Summary of Contents for HYVST SR100
- Page 1 PRESSURE ROLLER INSTRUCTION MANUAL SR100 SR200 Note: This manual contains important warnings and instructions, Please read and retain for reference...
-
Page 2: Safety Precautions
Safety Precautions This manual contains information that must be read and understood before using the equipment. When you come to an area that has one of the following symbols, pay particular attention and make certain to heed the safeguard. WARNING This symbol indicates a potential hazard that may cause serious injury or loss of life. - Page 3 NOTE TO PHYSICIAN: Injection in the skin is a serious traumatic injury. It is important to treat the injury as soon as possible. DO NOT delay treatment to research toxicity. Toxicity is a concern with some exotic coatings injected directly into the blood stream. Consultation with a plastic surgeon or reconstructive hand surgeon may be advisable.
-
Page 4: General Description
HAZARD: HAZARDOUS VAPORS- Paints, solvents, insecticides, and other materials can be harmful if inhaled or come in contact with body. Vapors can cause severe nausea, fainting, or poisoning. PREVENTION • Use a respirator or mask if vapors can be inhaled. Read all instructions supplied with the mask to be sure it will provide the necessary protection. -
Page 5: Operation
Operation WARNING This equipment produces a fluid stream at extremely high pressure . Read and understand the warnings in the Safety Precautions section at the front of this manual as well as the airless sprayer and spray gun manuals before operating this equipment. Setup Perform the following procedure to prepare the spray system foe operation. - Page 6 3. Start up the airless sprayer. Follow the startup procedure and safety precautions outlined in the airless sprayer’s Owner’s Manual. 4. Adjust the fluid pressure on the sprayer until the spray is completely atomized. Always spray at the lowest pressure necessary to get the desired results.
- Page 7 NOTE: Never spray during the upward stroke. This will result in an uneven finish. NOTE: The use of a tip with a larger orifice is assembly. He large tip size will reduce the chance of clogs and can be supported by most pumps. The recommended fan width is a 14’’...
-
Page 8: Parts List
5. 9’’ roller tube assembly; 6. Plastic position holder; 7. Plastic baffle plate; 8. Extension pole assembly, Ф24, 90cm/Ф24, 180cm(optional); 9. HYVST Gun. SR200 1. End Sleeve; 2. 9’’ paint distributor; 3. End cap and seal assembly; 4. Roll cover;... - Page 9 With the exception of any special, extended, or limited warranty published by HYVST, HYVST will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by HYVST to be defective. This warranty applies only when the equipment is installed, operated and maintained in accordance with HYVST’s written recommendations.
- Page 10 All written and visual data contained in this document reflects the latest product information available at the time of publication. HYVST reserves the right to make changes at any time without notice. YONGKANG OCEAN IMP & EXP CO.,LTD. ADD: 23 F, Jinsong Mansion, Headquarter Center, Yongkang City, Zhejiang Province, China.
