DPI GEN IV BTL Series Quick Start Manual

MNUL0047-A001 REV-1
Copyright©2018
Step #1: – Connect the input cable to the Power Supply before applying power or
connecting to the golf cart.
•
Plug AC Power Cord into power supply (only goes in one way) and wrap Tie-Strap around the
Cord to secure it in place.
•
Your Power Supply-Charger is now ready for use!
Step #2: - Battery Charging
– To charge the Cart's battery always connect the cables in the following order:
– Plug the Charging Cable into your cart's receptacle first, before applying AC Power. Make
sure the Cable is inserted FULLY into the cart receptacle.
MNUL0047-A001 Rev 1
GEN IV BTL™ Series Power Supply
Club-Car-Type Golf Carts 48VDC/120VAC
Quick Start Guide Begin Here
Your new BTL™ Series Power Supply . . .
•
Provides the DC charging power for Club-Car-type carts
equipped with an On-Board Computer
•
Designed specifically to work with the OBC to precisely
charge and maintain the battery pack
•
American Made, circuit breaker protected, and UL listed
to ensure quality and safety!
Note:
The BTL™ series Power Supply/Charger
works ONLY with Electric Vehicles
equipped with an On-Board Computer
(OBC). Refer to your EV's owner's manual
or check with your dealer to determine if
your vehicle is equipped with an OBC.
