Summary of Contents for ALTER TXA09
- Page 1 TX0 - TXA 2,45 GHz OPEN FRAME MAGNETRON HEADS, AIR COOLED (TXA) WATER COOLED (TX0) TX..09: 900 W TX..12: 1200 W TX..20: 2000 W TX..30: 3000 W TECHNICAL NOTE (issue: July 2008)
-
Page 2: Ce Declaration
Generatore di microonde (testa) TXA e TX0 product name: Microwave remotable head TXA and TX0 modelli: TXA09,TX009, TXA12, TX012, TXA20, TX020, models: TXA30, TX030, TXA31, TX031 al quale questa dichiarazione si riferisce sono conformi alle seguenti norme: comply with the following norms:... -
Page 3: Rohs Conformity
Decreto Legislativo D.L. n. 151 – 25/07/2005 (WEEE and RoHS) Starting from September 2005 Alter has set the rule to accept only RoHS compliant components from its Suppliers. At the present date of 15 May 2006, 90% of components in our stock is RoHS compliant. -
Page 4: Table Of Contents
TX0 - TXA Contents Indice CE Declaration 1 Assistenza tecnica 13 Components layout 2kW head air/water cooled 7 Avvertenze 4 Components layout 3kW head air/water cooled 8 Avvertenze Generali 4 Components list 10 Caratteristiche meccaniche 5 Environmental conditions 6 Caratteristiche elettriche 6 Equipment ratings 6 Condizioni ambientali di utilizzo 6 General Informations 4... -
Page 5: General Informations
TX0 - TXA Avvertenze Generali General Informations I generatori di microonde della serie TMA/TM0 sono These magnetron heads satisfy the European Standard conformi alla Norma Europea EN 61010-1 (=CEI 66-5) EN 61010-1 (=CEI 66-5) (=IEC 1010-1) approved by approvata dal Cenelec il 9/3/1993. CENELEC on 9/3/1993. -
Page 6: General Description And Ratings
The user is responsable of the respect of this rule: Alter di protezione, che impedisca l'accesso, anche involontario, will be not responsable of any use without a protective quando il generatore è... -
Page 7: Environmental Conditions
TX0 - TXA Equipment Ratings Caratteristiche elettriche Input voltage of Alimentazione del trasformatore filament trafo: look at voltage indication del filamento: dipende dall'alimen- on head's label. To modify tatore che lo pilota, pls look at filament transf- in genere 230V. Si ormer schematics below veda schema del Fan input:... -
Page 8: Components Layout 2Kw Head Air/Water Cooled
TX0 - TXA COMPONENTS LAYOUT 2kW Air cooled microwave generator 33,5 222,5 216,5 2kW Water cooled microwave generator 194,5 156,4 File: TX0-TXA_r0 - July 2008 - Manual for: TX0-TXA Heads page 7 of 13... -
Page 9: Components Layout 3Kw Head Air/Water Cooled
TX0 - TXA COMPONENTS LAYOUT 3kW Air cooled microwave generator air cooled 33,5 247,5 3kW Water cooled microwave generator 219,5 156,5 page 8 of 13 File: TX0-TXA_r0 - July 2008 - Manual for: TX0-TXA Heads... -
Page 10: Table Of The Models
TX0 - TXA Tabella riassuntiva dei modelli Available Models Table cooling water = present Magnetron 2M244 or similar air cooled Magnetron 2M137 or similar air cooled Magnetron 2M130 or similar air cooled Magnetron NL10230 or similar air cooled Magnetron 2M265 or similar air cooled Magnetron 2M107A or similar water cooled... -
Page 11: Components List
TX0 - TXA Components list Elenco componenti TXA..air cooled generator Pos Q.ty Description Note Centrifugal fan VEVC100 Filam. transformer for 0.9 kW magnetron 42FIL35F Filam. transformer for 1.2 kW magnetron 42FIL65F Filam. transformer for 2 /3 kW magnetron 42FIL100FR Fan grid VELZ302... -
Page 12: Tma Pin-Out Of The Connectors
HIGH VOLTAGE CABLE FIL100FR TRASF. FILAMENTO FILAMENT TRANSFORMER TX0 - TXA Pin connections of connectors Pin-out connettori generatore generator air cooled raff. ad aria TX020 SCHEMA GENERALE DEI COLLEGAMENTI TX020 GENERAL SCHEMATIC DIAGRAM CAVO DI TERRA EARTH CABLE MAGNETRON TXA20 raffreddato ad ARIA AIR cooled VITE DI TERRA... -
Page 13: Tm0 Pin-Out Of The Connectors
TX0 - TXA Pin connections of connectors Pin-out connettori generatore generator water cooled raff. ad acqua VITE DI TERRA TX020 EARTH SCREW MAGNETRON GI/VE 1.5mm≤ YELLOW/GREEN 1.5mm≤ CAVO DI TERRA EARTH CABLE TERMO-SWITCH THERMAL SWITCH CAVO DI ALTA TENSIONE TSW1 FASTON HIGH VOLTAGE CABLE FIL100FR... -
Page 14: How To Order
Cable sets: available on request Cablaggi: disponibili a richiesta La Alter si riserva il diritto di apportare miglioramenti o modifiche al prodotto descritto nel manuale in qualsiasi Alter reserves the right to improve or modify this products, momento e senza preavviso.
