    1 Introduction 1.1 Purpose This document provides guidance on how to use the H2S-30 HDMI® to SDI converter that incorporates High-Definition Multimedia Interface technology, as well as the Doremi Universal Interface Software (DUIS). It explains all features of the H2S as well as the infrared remote control and how to upgrade the firmware.

  • Page 9: H2S-30 Overview

    2 H2S-30 Overview 2.1 H2S-30 Description The H2S-30 is an HDMI to SDI format converter featuring HDMI and SDI connectors that allow for any HDMI input to be converted to any supported SDI output format or scan rate. It supports both SD and HD video and employs 12 bit bi-cubic interpolation to ensure the highest quality picture.

  • Page 10: H2S-30 Rear Panel

    2.1.3 H2S-30 Rear Panel The H2S-30 rear panel is illustrated below: Power Connector HDMI SYNC SDI-B SDI-A Figure 3: H2S-30 Rear Panel View The rear panel has the following connectors: Connector Description USB connector HDMI in HDMI input connector SDI-A out SDI output connector –...

  • Page 11: Supported Formats

    2.2 Supported Formats The table below summarizes all supported inputs and outputs available on the H2S-30. Supported Input(s) Supported Output(s) HDMI: Supported input formats are SD-SDI: NTSC, PAL (SMPTE 259M-C listed below: 4:3 or 16:9, SMPTE 259M-C 4:3 or 16:9)

  • Page 12: H2S Osd Menu System Overview

    3 H2S OSD Menu System Overview The H2S-30 is configured using the IR remote control to access the menu system through the OSD (see Section 4). Or by using the Doremi Universal Interface Software (DUIS) - see Section 3.1 Input Menu The Input menu can be used to set up the input parameters.

  • Page 13: Output Menu

    Set the SDI output pixel SDI Resolution NTSC resolution. Match Input: In this mode, the 720p SDI output will have the same 1080i/sf resolution as the input source. 1080p 2Kp Flat Match Input H2S.OM.001539.DRM Page 13 Version 1.3 Doremi Labs...
  • Page 14 Off: No embedded timecode on Free wheel SDI output. Bypass SDI: Pass embedded timecode from HDMI input to SDI output. Free wheel: Generate embedded Time Code starting at the moment this option is enabled. H2S.OM.001539.DRM Page 14 Version 1.3 Doremi Labs...

  • Page 15: Color Space

    • 0 to 1023 for 10bit coding • On the H2S-30, the full range modes are designated by the “ext” following the color space conversion mode. 3.3 Image Menu The Image menu can be used to set up the image parameters.
  • Page 16 For User Defined Input LUT use the DUIS software (see Section 5.4.3) Output LUT User Defined Set the output Gamma correction. 0.1 to 4.0 For User Defined Output LUT use the DUIS software (see Section 5.4.3) H2S.OM.001539.DRM Page 16 Version 1.3 Doremi Labs...

  • Page 17: Sync Menu

    Sub-Menu Value Description HDMI/DVI Input Extern: Sync is derived from the Sync Input connector. Extern H offset X pixels Horizontal Sync offset in pixels V offset X lines Vertical Sync offset in lines H2S.OM.001539.DRM Page 17 Version 1.3 Doremi Labs...

  • Page 18: Audio Menu

    SDI Output: 48 kHz • Note: The H2S-30 does not support audio sample rate conversions. If using the Embedded SDI Audio output, you must use 48 kHz audio on the HDMI input. Using unsupported audio sample rates will result in degraded audio output.

  • Page 19: On Screen Display (Osd) Menu

    H2S- levels when the 30 output OSD is not active. Input Status: In addition to the timecode BIW, the H2S-30 output will display the Input Status including Audio levels, Closed Caption presence, Input Format and CRC errors (flashing red dot).

  • Page 20: System Menu

    Infra-Red. To avoid IR interference with multiple H2S-30 units, assign each a different IR code from 0x0 to 0xF (16 total) default is 0. Set the DIP switch on the Doremi IR remote accordingly...

  • Page 21: Infrared Remote Controller

    The Menu System can be accessed using the IR remote controller in conjunction with the OSD. Pressing the Menu button will invoke the menu system. The Left arrow, Right arrow, Select and Exit buttons can be used to navigate the OSD menu selections and set up the H2S-30. 4.1 Remote Controller Overview “Select”...

  • Page 22: Remote Controller Functions

    “Select” button Ok/Select Scaling Cycles through the image settings De-Int Filter Cycles through the available De-int Filter settings Status OSD Cycles through the OSD status options Save Saves the current settings to flash H2S.OM.001539.DRM Page 22 Version 1.3 Doremi Labs...

  • Page 23: Input Source Setting

    Then, press the Output format to set: 480i, 576i, 720p, 1080i, 1080p, InRes, InFPS, • (more formats are available through the menu system). See Figure 6 below for more information. Figure 6: Quick SDI Output Format Setting H2S.OM.001539.DRM Page 23 Version 1.3 Doremi Labs...

  • Page 24: Setting The Ir Channel

    When using multiple H2S-30 units, you can avoid interference by pairing each unit to an individual remote. Assign each H2S-30 a different IR code from 0x0 to 0xF (16 total), and set the dip-switches on the Doremi IR remote accordingly.

  • Page 25: Doremi Universal Interface Software (Duis)

    5.1 DUIS Installation To install the Doremi Universal Interface Software, follow the steps below: Plug the USB cable between the H2S-30 and an available USB port on a computer. • If the "Found New Hardware Wizard" window appears click “Cancel.”...
  • Page 26 Figure 11: ”Found New Hardware Wizard” Window Last Step Run the DUIS and verify that there is a proper connection. • If the "Hardware Installation" warning window appears, click on the “Continue Anyway” • button (see Figure 12 & 13). H2S.OM.001539.DRM Page 26 Version 1.3 Doremi Labs...
  • Page 27 Figure 12: Hardware Installation Warning Window Figure 13: Hardware Installation Warning Window for Windows 7 H2S.OM.001539.DRM Page 27 Version 1.3 Doremi Labs...

  • Page 28: Doremi Universal Interface Software Overview

    The “Devices” field, located on the top of the window, can be used to select a connected • H2S-30 from the drop down menu. Click on the “Refresh” button to see if all the connected H2S-30 units are visible (see Figure 14).

  • Page 29: Settings Field

    5.3 Settings Field The Settings field can be used to manage the settings files. To save the current H2S-30 configuration settings into a file, enter a settings "filename" • into the “Settings” text box in the top left corner and then click on the “Save” button.
  • Page 30 The imported file will appear in the “Settings” field on the left part of the window. To • apply the settings to the connected H2S-30 unit, select the file and click on the “Load” button. The H2S-30 settings will be updated (see Figure 15).

  • Page 31: Tabs Description

    Section 3.1. 5.4.2 Output Tab The Output tab is illustrated below in Figure 16. Figure 16: H2S-30 Control Panel Output Tab All parameters are explained earlier in this manual in Section 3.2. H2S.OM.001539.DRM Page 31 Version 1.3...

  • Page 32: Image Tab

    LUT User Gamma Curves Radio Button Button Figure 17: H2S-30 Control Panel Image Tab All parameters are explained earlier in this manual in Section 3.3. To define either an Input or Output Gamma Curve, click the corresponding “User” radio •...
  • Page 33 Load File Radio Button Formula Editing Section Figure 18: Gamma Correction Pop-Up Window H2S.OM.001539.DRM Page 33 Version 1.3 Doremi Labs...

  • Page 34: Sync I/O Tab

    5.4.4 Sync I/O Tab The Sync I/O tab is illustrated below in Figure 19. Figure 19: H2S-30 Control Panel Sync I/O Tab All parameters are explained earlier in this manual in Section 3.4. H2S.OM.001539.DRM Page 34 Version 1.3 Doremi Labs...

  • Page 35: Audio Tab

    5.4.5 Audio Tab The Audio tab is illustrated below in Figure 20. Figure 20: H2S-30 Control Panel Audio Tab All parameters are explained earlier in this manual in Section 3.5. H2S.OM.001539.DRM Page 35 Version 1.3 Doremi Labs...

  • Page 36: Osd Tab

    5.4.6 OSD Tab The OSD tab is illustrated below in Figure 21. Figure 21: H2S-30 Control Panel OSD Tab All parameters are explained earlier in this manual in Section 3.6. H2S.OM.001539.DRM Page 36 Version 1.3 Doremi Labs...

  • Page 37: System Tab

    Display Logs Firmware Button Upgrade Button Figure 22: H2S-30 Control Panel System Tab The parameters are explained earlier in this manual in Section 3.7. In addition, the System tab can be used to perform the following functions: • To save the current settings to flash, click on the “Save Settings” button (see Figure 22).
  • Page 38 A window containing the logs will appear: • Figure 23: Log Window Select “Auto Update” from the Log Window to see all messages (see Figure 23). • H2S.OM.001539.DRM Page 38 Version 1.3 Doremi Labs...

  • Page 39: Firmware Update

    The firmware can be updated through a USB using the DUIS. In case one of the files listed in the procedures below is missing, please contact Doremi Labs (see Section 1.3). Note: The H2S-30, S2H-30, and GHX-10 all use the same firmware version, which is included with the DUIS software.

  • Page 40: Acronyms

    7 Acronyms Term Definition DUIS Doremi Universal Interface Software Digital Visual Interface HDMI High-Definition Multimedia Interface HD-SDI High-Definition Serial Digital Interface Infra Red On Screen Display Pixel Aspect Ratio Serial Digital Interface Universal Serial Bus H2S.OM.001539.DRM Page 40 Version 1.3...

  • Page 41: Document Revision History

    8 Document Revision History Date Version Description 02/10/2011 First version. 03/02/2011 New pictures added. 07/26/2012 Logo and contact information updated. 02/13/2013 Minor revisions made to entire document. Section 1 updated. H2S.OM.001539.DRM Page 41 Version 1.3 Doremi Labs...
