- Page 1 WOOD CHIPPER BE-WCGR4XXX OPERATIONS & PARTS MANUAL FOR MODELS: • BE-WCGR4R13 • BE-WCGR4R13E • BE-WCGR4H13 • BE-WCGR4H13E PURCHASE DATE MODEL NO. SERIAL NUMBER DEALER MANUAL CODE: 102.106B...
-
Page 2: Warning Symbol
WARNING SYMBOL WARNING: This is the warning symbol to get your high attention for the instruction notice, which should be followed to avoid the potential serious personal injury. Anyone to use this equipment should read all the instructions of this manual. Keep this instruction manual for future reference. Do not allow children to operate this wood chipper. - Page 3 INDEX Features Specifications 4 - 8 Safety & Labels Upacking the Container 9 - 10 Assembly Knife Removal and Replacement 11 - 12 Operation Transporting and Storage 13 - 14 Maintenance 15 - 16 Trouble Shooting 16 - 17 Parts Breakdown BE-WCGR4XXX USER MANUAL...
-
Page 4: Specifications
FEATURES Discharge chute Engine In-feed Bin Body SPECIFICATIONS ITEM NO. BE-WCGR4R13 BE-WCGR4R13E BE-WCGR4H13 BE-WCGR4H13E Engine Powerease Powerease Honda GX390 Honda GX390 420 cc / 15 HP 420 cc / 15 HP 389 cc / 13 HP 389 cc / 13 HP Rotor Blades Rotor Diameter 220 mm... -
Page 5: General Operating Safety
GENERAL OPERATING SAFETY 1. Read, understand, and follow all instructions in the manual and on the unit before starting 2. Locate the Chipper on a flat, level, sturdy surface capable of supporting the weight of the Chipper and any additional tools and equipment. 3. - Page 6 spark plug. Wait for 5 minutes for the machine to cool down. Inspect the unit for any signs of damage or foreign material in the chipping or shredding areas. Remove any solid material that may be preventing the unit from operating properly. •...
- Page 7 Gasoline Fires and Handling Fuel Safely Use extra care in handling gasoline and other fuels. They are flammable and vapors are explosive. 1. When storing extra fuel be sure that it is in an appropriate container and away from any fire hazards. 2.
-
Page 8: Unpacking The Container
UNPACKING THE CONTAINER Remove the wooden plate in the top. At least two people hold up the package and move it from the top. ASSEMBLY Install the Wheels(See Figure 1) 1. Put the wheel (A) onto the axle (B), Make sure the wheel disc flat side faces the machine. - Page 9 Install the Inserting piece (See Figure 3) 1. Insert the Inserting piece (B) into the slot of the safety switch box (A). 2. Fix the Inserting piece with the two M8x16 flange bolts (C) and two flange M8 nuts (D). Figure 3 Install the Discharge chute (See Figure 4) 1.
- Page 10 Install the Handwheel (See Figure 6) 1. Assemble the handwheel (C) by using the spring washer (D) and flat washer (E), the splash guard (A) can be adjusted at the desired direction, then tighten the handwheel. Figure 6 Install the Battery Cord (Electric start version only, see Figure 7) 1.
-
Page 11: General Operation
KNIFE REMOVAL AND REPLACEMENT This chipper shredder is equipped with two chipper knives mounted on the cutting disk. When the knives get dull or show visible nicks, the machine will lose its self- feeding action and the material has to be pushed in. - Page 12 Operation Location 1. Select an area with firm, level ground, covered by dirt or grass. 2. Do not operate on wet or slick surfaces, or near bystanders. 3. Locate and organize the materials to be processed so that you don’t have to walk in front of the inlet or discharge openings, and so you have adequate room to work safely.
-
Page 13: Transporting And Storage
TRANSPORTING AND STORAGE 1. Always observe safe refueling and fuel handling practices when refueling the unit after transportation or storage. 2. Never store the unit (with fuel) in an enclosed poorly ventilated structure. Fuel vapors can travel to an ignition source (such as a furnace, water heater, etc.) and cause an explosion. Fuel vapor is also toxic to humans and animals. -
Page 14: Troubleshooting Chart
Engine Maintenance Refer to the engine manual included in your package for information on engine maintenance. Your engine manual provides information and a maintenance schedule for performing the following tasks: 1. Always check oil level before starting engine. Refer to engine manual for capacity and type of oil to use. 2. - Page 15 WARNING 1. TO AVOID SERIOUS INJURY, PERFORM MAINTENANCE ON THE UNIT ONLY WHEN THE ENGINE IS STOPPED. 2. ALWAYS DISCONNECT THE SPARK PLUG WIRE AND FASTEN IT AWAY FROM THE PLUG BEFORE BEGINNING THE MAINTENANCE, TO PREVENT ACCIDENTAL STARTING OF THE ENGINE. PROBLEM(S) POSSIBLE CAUSE CORRECTIVE ACTION...
- Page 16 27、28 46、47 15、16、17 BE-WCGR4XXX USER MANUAL...
- Page 17 PARTS LISTS BE-WCGR4R13 / BE-WCGR4R13E / BE-WCGR4H13 / BE-WCGR4H13E NO. DESCRIPTION PART# NO. DESCRIPTION PART# Circlips 102.106B.100 Chipper drum 102.106B.129 Wheel 102.106B.101 Knife 102.106B.130 Flange nut M8 102.106B.102 Bolt M8x25 102.106B.131 Belt cover 102.106B.103 Side cover 102.106B.132 Bolt M8x16 102.106B.104 Bearing cover 102.106B.133 Key parallel pin...
- Page 18 B RA B E R EQ .CO M WGSALES@BRABEREQ.COM PHONE: 604-850-7770 FAX: 604-850-7774 TOLL FREE PHONE: 1-877-588-3311 TOLL FREE FAX: 1-800-665-7334 BE-WCGR4XXX USER MANUAL...
