Kohler Underscore K-1174-XH2G Quick Start Manual

Features

•
122 airjets release thousands of bubbles that surround, support,
and massage the body.
•
Variable-speed blower lets you adjust airjet massage intensity
to 18 levels.
•
Zones of Control feature allows you to target airjet massage
to back, midsection, or feet.
•
8 hydromassage jets can be individually adjusted for water flow
and direction.
•
Variable-speed pump for adjusting hydromassage intensity.
•
Built-in heater.
•
Lighted keypads.
•
Generous 6-foot length provides an incredibly spacious bathing
area.
•
Sloping backrest provides comfort.
•
Slotted overflow allows for deep soaking.
•
Immediate and manual purge cycles remove residual water
from air channels after use
•
Center drain.

Material

•
Acrylic

Hydrotherapy

•
BubbleMassage
•
Whirlpool

Installation

•
Drop-in or under-mount.
•
Requires 240V hard-wire electrical service.
•
Under-mount installation requires kit K-592 (sold separately).

Required Accessories

K-9698 Flexjet® Whirlpool Trim Kit
K-7271 Slotted Overflow Bath Drain
K-7272 Slotted Overflow Bath Drain
USA/Canada: 1-800-4KOHLER (1-800-456-4537)
www.kohler.com
3-14-2015 03:05
6' Bubblemassage Whirlpool Bath

Codes/Standards

ASME A112.19.7/CSA B45.10
CSA B45.5/IAPMO Z124
ASTM E162
ASTM E662
UL 1795
CSA C22.2 No. 218.2
CARB P2

Kohler One-Year Limited Warranty

See website for detailed warranty information.

Available Color/Finishes

Color tiles intended for reference only.
Color Code Description
0 White
96 Biscuit
47 Almond
NY Dune
95 Ice
G9 Sandbar
33 Mexican Sand
K4 Cashmere
58 Thunder
7 Black Black
Underscore
K-1174-XH2G
Grey
Grey
