Summary of Contents for Studio 77474295
- Page 1 W87*D97-167*H101-78CM...
- Page 2 BEFORE ASSEMBLY Check all components are present Do not use sharp knives to open any packaging Keep children and animals away from work area Ensure you have enough space to lay out the components before starting assembly Assembly the item on a soft level surface as close to its final position as possible Do not stand or put weight on the product or components, this may cause damage Assembly will be easier with 2 people Do not use power tools for assembly...
- Page 3 CLEANING Thorough cleaning is recommended every 6 months Do not use harsh chemicals Use a soft damp cloth with a gentle cleaning aid if necessary Never use hot water on the fabric Do not soak Accidental spillage Always tip the excess from the surface ...
- Page 4 COMPONENT PARTS PLEASE CHECK YOU HAVE ALL COMPONENTS LISTED BEFORE BEGINNING ASSEMBLY A X1 Seat Unit B X1 Back Cushion C X1 Left back ear D X1 Right back ear...
- Page 5 Assembly Instruction Stage 1 - Preparing the Seat Unit NOTE: It would be useful to ask someone to help you at this stage. Step 1 Carefully tilt back the seat unit onto it's back. See Fig.1. Step 2 Take the two back ears from the iron frame. See Fig.2.
- Page 6 Assembly Instruction Stage 3- Operating the Unit Back and Foot Rest Adjustment This Chair features a reclining back rest and raised foot rest. You need to be sitting in the chair to activate the features. Just pull the handle of the chair. The back will stretch and foot rest will open.
