Aim FOL429-P Hardware Manual

Portable standalone fibre optic link for arinc429
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FOL429-P
Portable
Standalone
Fibre Optic Link
for
ARINC429
Hardware
Manual
V01.01 Rev. A
January 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FOL429-P and is the answer not in the manual?

Questions and answers

Summary of Contents for Aim FOL429-P

  • Page 1 FOL429-P Portable Standalone Fibre Optic Link ARINC429 Hardware Manual V01.01 Rev. A January 2017...
  • Page 3 FOL429-P Portable Standalone Fibre Optic Link ARINC429 Hardware Manual V01.01 Rev. A January 2017 AIM No. 60-90436-16-0101-A FOL429-P Hardware Manual...
  • Page 4 Notice: The information that is provided in this document is believed to be accurate. No responsibility is assumed by AIM GmbH for its use. No license or rights are granted by implication in connection therewith. Specifications are subject to change without notice.
  • Page 5 The following table defines the history of this document. Version Cover Date Created by Description 01.00 Rev A 19.01.2017 Matthias Lamp First Release 01.01 Rev A 27.01.2017 Matthias Lamp Add some clarifying description for ARINC429 speed settings FOL429-P Hardware Manual...
  • Page 6 THIS PAGE IS INTENTIONALLY LEFT BLANK FOL429-P Hardware Manual...

  • Page 7: Table Of Contents

    Power Supply Connector .......................10 LED indicators ..........................10 TECHNICAL DATA ....................11 Notes ........................13 Acronyms ..........................13 Appendix ....................... 15 Signal Propagation Delay measurements of the system .............15 Certificate of Volatility ......................16 Safety Instruction for Lithium batteries .................17 FOL429-P Hardware Manual...
  • Page 8 Figure 2-2: FOL429-P rear plate ..................4 Figure 2-3: Front Plate FOL429-P-T ................5 Figure 2-4: Front Plate FOL429-P-R ................5 Figure 2-5: DSUB37 female..................... 6 Figure 2-6: FOL429-P Power supply overview ..............9 Figure 2-7: FOL429-P DC Power-Plug ................10 LIST OF TABLES Figure...

  • Page 9: Introduction

    In order to support such scenarios, AIM GmbH have developed a fibre optical based system, which allows users to connect commercial of the shelf avionics data bus test equipment over an extended distance to the aircraft data bus or the unit under test.

  • Page 10: How This Manual Is Organized

    1. INTRODUCTION 1.2 How This Manual is organized The FOL429-P Hardware Manual is comprised of following sections. Section 1 - Introduction - contains an overview of this manual. Section 2 - System Overview and Component Description describes the basic operation of the FOL429 system as well as the component connections.

  • Page 11: Components Description And Connectors

    2 COMPONENTS DESCRIPTION AND CONNECTORS 2.1 Component description The FOL429-P system contains of two components, the FOL429-P-T and FOL429-P-R part. These two Parts establish a unidirectional link from the UUT to the analyser or from the analyser to the UUT.

  • Page 12: Connectors And Indicators

    2. COMPONENTS DESCRIPTION AND CONNECTORS 2.2 Connectors and indicators 2.2.1 Rear plate Connectors and the LED on the rear plate of the FOL429-P-T and -R • Figure 2-2: FOL429-P rear plate  DSUB37 (female) Connection to the ARINC429 Stub (LRU) or analyser.

  • Page 13: Front Plate

    2. COMPONENTS DESCRIPTION AND CONNECTORS 2.2.2 Front plate The following figures show the Front Plate of the FOL429-P-T and FOL429-P-R. Figure 2-3: Front Plate FOL429-P-T Figure 2-4: Front Plate FOL429-P-R FOL429-P Hardware Manual...

  • Page 14: Connection To Uut Or Analyser

    DC power supply.  Power switch to switch on and off the FOL429-P, the charge of the internal battery is independent of the switch, and starts as soon an external power supply is connected.

  • Page 15: Table 2-1: Pinout Dsub37 Rx

    RX channel 10 RX# channel 11 RX channel 11 RX# channel 12 RX channel 12 RX# channel 13 RX channel 13 RX# channel 14 RX channel 14 RX# channel 15 RX channel 15 Table 2-1: Pinout DSUB37 RX FOL429-P Hardware Manual...

  • Page 16: Table 2-2: Pinout Dsub37 Rx

    TX channel 10 TX# channel 11 TX channel 11 TX# channel 12 TX channel 12 TX# channel 13 TX channel 13 TX# channel 14 TX channel 14 TX# channel 15 TX channel 15 Table 2-2: Pinout DSUB37 RX FOL429-P Hardware Manual...

  • Page 17: Power Supply, Internal Battery / Battery Charger

    FOL429-P-R unit using a 62,5µm/125µm multimode gradient index optical fibre. The optical output of the FOL429-P-T [Out Ch. 0..7] should be connected to the optical input of the FOL429-P-R [In Ch. 0...7] and the optical output of the FOL429-P-T [Out Ch.

  • Page 18: Power Supply Connector

    2. COMPONENTS DESCRIPTION AND CONNECTORS If the FOL429-P is switched off, the charging time is lower than when the System is operational. The typical operation time is listed in the Technical Data chapter. Note: The temperature range, where the batteries can be charged is limited to 0…45°C.

  • Page 19: Technical Data

    11,2V capacity 2600mAh; ~29Wh Battery operating time: FOL429-P-T = ~6h Charge: Charge current 1,1A Charge time ~3:30h (FOL429-P is switched off) ~4:30h (FOL429-P is operating) Power: V = 15..28VDC, min. 1,3A DCIN Dimensions: height: = 37mm width: = 138mm length:...
  • Page 20 The optical Transmitter/ Receiver modules are designed for a data communication over several hundred of meters, which imply the corresponding attenuation on the fibre connection. If the FOL429-P-T and FOL429-P-R are connected via short jumper cables, then communication failures on the fibre optic link may happen, because of saturation effects on the optical receiver unit.

  • Page 21: Notes

    Joint Test Action Group (IEEE 1149.1 Boundary Scan) Logic Cell Array (XILINX - Programmable Gate Array) Line Replaceable Units Light-emitting Diode MIL-STD Military Standard MILbus MIL-STD-1553 bus Surface Mounted Device Tester Universal Fibre Optic Unit Under Test FOL429-P Hardware Manual...
  • Page 22 4. NOTES THIS PAGE INTENTIONALLY LEFT BLANK FOL429-P Hardware Manual...

  • Page 23: Appendix

    = 2*10 Following formulas can be applied to calculate the propagation delay of a given system: td = 1µs + (L / CF) Monitor System (uni-directional) L = Length of fibre optic cable in one direction [m] FOL429-P Hardware Manual...

  • Page 24: Certificate Of Volatility

    All operating Data for handling the I/O Protocol will be stored in volatile memory only. No Transfer data is stored in Non-Volatile Memory. The Non-Volatile Memory only contains production relevant data for board personalisation, FPGA Logic or Firmware Code for the on board Microcontroller. FOL429-P Hardware Manual...

  • Page 25: Safety Instruction For Lithium Batteries

    3. Do not longer use the Battery if damaged, overheated, deformed or other irregularities. Classification: The used Battery is below 100Wh and fix mounted into a Device. The UN classification is UN3481. PI967-Section 2. One Battery per FOL429-P-T / -R is included FOL429-P Hardware Manual...
