® EarthLinked Series PHXTI Pool Heat Exchangers Installation Manual CONTENTS PAGE Pre-Installation Installation • Water Connections • Refrigerant Connections • Freeze Protection/Winterizing • Warranty PHXTI-IM (05/13) Copyright 2013 Earthlinked Technologies, Inc. - Page 2 HVACR equipment, and in accordance with instructions set forth in this manual. Earthlinked Technologies shall not be liable for any defect, unsatisfactory performance, damage or loss, whether direct or consequential, relative to the design, manufacture, construction, application or installation of other components in the swimming pool system.
-
Page 3: Pre-Installation
1. Pre-Installation Upon receipt of the swimming pool heat exchanger, check the model number against the bill of lading. The Earthlinked Technologies model numbers are as follows: Model Number Rating, BTU/HR PHXTI-90 90,000 PHXTI-115 115,000 PHXTI-130 130,000 This heat exchanger is approved for use with swimming pool heat pump heating systems using R-410A, R-407C or R-22 refrigerants. -
Page 4: Water Connections
Figure 1. Heat Exchanger Dimensions A. Water Connections A typical piping arrangement for the installed heat exchanger is shown in Figure 2. The heat exchanger is installed downstream of the filter and upstream of the water conditioning system. The heat exchanger shall be no more than 10 feet from the heat pump compressor unit. In addition, the heat exchanger water inlet and outlet connections shall have union connections to the water circuit. - Page 5 Figure 2. Typical Pool Installation Piping The heat exchanger water connections are nominal 2 inch PVC. Plumb these connections first, as follows: 1. With abrasive cloth (Oatey #31411 or equivalent), roughen the ID surfaces of the female connectors on the heat exchanger and the OD surfaces on the water supply and return PVC pipes.
- Page 6 Figure 3. Heat Exchanger Refrigerant Connections PHXTI-IM (05/13) Page 6...
-
Page 7: Refrigerant Connections
B. Refrigerant Connections The refrigerant connections are shown in Figure 3. Each connection is 5/8 inch OD copper tube. The refrigerant line connections are brazed as follows: 1. Clean and deburr the copper stub outs and the field supplied fittings that will make the connections from the refrigeration system. - Page 8 ® Figure 4. Wrap SWAGLOK Joints PHXTI-IM (05/13) Page 8...
- Page 9 Figure 5. Apply Flame Retardant Shield PHXTI-IM (05/13) Page 9...
- Page 10 Figure 6. Braze Joints PHXTI-IM (05/13) Page 10...
-
Page 11: Freeze Protection/Winterizing
5. After the refrigerant joints have been brazed, seal test the joints by pressurizing the refrigeration system to 150 psig dry nitrogen and check each joint with a quality leak detector. 6. Next, evacuate the refrigeration system in accordance with the pool heater system manufacturer’s instructions, being sure to thoroughly remove all moisture from the system. -
Page 12: Warranty
D. Warranty All warranty claims shall be handled directly through AquaCal AutoPilot, Inc. PHXTI-IM (05/13) Page 12...
