PANEL DETAILS
DISCLAIMER OF LIABILITY:
Disclaimer of Liability
Since the conditions or methods of installation, operation, use and maintenance
Since the conditions or methods of installation, operation, use and maintenance of this product are beyond its
of this product are beyond its control, Manfred Frank Systems Limited does not
control, Manfred Frank Systems Limited does not assume responsibility and expressly disclaims liability of loss,
assume responsibility and expressly disclaims liability of loss, damage, or expense arising
damage, or expense arising out of or in any way connected with such installation, operation, use, or maintenance.
out of or in any way connected with such installation, operation, use, or maintenance.
10.0
2 x 45 Chamfer
Note:
Dimensions based on Zero Gap
between Door and Frame
Adjust Hinge for Gap
between Doors
M8 Washer (x2)
4x25 Pan Head Wood Screw (x6)
4x20 Pan Head Wood Screw (x4)
CURTAIN WALL - D50 MORTISED INSERT - NON-GLASS DOOR - NON-GLASS FRAME
THRU
M8 Socket Head Cap Screw (x2)
© Manfred Frank Systems Ltd.
All Rights Reserved.
Manfred Frank Systems, Unit C, 11 Echelon Place, Botany 2013, Auckland, New Zealand
USE INSERT POSITION 4,3 or 2
M8 Insert Nut (x2)
Door Insert D5B
Clip On Cover D5D
©
