Page 2
WARNING Seller and Manufacturer disclaim all and any liability for property damage, personal injury, or loss, direct, indirect, or incidental, resulting from the incorrect assembly, inadequate maintenance, improper use, or neglect of this product. NOTICE Keep these assembly instructions for future reference. Do not use this product if there are missing, damaged, or broken parts until repairs are made and/or factory replacement parts are installed.
Page 3
ARMCHAIR PARTS Washer Bolt (M6 x 40mm) x 14 x 14 A ..Right Side ....x 1 B ..Left Side....x 1 C..Back ......x 1 D..Seat ......x 1...
Page 4
ARMCHAIR ASSEMBLY - STEP 1 Washer Bolt (M6 x 40mm) Attach Left Side (B) to Back (C) with Washer (E) and Bolt (F) as shown. Note: Do not fully tighten any bolts until assembly is complete. Failure to follow these instructions may cause the bolt holes to be misaligned during assembly.
Page 5
ARMCHAIR ASSEMBLY - STEP 2 Washer Bolt (M6 x 40mm) Attach Seat (D) to Left Side (B) with Washer (E) and Bolt (F) as shown. Note: Do not fully tighten any bolts until assembly is complete. Failure to follow these instructions may cause the bolt holes to be misaligned during assembly.
Page 6
ARMCHAIR ASSEMBLY - STEP 3 Washer Bolt (M6 x 40mm) Attach Seat (D) to Back (C) with Washer (E) and Bolt (F) as shown. Note: Do not fully tighten any bolts until assembly is complete. Failure to follow these instructions may cause the bolt holes to be misaligned during assembly.
Page 7
ARMCHAIR ASSEMBLY - STEP 4 Washer Bolt (M6 x 40mm) Attach Right Side (A) to Back (C) and Seat (D) with Washer (E) and Bolt (F) as shown. IMPORTANT: Fully tighten all bolts after this step is complete.
Page 8
L CORNER PARTS Washer Bolt (M6 x 40mm) x 12 x 12 B ..Left Side....x 1 G ..Back ......x 1 H..Seat ......x 1 I ..Side Panel ....x 1...
Page 9
L CORNER ASSEMBLY - STEP 1 Washer Bolt (M6 x 40mm) Attach Left Side (B) to Back (G) with Washer (E) and Bolt (F) as shown. Note: Do not fully tighten any bolts until assembly is complete. Failure to follow these instructions may cause the bolt holes to be misaligned during assembly.
Page 10
L CORNER ASSEMBLY - STEP 2 Washer Bolt (M6 x 40mm) Attach Seat (H) to Left Side (B) with Washer (E) and Bolt (F) as shown. Note: Do not fully tighten any bolts until assembly is complete. Failure to follow these instructions may cause the bolt holes to be misaligned during assembly.
Page 11
L CORNER ASSEMBLY - STEP 3 Washer Bolt (M6 x 40mm) Attach Seat (H) to Back (G) with Washer (E) and Bolt (F) as shown. Note: Do not fully tighten any bolts until assembly is complete. Failure to follow these instructions may cause the bolt holes to be misaligned during assembly.
Page 12
L CORNER ASSEMBLY - STEP 4 Washer Bolt (M6 x 40mm) Attach Side Panel (I) to Seat (H) and Back (G) with Washer (E) and Bolt (F) as shown. IMPORTANT: Fully tighten all bolts after this step is complete.
Page 13
R CORNER PARTS Washer Bolt (M6 x 40mm) x 12 x 12 A ..Right Side ....x 1 J ..Back ......x 1 K ..Seat ......x 1 I ..Side Panel ....x 1...
Page 14
R CORNER ASSEMBLY - STEP 1 Washer Bolt (M6 x 40mm) Attach Right Side (A) to Back (J) with Washer (E) and Bolt (F) as shown. Note: Do not fully tighten any bolts until assembly is complete. Failure to follow these instructions may cause the bolt holes to be misaligned during assembly.
Page 15
R CORNER ASSEMBLY - STEP 2 Washer Bolt (M6 x 40mm) Attach Seat (K) to Right Side (A) with Washer (E) and Bolt (F) as shown. Note: Do not fully tighten any bolts until assembly is complete. Failure to follow these instructions may cause the bolt holes to be misaligned during assembly.
Page 16
R CORNER ASSEMBLY - STEP 3 Washer Bolt (M6 x 40mm) Attach Seat (K) to Back (J) with Washer (E) and Bolt (F) as shown. Note: Do not fully tighten any bolts until assembly is complete. Failure to follow these instructions may cause the bolt holes to be misaligned during assembly.
Page 17
R CORNER ASSEMBLY - STEP 4 Washer Bolt (M6 x 40mm) Attach Side Panel (I) to Seat (K) and Back (J) with Washer (E) and Bolt (F) as shown. IMPORTANT: Fully tighten all bolts after this step is complete.
Page 18
CHAIR PARTS Washer Bolt (M6 x 40mm) x 10 x 10 L ..Back ......x 1 M ..Seat ......x 1 I ..Side Panel ....x 2...
Page 19
CHAIR ASSEMBLY - STEP 1 Washer Bolt (M6 x 40mm) Attach Seat (M) to Back (L) with Washer (E) and Bolt (F) as shown. Note: Do not fully tighten any bolts until assembly is complete. Failure to follow these instructions may cause the bolt holes to be misaligned during assembly.
Page 20
CHAIR ASSEMBLY - STEP 2 Washer Bolt (M6 x 40mm) Attach Side Panels (I) to Seat (M) and Back (L) with Washer (E) and Bolt (F) as shown. IMPORTANT: Fully tighten all bolts after this step is complete.
Page 21
TABLE PARTS Washer Bolt (M6 x 40mm) x 12 x 12 Table ..Frt/Bck Panel ..Side Panel ......P ..Glass Top ....x 1 Q ..Table Top Panel ..x 1...
Page 22
TABLE ASSEMBLY - STEP 1 Washer Bolt (M6 x 40mm) Attach Table Frt/Bck Panels (N) to Table Top Panel (Q) with Washer (E) and Bolt (F) as shown. Note: Do not fully tighten any bolts until assembly is complete. Failure to follow these instructions may cause the bolt holes to be misaligned during assembly.
Page 23
TABLE ASSEMBLY - STEP 2 Washer Bolt (M6 x 40mm) Attach Side Panels (O) to Table Frt/Bck Panels (N) with Washer (E) and Bolt (F) as shown. IMPORTANT: Fully tighten all bolts after this step is complete.
Page 24
TABLE ASSEMBLY - STEP 3 Carefully position Glass Top (P) into place as shown while making sure the suction cups adequately grasp the Glass Top (P) bottom surface.
Page 25
OTTOMAN PARTS Washer Bolt (M6 x 40mm) x 12 x 12 O ..Side Panel ......x 2 R..Ottoman Frt/Bck Panel ..x 2 S ..Ottoman Top Panel....x 1...
Page 26
OTTOMAN ASSEMBLY - STEP 1 Washer Bolt (M6 x 40mm) Attach Ottoman Frt/Bck Panels (R) to Ottoman Top Panel (S) with Washer (E) and Bolt (F) as shown. Note: Do not fully tighten any bolts until assembly is complete. Failure to follow these instructions may cause the bolt holes to be misaligned during assembly.
Page 27
OTTOMAN ASSEMBLY - STEP 2 Washer Bolt (M6 x 40mm) Attach Side Panels (O) to Ottoman Frt/Bck Panels (R) with Washer (E) and Bolt (F) as shown. IMPORTANT: Fully tighten all bolts after this step is complete.
Page 28
CONFIGURATIONS Your patio set includes connectors that allow you to customize the layout of your pieces. To use the connectors, simply place them over the adjoining frames as shown above.
