Summary of Contents for UGO BASILE 47400-030
- Page 1 USB Camera Cat. No. 47400-030 Cat. No. 47400-040 UGO BASILE S.R.L. sales@ugobasile.com / service@ugobasile.com www. .com ugobasile...
- Page 2 (* the lens adaptor is provided as standard with the videocamera, for possible other applications) You will find in the 47400-030 kit, beside the camera, the following components (see pic- ture): TBL2.1: 2.1mm Optics (for Rat cage) TBL4.0: 4.0mm Optics (for Mouse cage)
- Page 3 Assemble the M12 adaptor on the camera body. Let’s consider the two optics included with the 47400-030 camera; they are both provided with a visible light block filter (6) already fitted in the correct position. If necessary, the filter separates easily from the optics.
- Page 4 Page 3 assembling instructions (Rev. 2) Insert and tighten the correct optics (2.1 for rat cage, or 4.0 for mouse cage) inside the support. Here’s how the assembled camera looks like. Replace the optics if you plan to change from mouse to rat cage or viceversa.
- Page 5 Page 4 assembling instructions (Rev. 2) Attach the bracket to the camera, by the two screws provided (the arrows indicate where the screws must be positioned) Once the camera is attached to the cubicle ceiling, act on the optics, by turning it, until the correct focus is reached.
- Page 6 Page 5 assembling instructions (Rev. 2) Remove both, as you will not need them for standard opera- tion. (* the lens adaptor is provided as standard with the videocamera, for possible other applications) The 47400-040 kit, beside the camera, in- cludes the Day&Night 2.8-12mm Varifocal Lens, model YV4.3x2.8SA-2.
- Page 7 Page 6 assembling instructions (Rev. 2) Here’s how the assembled camera looks like. Once the videocamera has been in- stalled, the commands on the lens body will enable you to obtain the best view (WIDE< >TELE) and reach the correct focus (NEAR < > FAR).
-
Page 8: Customer Support
(or our local distribu- tor) either directly of via our support page http://www.ugobasile.com/support.html UGO BASILE s.r.l. Via G. Di Vittorio 2 21036 GEMONIO – Varese, ITALY Phone : +39 0332 744574 service@ugobasile.com... - Page 9 UGO BASILE Cat. 47400-030 DMK 22AUC03 Monochrome Camera 47400-040 The Imaging Source "22" Series USB 2.0 Camera Only 36 25 mm Lens not included The Imaging Source DMK 22AUC03 monochrome camera has a USB 2.0 interface and is the perfect solution for many industrial automation, quality assurance, security, surveillance and medical applications.
- Page 10 DMK 22AUC03 Specification GENERAL BEHAVIOR Example Configurations Resolution Format Sensitivity 480 (0.4 MP) " 4.8 V/lux-sec 480 (0.3 MP) 1 3.5 " 4.8 V/lux-sec 240 (0.1 MP) " 4.8 V/lux-sec Set resolution, format, FPS and sensitivity with shipped software. Color format Y800 Dynamic range 8 bit...
- Page 11 Micron MT9V024 Spectral Response Curve CMOS Sensor in DMK 22AUC03 Wavelength [nm]...
- Page 12 DMK 22AUC03 Dimensional Diagram 16,25 6,75 M6x1, depth 8 1/4-20 UNC, depth 8 Dimensions: mm Tolerances: DIN ISO 2768m...
- Page 13 CAMERA 47400‐040 ALSO MOUNTS THE YV4.3x2.8SA-2 OPTICS...
-
Page 14: Ce Conformity Statement
Fax n. +39 0332 745488 We hereby declare that Instrument. Videocamera Catalog number 47400-030, 47400-035, 47400-040 is manufactured in compliance with the following European Union Directives and relevant harmonized standards 2014/30/UE relating to electromagnetic compatibility Account Manager Mauro Uboldi...
