1 Introduction
No connection
Open imaging software
- Check workstation
- Image memory full or
plate detected without
patient selected
Unit in setup mode
(See chapter Advanced use)
Blinking in sequence:
- Imaging plate wrong way
round
Error number
4
Connected to imaging
application sw.
Not ready for processing
Ready to process
(Insert imaging plate)
Ready to Process
Image goes to workstation 4
(Insert imaging plate)
Remove protective cover
Manual plate removal
selected (Remove plate)
Waiting for 2nd size 3 plate
to make Comfort Occlusal™
4C image (Insert 2nd size 3
OR press START to cancel)
