35-Keys (Full-Travel 50 million ops) Includes Relegendable Keycaps
•
Fully-Programmable Serial Settings
•
Fully-Programmable Key Table
•
USB 1.0, 1.1, 2.0 or RS232C Compliant (Half-Duplex)
•
USB or Serial Cable (6' or 2 Meters)
•
Programmable LED (Top/Left Corner Key)
•
Internal "Flash" memory holds Key data and Settings.
•
Includes Genovation re-programming software "MacroMaster681" for easy customization & set-
up.
Controlpad 681
Fully-Programmable
RS232 or USB Serial Keypad
Product Features
Factory Default Settings
RS232 Settings
Baud Rate = 9600
Data Bits = 8
Stop Bits = 1
Parity = None
Protocol = None
Copyright© 2004,2005 Genovation, Inc.
Advertisement
Table of Contents
Related Manuals for Genovation Controlpad 681
Summary of Contents for Genovation Controlpad 681
- Page 1 • Programmable LED (Top/Left Corner Key) • Internal “Flash” memory holds Key data and Settings. • Includes Genovation re-programming software “MacroMaster681” for easy customization & set- Factory Default Settings RS232 Settings Baud Rate = 9600 Data Bits = 8 Stop Bits = 1...
- Page 2 Run the “TEST” utility, click the “Find Controlpad 681” Button. The Test Utility will now locate any Controlpad 681 on your PC. Once found, click it will inform you of it’s COM port location and allow you to TEST the keypad. Click the “TEST” button.
- Page 3 Any abuse including opening the case will void the warranty. Your sole remedy and Genovation's entire liability for this product will be repair or replacement as provided for above, or at Genovation's option, the refund of your purchase price.
