Summary of Contents for Nextar XPJ
- Page 2 Warning Statement All contents subject to change without prior notice WARNING This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 3: Table Of Contents
Important Safety Instructions --------------------------------------------------- 4 Introduction ------------------------------------------------------------------------- 5 ----------------------------------------------------------------------------5 ROJECTOR EATURES ------------------------------------------------------------------------------6 HIPPING ONTENTS ROJECTOR EXTERIOR VIEW Front / Upper View ----------------------------------------------------------------------------7 Left Side View ----------------------------------------------------------------------------------7 Right Side View --------------------------------------------------------------------------------8 Lower / Bottom View --------------------------------------------------------------------------8 ONTROLS AND UNCTIONS External Control Panel -----------------------------------------------------------------------9 Remote Control ------------------------------------------------------------------------------ 10 Remote control effective range------------------------------------------------------------- 11 Replacing the remote control battery ----------------------------------------------------- 11... -
Page 4: Important Safety Instructions
Avoid using an extension cord with a low voltage limit, as it may cause short-circuiting and physical injury. λ Do not catch your finger between the unit and surface of the floor when moving the projector installed on the floor. λ... -
Page 5: Introduction
Introduction Projector Features The projector integrates high-performance optical engine projection and a user-friendly design to deliver high reliability and ease of use. The projector offers the following features: λ Quick cooling function for reducing projector cooling time; λ Compact and portable unit;... -
Page 6: Shipping Contents
Shipping Contents The projector is shipped with the cables required for connection to a PC and video output devices. Carefully unpack the box and verify that you have all of the items shown below. If any of these items are missing, please contact your place of purchase. -
Page 7: Projector Exterior View
Projector exterior view Front / Upper View Left Side View Refer to "Connection" on page 12 6. 12VDC Power jet input 7. Main Power Switch 8. 3.5mm Audio in Phone Jack for more information on making connections to various equipment. -
Page 8: Right Side View
Right Side View 11. 2W mono speaker Lower / Bottom View 13. Lamp Cover 12. Lamp cover 14. Ceiling mount and adjustable feet... -
Page 9: Controls And Functions
1. Focus adjuster (lens focus can be adjusted by this key). "Start up" on page 14 2. Power (Refer to Turns the projector on or off. 3. Right key. (OSD control only). 4. Down key. (OSD control only). 5. Volume increase. Digital volume control. -
Page 10: Remote Control
Remote Control POWER – Turns the projector on or off. SOURCE – Sequentially selects the input signal Video, S-Video, Component Video, or RGB. MUTE – Audio mute on or off. Display – Display the video standard and mode. UP – Up key for OSD control. -
Page 11: Remote Control Effective Range
Infra-Red (IR) remote control sensors are located on the front and the back of the projector. The remote control must be held at an angle within 30 degrees of the projector’s IR remote control sensors to function correctly. The distance between the remote control and the sensors should not exceed 6 meters (~ 20 feet). -
Page 12: Connection
This section describes how to connect the projector to video source devices using video cables. Video cable connections are recommended for video presentations. You can connect your projector to various video source devices that provide any one of the following output sockets: λ... - Page 13 The audio connections illustrated in the following sections are provided for informational purposes only. You need not connect audio to the projector if there is an alternate sound system available, or if audio is not required.
-
Page 14: Operation
Check that the Power indicator on our projector adapter lights orange after power has been applied. 2. Plug the DC plug into the projector’s 12VDC socket. Remove the lens cap. If it is left on, it could become deformed due to the heat produced by the projection lamp. -
Page 15: Shutdown
Do not unplug the adaptor or power cord before the projector shutdown sequence is complete, or λ during the 45-second cooling down process. If the projector is not properly shut down, you risk damaging the lamp. Do not move the projector while λ the lamp is hot. -
Page 16: Menu Operation
Menu operation Menu system OSD MENU1 OSD Menu 2 Video S-Vide Dynamic Static Theater Game Front/Up Front/Down Rear/Up Rear/Down 0 to 100 Brightness (Default 50) 0 to 100 Contrast (Default 50) -
Page 17: Osd Menu
0 to 100 Color (Default 50) OSD Menu 3 0 to 100 Hue (Default 50) English French German Spanish Portuguese Italian System Default... -
Page 18: Picture Menus
Picture menus Some picture adjustments are available only when certain input sources are in use. FUNCTION (Default setting / Value) Source Input 1. Video Input: RCA composite video 2. S-Video Input: Mini DIN5 S-Video Video Mode 1. Dynamic (Default): Is suitable for enjoying colorful movies and TV in a blackened living room lighting level environment. - Page 19 Language sets the language for the OSD control menus. Use Left / Right select your desired language. Default Returns all settings to the factory preset values. on the projector , or Left / Right on the remote control, to...
-
Page 20: Troubleshooting
You are too far away from the projector. Remedy Plug the power cord into the AC inlet on the projector, and plug the power cord from the power outlet. If the power outlet has a switch, make sure that it is switched Wait until the cooling down process has completed. -
Page 21: Maintenance
Care of the projector Your projector needs little maintenance. The only thing you need to do on a regular basis is to keep the lens clean. Never remove any parts of the projector except the lamp. Contact your dealer if other parts need replacing. -
Page 22: Specifications
Specifications Projector specifications * All specifications are subject to change without notice. Display Technology Resolution Contrast Ratio Lamp Type and Life Maximum Resolution Dimensions (WxHxD) Aspect Ratio Noise Level Projection Lens Image Size Video Compatibility Displayable Colors Projection Method Power Supply... -
Page 23: Dimensions
Dimensions Unit: mm... -
Page 24: Warranty
Warranty Limited Warranty NEXTAR warrants this product against any defects in material and workmanship, under normal usage and storage. Proof of purchase date will be required with any warranty claim. In the event this product is found to be defective within the warranty period, NEXTAR’s only obligation—and your exclusive remedy—shall be replacement of any defective parts (labor included). - Page 25 Nextar may find it necessary to modify, amend or otherwise change or update this manual. We reserve the right to do this any time, without any prior notice. All specifications and features are subject to change without notice. All screen shots shown are simulated and may not represent the actual screen on production units sold to consumers.
