Summary of Contents for EtiamPro EDS201B/IP
- Page 2 EtiamPro QUICKSTART GUIDE Video/Audio Distributor Appearance Video/audio distributor Description Power indicator Network interface Cascade network indicator Network indicator Power input Reset button Cascade interface Terminals V. 02 – 12/05/2022 ©Velleman Group nv...
-
Page 3: Connection Scheme
EtiamPro Connection Scheme Installation Before You Start • Make sure the device in the package is in good condition. Make sure all related equipment is powered off during the installation. Check the product specifications for the installation environment. Steps Fix the DIN-rail onto the wall. -
Page 4: Wiring Description
Also, connect the 24 VDC from the power supply to the power connector on the monitor. EDS201B/IP distributor to indoor station monitor: 4 wires (2 wires data from the distributor + 2 wires power supply from the DIN rail). -
Page 5: Starting The System
EtiamPro Starting the System The system has a complete start-up wizard. It is very important to fully follow this wizard. Do not change any parameters during the start-up. Step 1. Enter a strong password and click OK. Step 2. Select the desired language and click Next. - Page 6 EtiamPro Step 3. Swipe the DHCP button to the right (the button briefly turns green before turning grey). You will receive an IP address from the router (home network). So, in short: Switch on first. The IP parameters will be filled in automatically.
- Page 7 EtiamPro Step 5. The device (outdoor unit) will appear in a list. Select the device in the list. A √ appears next to the device. Note that you do not need to enter a serial number manually. Step 6. Click Finish. The device is now ready-for-use. You can link the device to the Guarding Vision app for mobile use.
- Page 8 EtiamPro Linking to Guarding Vision Make sure the EDS201B/IP module is physically connected to your router with an LAN cable. Connect your smartphone with the wireless home network (Wi-Fi) or data network. Scan the QR code, which you can find in the settings menu of your monitor: indoor unit.
- Page 9 EtiamPro Select the + icon to add a device (1). Next, select the option Scan QR code (2). Scan the QR code which is displayed. The device has been added and is ready-for-use. You can now watch live and recorded images.
- Page 10 EtiamPro Activating Push Messages The push message function must be activated in order to receive push messages and live images when the doorbell is activated. V. 02 – 12/05/2022 ©Velleman Group nv...
- Page 11 Made in PRC Imported by Velleman Group nv Legen Heirweg 33, 9890 Gavere, Belguim www.velleman.eu...
