Summary of Contents for Studio Evolution EVOBOX
- Page 1 Quick Start Guide...
-
Page 2: Let's Start
1. Connect one end of the HDMI cable to the HDMI port on your TV. Connect the other end of the HDMI cable to the EVOBOX HDMI port 2. Use the RCA cable to connect EVOBOX to the audio system 3. Use TRS cables to connect wired microphones or a wireless microphone receiver to the appropriate Mic1 and Mic2 inputs 4. -
Page 3: Remote Control
Karaoke system activation Please activate your EVOBOX system so it could operate at its full potential. Without activation, EVOBOX will run in demo mode only. In the demo mode, the song duration is limited to 45 seconds. To activate your karaoke system, use the instructions on the screen of your TV. -
Page 4: Smart Control
LiveFX is available for tracks marked with the special icon Use the green function key to enable/disable the effect. Smart control You can control the EVOBOX karaoke system using its Bluetooth remote control with a full-size keyboard, as well as rely on our official applications. -
Page 5: Microphone Settings
Record your concerts Record your performances with EVOBOX in studio quality. To enable it, press the Record key on the remote control or tap a similar button in the application interface. You can easily copy the recordings to a USB drive or instantly share them with your friends and family members via instant messengers or social networks, with the application. -
Page 6: What's Inside
How to buy songs At any moment, you can purchase individual tracks from the Studio Evolution full karaoke catalogue. Studio Evolution Catalogue is updated several times a week with just-outs and trendy songs. In the Catalogue, the songs available for purchase are marked grey. -
Page 7: Specifications
The maximum screen resolution: 4K UHD (3840 × 2160) Visit support.studio-evolution.com to learn more about the way you can use the EVOBOX karaoke system. Please note that the appearance and interface of the equipment may differ from those described in this manual. - Page 8 WIRELESS DIGITAL MICROPHONES Microphone 2 Microphone 1 Microphone number Channel operational Channel frequency Power level Display Button Switch Battery case Battery Protection USB Type-C charging port U se only external USB power adapter* (5V⎓1А or 5V⎓2А) to charge the microphones. USB power adapter not included.
-
Page 9: Starting Operation
Starting operation Before starting, make sure the karaoke system is unplugged. Connect the supplied antenna to the UHF ANTENNA socket at the back panel of the karaoke system*. Connect the karaoke system to the mains. Unscrew the protective cap on the microphone and place the battery with the pole "+" downward. Screw the cap back and switch the microphone on by pressing the "Button Switch"... -
Page 10: Microphone Connection
Switch" changes the current channel number. Once the channel is selected, the microphone will exit this mode automatically after 5 seconds. IMPORTANT NOTICE! To ensure the connection to the karaoke system, change the channels when EVOBOX is on, and the microphone is connected to the karaoke system. -
Page 11: Technical Characteristics
Microphone does not work while charging. The microphone is switched on but produces no sound Make sure EVOBOX is properly connected to the acoustic system. Set up the general sound volume of the karaoke system and the microphone sound volume at the level of 75%. - Page 12 , 2022...
