Summary of Contents for Wise TSW500CATV
- Page 1 Operation Manual TSW500CATV Version: 1 Revision: 0 November/2017 Wise Telecommunications Industry...
- Page 2 Copyright Wise Telecommunication Industry created this manual. No part or contents of this manual reprinted without written authorization Wise Telecommunication Industry. Wise Telecommunication Industry reserves itself the right to alter its products, and the manual contents, at any time, without any warning, according to its own needs.
-
Page 3: Table Of Contents
Summary 1. Introduction ......................4 1.1 TSW500CATV Characteristics ............... 4 1.2 Technical Specifications .................. 4 2. Characteristics ....................... 5 2.1 Keyboard ......................5 2.2 Battery ......................6 3. Equipment Initial Operation .................. 7 3.1 Setting the Equipment ..................7 3.1.1 System Configuration ............... 7 3.1.2 Date/time Configuration .............. -
Page 4: Introduction
BER and MER and a voltmeter. The TSW500CATV has a plastic shield that makes it resistant to impact; it is lightweight and has a simple and practical keyboard that makes possible the operation with only one hand. -
Page 5: Characteristics
- Voltage: 1 Vdc until 100 Vdc. 2. Characteristics 2.1 Keyboard Figure 2.1: TSW500CATV Keyboard. The TSW500CATV keyboard has a key diversity to facilitate your operation: Power Button; Go to the main menu; Function of these keys dependent on the screen displayed. The label displayed in the lower line, right above the keys;... -
Page 6: Battery
If the battery is not charged up to its maximum capacity, the TSW500CATV operating time will be reduced. To avoid power line interferences that may alter the test results, it is wise to avoid connecting or disconnecting the TSW500CATV battery charger whenever a test is in progress. -
Page 7: Equipment Initial Operation
The choice is made using the move keys . To start the desired test press 3.1 Setting the equipment Press the key to enter in the settings of TSW500CATV, use the keys to choose the options. Figure 3.2: Setup Options screen. 3.1.1 System Configuration Figure 3.3: System Setup screen. -
Page 8: Date/Time Configuration
Changes the year. Use the directional keys to increase or decrease. 3.1.3 Channel Configuration This screen contains a list with the name and type of the channels, to change some channel choice with the directional keys and press . Back to press Wise Telecommunications Industry... -
Page 9: Line-Up Update
IMPORTANT: Never connect the USB cable and the coax at the same time, it can generate from malfunctions until destruction of equipment. There is in the TSW500CATV the option to create and update the line-up of channels through the software, can be downloaded on the website of Wise Telecommunications industry (www.wi.com.br). -
Page 10: Ingress Configuration
Remembering that the line-up file is a .csv file (comma delimited file), which can be created in excel or in note block of the following modes: (a) CSV file in excel. (b) CSV files in Notepad. Figure 3.8: CSV file creation modes. 3.1.5 Ingress Configuration Figure 3.9: Ingress Test Setup screen. Wise Telecommunications Industry... -
Page 11: Tests
On this screen, you can choose the channel. In addition, the following parameters can be viewed: Type Analogue or Digital. Channel Channel number. Name Name of the channel. Video Freq. Wise Telecommunications Industry... - Page 12 Use the key keys to move the marker. Within the screen with the spectrum press to use a marker to show the marker frequency power. Use the key keys to move the marker. Wise Telecommunications Industry...
- Page 13 BER PRE Bit error rate before the correction made by the tuner. BER POST Bit error rate after the correction made by the tuner. ERR PACKAGES. Number of packets wrong. POWER Carrier power. Wise Telecommunications Industry...
-
Page 14: Frequency Test
15 channels. To start press (a) Tilt channels selection. (b) Tilt graph. Figure 4.7: Tilt screens. To facilitate the marking of channels there is a filter button that can be accessed press . It contains a filter type of existing channels. Wise Telecommunications Industry... -
Page 15: Full Scan
17dBmV or less than 13dBmV. When finished it is possible score a point by pressing and moving the markup with the directional To update the graphic press and to return Figure 4.9: Full Scan. Wise Telecommunications Industry... -
Page 16: Ingress Test
The directional keys move the cursor. The value is shown on the lower right side. The button restarts the test. 4.6 Voltmeter Figure 4.11: Voltmeter. The voltmeter is used to measure DC voltage on the cable for field-testing. Wise Telecommunications Industry... -
Page 17: Software Update
IMPORTANT: Never connect the USB cable and the coax at the same time because this can generate from malfunctions until destruction of equipment. To update the TSW500CATV is necessary to use the UPW updater that can be found on the website of Wise Telecommunications industry (www.wi.com.br). After installing the UPW follow these steps to update the equipment.
