OWNER'S MANUAL
SPECIFICATIONS
Maximum Capacity ...........................................700-Lbs.
Adjustable Hook Screw Length ..................................14"
Steel Cable Diameter ............................................... 1/8"
Support Bar Adjustment ............................34-1/2" - 61"
Weight ...........................................................25.24-Lbs.
ESB700A
ESB700A
700-LBS.
CAPACITY
ENGINE SUPPORT BAR
ASME PASE-2014
© 2019 Mac Tools
06/07/19
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for MAG TOOLS ESB700A
Summary of Contents for MAG TOOLS ESB700A
- Page 1 ESB700A 700-LBS. CAPACITY ENGINE SUPPORT BAR OWNER'S MANUAL SPECIFICATIONS Maximum Capacity ...........700-Lbs. ASME PASE-2014 Adjustable Hook Screw Length ........14" Steel Cable Diameter ..........1/8" Support Bar Adjustment ......34-1/2" - 61" Weight ............25.24-Lbs. © 2019 Mac Tools ESB700A 06/07/19...
-
Page 2: Warning Information
Failure to read this manual completely and thoroughly, failure to understand its OPERATING INSTRUCTIONS, SAFETY WARNINGS, MAINTENANCE INSTRUCTIONS and comply with them, and failure to comply with the METHODS TO AVOID HAZARDOUS SITUATIONS could cause accidents result- ing in serious or fatal personal injury and/or property damage. ESB700A 06/07/19... -
Page 3: Setup Instructions
ESB700A 700-LBS. CAPACITY ENGINE SUPPORT BAR SETUP INSTRUCTIONS WARNING Failure to follow these Setup Instructions may result in serious injury or death, and/or property damage. PLEASE REFER TO THE EXPLODED VIEW DRAWING IN THIS MANUAL IN ORDER TO IDENTIFY PARTS. -
Page 4: Preventive Maintenance
ESB700A 700-LBS. CAPACITY ENGINE SUPPORT BAR PREVENTIVE MAINTENANCE WARNING Failure to follow these Preventive Maintenance instructions may result in serious injury or death, and/or property damage. 1. Always store the this device in a well protected area where it will not be exposed to inclement weather, corrosive vapors, abrasive dust, or any other harmful elements. -
Page 5: Parts Diagram And List
ESB700A 700-LBS. CAPACITY ENGINE SUPPORT BAR PARTS DIAGRAM AND LIST Index No. Part No. Description Qty. Index No. Part No. Description Qty. Hex Bolt M10 x 55 Support Beam (Large) Transfer Bar Support Beam (Small) Transfer Adapter "J" Hooks Wing Nut M12 RS520712A 1/8"... -
Page 6: Limited Warranty
ESB700A 700-LBS. CAPACITY ENGINE SUPPORT BAR LIMITED WARRANTY MAC TOOLS WARRANTS TO ITS CUSTOMERS THAT THE COMPANY’S MAC TOOLS BRANDED PRODUCTS ARE FREE FROM DEFECTS IN WORKMANSHIP AND MATERIALS. Mac Tools will repair or replace its Mac Tools branded products which fail to give satisfactory service due to defective workmanship or materials, based upon the terms and conditions of the following described warranty plans attributed to that specific product. -
Page 7: Especificaciones
ESB700A BARRA DE SOPORTE PARA MOTOR 700-LIBRAS CAPACIDAD MANUAL DE OPERATIÓN ESPECIFICACIONES Maxima capacidad ........700-Libras ASME PASE-2014 Longitud del tornillo de gancho ajustable ....14" Diámetro del cable de acero ........1/8" Ajuste de la barra de soporte ....34-1/2" - 61"... -
Page 8: Información De Advertencia
Hacer caso omiso, al no leer este manual detenidamente y de forma completa, y no comprender sus INSTRUCCIONES DE OPEARACIÓN, ADVERTENCIAS DE SEGURIDAD, INSTRUCCIONES DE MANTENIMIENTO y cumplir con ellas, y desatender los MÉTODOS PARA EVITAR LAS SITUACIONES PELIGROSAS podría ocasionar accidentes, resultando en lesiones personales serias o fatales y/o daños a la propiedad. ESB700A 06/07/19... -
Page 9: Instrucciones De Montaje
ESB700A BARRA DE SOPORTE PARA MOTOR 700-LIBRAS CAPACIDAD INSTRUCCIONES DE MONTAJE Hacer caso omiso a estas Instrucciones de montaje podría ocasionar lesiones serias o aun la muerte, ADVERTENCIA y/o daños a la propiedad. 1. Consulte la ilustración de vista ampliada en la página 5, con el fin de identificar los componentes de la barra de suporte para motor. -
Page 10: Garantía Limitada
ESB700A BARRA DE SOPORTE PARA MOTOR 700-LIBRAS CAPACIDAD INSTRUCCIONES DE OPERACIÓN (continuado) NOTA: Use sólo sujetadores de grado 5 ó mayores como pernos de soporte del motor. 4. Apriete las tuercas hexagonales de barril (#7) en ambos ganchos tipo J, hasta que los cables estén bien ajustados o las tuercas hexagonales estén apreta das contra la barra de soporte. -
Page 11: Spécifications
ESB700A BARRE DE SUPPORT DE MOTEUR 700-LIVRES D’UNE CAPACITÉ DE MANUEL D'OPERATIÓN SPÉCIFICATIONS Capacité maximale ........700-Livres ASME PASE-2014 Longueur réglable de vis de crochet ...... 14 po Diamètre du câble d'acier ........1/8 po Ajustement de la barre de support ..34-1/2 po - 61 po Poids ............ - Page 12 AVERTISSEMENT L'inobservance des CONSIGNES D'UTILISATION, des MISES EN GARDE, des CONSIGNES D'ENTRETIEN ainsi que des MÉTHODES POUR ÉVITER LES SITUATIONS DANGEREUSES peut causer des accidents ayant pour conséquences des dommages matériels ou des blessures corporelles graves ou mortelles. ESB700A 06/07/19...
-
Page 13: Consignes D'installation
ESB700A BARRE DE SUPPORT DE MOTEUR 700-LIVRES D’UNE CAPACITÉ DE CONSIGNES D’INSTALLATION Le non-respect de ces consignes d’Installation pourrait entraîner des blessures corporelles graves ou AVERTISSEMENT la mort, et/ou des dommages matériels. 1. Rapportez-vous à la vue explosée du dessin à la page 5 pour identifier les composantes de la barre de support de moteur. -
Page 14: Entretien Préventif
ESB700A BARRE DE SUPPORT DE MOTEUR 700-LIVRES D’UNE CAPACITÉ DE ENTRETIEN PRÉVENTIF Le non-respect de ces consignes d’Entretien Préventif pourrait entraîner des blessures corporelles graves ou la mort, AVERTISSEMENT et/ou des dommages matériels. 1. Entreposez toujours le dispositif dans un endroit bien protégé où ils ne seront pas exposés au mauvais temps, aux vapeurs corrosives, à la poussière abrasive, ou à...
