EPM 300(C) Installation Test Tool
User Manual Template for OEM Manufacturers/First Marketer
EnOcean GmbH
Phone +49.89.67 34 689-0
Kolpingring 18a
Fax
82041 Oberhaching
info@enocean.com
Germany
www.enocean.com
+49.89.67 34 689-50
Subject to modification
EPM 300(C) User Manual
October 1, 2010 10:15 AM
Page 1/11
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for EnOcean EPM 300
- Page 1 EPM 300(C) Installation Test Tool User Manual Template for OEM Manufacturers/First Marketer Subject to modification EnOcean GmbH Phone +49.89.67 34 689-0 Kolpingring 18a +49.89.67 34 689-50 EPM 300(C) User Manual 82041 Oberhaching info@enocean.com October 1, 2010 10:15 AM Germany www.enocean.com...
- Page 2 As far as patents or other rights of third parties are concerned, liability is only assumed for modules, not for the described applications, processes and circuits. EPM 300 and EPM 300C are designed and produced as OEM products. They will be brought to market by local OEM manufacturers. They are not considered to be finished end products in terms of documentation, packaging and WEEE (electronic waste regulation).
-
Page 3: Table Of Contents
USER MANUAL EPM 300(C) Content 1. Introduction 2. Technical Data 3. Overview 4. Getting Started 5. Approvals 6. Recommendations © 2010 EnOcean | www.enocean.com EPM 300(C) OEM User Manual | Page 3/11... -
Page 4: Introduction
EPM 300(C) 1. Introduction EPM 300(C) is a mobile tool for radio link range testing. It helps electrical installers to find the right position to mount products supporting EnOcean protocol. EPM 300(C) is available for original equipment manufacturers (OEM’s) using EnO- cean technology within there products. -
Page 5: Overview
EPM 300(C) 3. Overview EPM 300(C) can be switched on and off via finger touch on the left sensor button for more than 2 s. Operation modes will be changed via finger touch (1 s) on right sensor button. Current mode will be indicated by four indicator LEDs. The device can be switched off via on/off sensor button on the left side. -
Page 6: Getting Started
1. Open battery cover (backside) and insert two lithium or alkaline type AA/LR06 batteries. 2. Activate EPM 300(C) by pressing the on/off button. Battery low will be indicated by flashing mode LED. 3. Send EnOcean telegram by pushing a self-powered switch (e.g. PTM 200) or by pressing the learn button of a self-powered sensor. - Page 7 This could be from other This signal will disturb EnOcean telegrams. Signal Low without Valid indicates a medium level of background noise on the same carrier frequency. This “noise” can come from EnOcean sensor or system telegrams (no teach in) or other radio devices.
- Page 8 Position EPM 300(C) at desired actuator/receiver position. Go to required switch or sensor position and push the button. Go back to the EPM 300(C) and observe signal level held for 60s. Attention: This mode only provides reliable information if no other switch or learn tele- grams have been sent during the time period you needed to move from the switch to the EPM 300(C).
- Page 9 Use of secondary (rechargeable) batteries with 1.2 V cells (e.g. Ni-Cd / NiMH) is not recom- mended. If you don’t use your EPM 300(C) for a longer period, remove the batteries from the de- vice. This will increase the lifetime of both batteries and the product.
-
Page 10: Approvals
5. Approvals 5.1 CE and R&TTE conformity (European Union) EPM 300 (868Mhz) conforms to CE and to the R&TTE EU directive on radio equipment. The device conforms to the European and national requirements of electromagnetic compatibil- ity. The conformity has been proven and the according documentation has been deposited at EnOcean. -
Page 11: Recommendations
USER MANUAL EPM 300(C) 6. Recommendations EPM 300 and EPM 300C has an internal antenna. The described area should not be covered by metal or other shielding material. It is recommended to hold EPM 300(C) below this an- tenna area.
