- Page 1 Wireless Gateway Wireless Gate (LAN) FOR WL-ZGWMDPB-G100-02 User Manual Nanjing IOT Sensor Technology Co., Ltd. Publication No. ：2015-0408.V01...
- Page 2 Nanjing IOT Sensor Technology Co., Ltd. (hereinafter referred to as “Wulian”). This product shall be synchronized with relevant APP terminal of smart home. And the supplied accessories shall be used together. Wulian is not responsible for any loss due to improper installation and usage of this product.
- Page 3 Features ●Supports IEEE 802.15.4 protocol. ●The standard Ethernet interface makes it possible to connect the smart home network with LAN or internet, and to transfer wireless communication data safely and reliably. ●Any power adapter meeting IEC standard could match this product, which makes it available in over 150 countries and regions around the world.
-
Page 4: Specifications
Specifications IEEE 802.15.4 ZigBee/SmartRoom 500m (visible) Communication Protocol Communication Distance AC/DC Adapter，DC5V/1A Network Access 以太网 Power Supply PCB Antenna ≤3W Antenna Type Standby Power Consumption RT5350 127×111×56 Processor Parameter Dimensions（Length×Width×Height） Flash 128Mbit PC+ABS，Black ROM Type &Capacity Materials & Color SDRAM 256Mbit UL94 V-2 Memory Type &Capacity Flame Resistance Level... -
Page 5: Packing List
Packing List Specifications Warranty Card Warranty Card*1 WL Wireless Gateway Specifications*1 AC/DC Adapter*1 Wireless Gate (LAN)*1 （take the Chinese standard as example）... -
Page 6: Installation Diagram
Installation Diagram Set Key ZigBee Network Indicator System Key ZigBee Network Setting Light Ethernet Interface Ethernet Indicator TF Card Slot System Indicator micro USB Interface Power Indicator DC—5V Power Interface... - Page 7 Networking Step One: Connected to the Server Power Indicator stays on, Ethernet Indicator flashes meaning power supply is every meaning The gateway is started (takes Connect network normal Ethernet is normal Power on about 1-2min) cable and set Ethernet Step Two: Build the ZigBee network for the first time Click SET Key 6 times quickly and ZigBee network is built successfully ZigBee network is working and flash every 1s...
- Page 8 Step Three:Add to the network Other devices are allowed to be added in ZigBee Network Indicator stays on Click SET Key 4 times quickly ZigBee network. Default time for allowing new and each click is less than 1s devices to add in ZigBee network is 4 minutes, and the ZigBee Network Setting Light will go out after that.
- Page 9 Step Four：Exit network The system restarts automatically and restores to factory Press on SYS Key for 10s settings while ZigBee network will not be affected. The gateway exits ZigBee network automatically Press on SET Key for 10s...
- Page 10 Smart Home System Configuration a.Wireless IR Motion Detector b.Temperature and humidity monitor c.Multi-functional Detector d.Fingerprint&Password Lock e.Scene Switch f.Wall Socket g.Wireless Dimmer Switch h.Wireless IR Motion Detector i.Parking Sensor j.Wireless Body Weight Meter k.Wireless Water Logging Sensor m.Rainbow Light l.HD Video Camera n.Wireless Gateway o p.Wireless Emergency Button...
- Page 11 Cautions 1.For initial use, open APP Client to enter the gateway. Inputting ID or scanning QR Code at the bottom of this product to obtain username. The initial password is the last six characters of product ID. (Please modify the password immediately.) 2.Make sure this product is placed away from the washing machine, microwave oven, refrigerator, Router and other sources of interference, in case of poor communication sensitivity and working performance.
-
Page 12: Troubleshooting
Trouble Shooting Corrective Action Trouble First make sure the power supply is good. Then check The indicators and setting lights are not whether the matching power adapter is used. working. Try to restore to factory settings. When power is on, press on System Key for 10s. - Page 13 Corrective Action Trouble Try to a.exit the network and then add to the designated When adding devices to the gateway, gateway; indicator displays successful b.Check the version of the gateway and build the adding while there is no hint on the network and reboot.
- Page 14 Ordering WL Wireless Gateway Wireless Gate (LAN) Name WL-ZGWMDPB-G100-02 Model PC+ABS，Black Material & Color WLPN141030007 Item No.
-
Page 15: Software Download
Users can download the software by scanning the QR Code in the packaging box. Option B： Download link：http://www.wulian.cc/service.shtml Tips: For initial use, please read the Software User Manual carefully. Check the Tips Wulian website periodically for manual update availability and its relevance. - Page 16 TỔNG ĐẠI LÝ CHÍNH HÃNG WULIAN TẠI VIỆT NAM CÔNG TY TNHH TM và DV KHCN ĐO LƯỜNG Địa chỉ : Số nhà 12 Khu C - Dự án Mỹ Đı ̀ n h, Quận Nam Từ Liêm, TP Hà Nội, Việt Nam VPGD : Phòng 902, nhà...
