.04 Hodge Clemco Ltd...
- Page 5 If in doubt, please refer to the Technical Office for assistance. Maintenance Safety note: All maintenance operations should be performed only by suitably qualified and experienced personnel. Isolate electrical supply before commencing. Use only original spare parts for repairs. TS OM535 Date of Issue: 13.07.04 Hodge Clemco Ltd...
- Page 6 Worn or damaged parts should be replaced as soon as possible, to minimise the risk of injury or greater damage. TS OM535 Date of Issue: 13.07.04 Hodge Clemco Ltd...
- Page 7 Press ”clean” button on controller and check time delay before clean starts, then duration of clean cycle. These times should be approx. 2 minutes delay followed by 8 seconds clean. Check than unit will re-start after this cleaning cycle, by pressing ”start” button. TS OM535 Date of Issue: 13.07.04 Hodge Clemco Ltd...
- Page 8 Fit the bag mounting frame over bag, pulling a vee-pocket through each slot. Stretch out the bottom skirt so that it does not fold under the bag. Replace the self adhesive sealing strip around the filter mounting area. TS OM535 Date of Issue: 13.07.04 Hodge Clemco Ltd...
- Page 9 Proceed generally as above but note that the shaker motor is located on a bracket on top of the unit case. To gain access, remove the plate on the front of the bracket. TS OM535 Date of Issue: 13.07.04 Hodge Clemco Ltd...
- Page 10 The waste container is Use a plastic bag or disconnect intended for use with a and seal the connection for the plastic liner but no plastic bin balancing pipe liner is used TS OM535 Date of Issue: 13.07.04 Hodge Clemco Ltd...
- Page 11 The filter materials are normally composed of : Polyester needlefelt, perhaps with antistatic, ptfe or other chemical treatment. Other: Please request data sheet for filter material. Other technical information. Operating pressure. Auto M Z-Series: - TS OM535 Date of Issue: 13.07.04 Hodge Clemco Ltd...
- Page 12 Auto M Z-Series components: - Access door Sealing for side access door Lock for access door, (not shown) Hinge for access door, (not shown) Filter bag Bag sealing gasket TS OM535 Date of Issue: 13.07.04 Hodge Clemco Ltd...
- Page 13 7.5, 15, 25 etc = filter area in sq.m. Final number eg. /2.2 = fan motor power in kW. Examples: - For explosible dust: - Auto M Z 25/2.2 (25 sq.m, 2.2kW fan, explosion panel)). TS OM535 Date of Issue: 13.07.04 Hodge Clemco Ltd...
- Page 14 Page 14 of 17 TS OM535 Date of Issue: 13.07.04 Hodge Clemco Ltd...
- Page 15 Pred. Whilst some research work and papers (G. Lunn and others) have been produced in the past, there is no unified guidance available on this subject and therefore a very conservative approach should be taken. TS OM535 Date of Issue: 13.07.04 Hodge Clemco Ltd...
- Page 16 It is always recommended to place filter units outdoors when they are fitted with explosion relief ventilation panels. If indoors, then only a short straight duct should be fitted, to ventilate to an external safe area. TS OM535 Date of Issue: 13.07.04 Hodge Clemco Ltd...
- Page 17 Page 17 of 17 TS OM535 Date of Issue: 13.07.04 Hodge Clemco Ltd...
