Falcon H8 LED Handheld Light
Features
Falcon H8 is a compact hand-held LED tactical flashlight, which packs state-of-the-art optical
engineering and a customized LED light source into a single unit.
◎ With a power consumption of only 10 w, it puts out a beam as far as 800 m which is a world
record in terms of brightness and beam throw for its class
◎ Multi-mode operation: Strobe, high, and 1%-50% dimming, selectable with the press (and hold)
of a single button
◎ Continuous twist focusing that makes it easy to adjust from spot to flood
◎ A sturdy aerospace-grade aluminum alloy housing with a HAIII military-grade hard-anodized
finish that ensures rugged and reliable performance under extreme conditions and is waterproof
up to 5 m of submersion
General Information
Characteristics:
Peak beam intensity
Range
Modes
Runtime
Power supply
Charge time
Beam divergence
LED power consumption
Bezel diameter
Housing diameter
Page 1 of 3
160,000 cd
800 m (as per ANSI/PLATO FL1-2016)
100% power;
1%- 50% dimming;
2 hr (100% power);
1*18650（3,400mAh) rechargeable Li-ion batteries or 2*CR123A
3.5 hr (by MicroFire A1 AC charger)
2.4° - 24°
40 mm
25.4 mm
Operation Manual
Strobe
56 hr (1% power)
10 W
http://www.microfire-system.com
Advertisement
Table of Contents
Summary of Contents for MicroFire Falcon H8
- Page 1 Falcon H8 LED Handheld Light Features Falcon H8 is a compact hand-held LED tactical flashlight, which packs state-of-the-art optical engineering and a customized LED light source into a single unit. ◎ With a power consumption of only 10 w, it puts out a beam as far as 800 m which is a world record in terms of brightness and beam throw for its class ◎...
- Page 2 50% level. Release the button to lock the brightness level. 3. Strobe activation: When the light is off, press and then release the button after 3 seconds, strobe will be activated. 4. Beam divergence adjustment: Page 2 of 3 http://www.microfire-system.com...
- Page 3 All rights on the design of MicroFire website, brochure, manuals and/or all sales publications are solely owned and reserved by MicroFire Technology Co., Ltd. Reproduction of the site or any part thereof or of any MicroFire publications is prohibited and will be prosecuted for copyright infringement 5.
