Summary of Contents for SIREM Swimeo A2
- Page 1 Instructions SWIMEO S1-A2 NT-5222-1-01 ind.:00 12/01/2022...
-
Page 2: Table Of Contents
CONTENTS Safety instructions ................................2 1.1. Safety instructions – installation..........................2 1.1.1. Electrical risk ..............................2 1.1.2. Mechanical risk ............................... 2 1.2. Safety instructions – use ............................2 Technical description of the product ..........................3 2.1. Product references: ..............................3 2.2. -
Page 3: Safety Instructions
The final installation’s compliance is the responsibility of the installer. SIREM cannot be held liable for the direct or indirect consequences of incorrect installation of the SWIMEO S1 and A2 product. -
Page 4: Technical Description Of The Product
2. Technical description of the product 2.1. Product references: 3/20 03/11/2021 Ind. 00 NT-5222-1-01... - Page 5 In case of missing or broken elements, contact your dealer The applicable warranty conditions are those specified by your seller. The manufacturer Sirem guarantees the product for 2 years in the context of the strict application of its general terms and conditions of sale, which are available on the https://www.sirem.fr/...
- Page 6 Basic diagram: 5/20 03/11/2021 Ind. 00 NT-5222-1-01...
-
Page 7: Technical Characteristics
2.2. Technical characteristics Swimeo A2 Swimeo S1 Unit Weight Box 05-0812901 Mechanical Weight Dimensions (HxWxD) 565 x 275 x 170 Waterproofing IP20 Mounting 6 M6 screws Waterproofing IP20 Electrical Power supply voltage 230 +/- 10% Power supply frequency Current consumption... -
Page 8: Installing The Turbine In The Pool
3. Installing the turbine in the pool: Before installing, refer to the safety instructions in 1.1 Remove all film wrap and packaging before installing your turbine in the pool. 3.1. Step 1 Mounting beneath the edging tiles The 14-0843001 plate is mounted on top of the concrete wall, with no need to go through the wall of the pool Wall fixings are not supplied in the kit. -
Page 9: Step 1A Wall Mounting The Swimeosb01 Above The Water Line (Optional)
3.2. Step 1a Wall mounting the SWIMEOSB01 above the water line (optional) Wall fixings are not supplied in the kit. The liner must be pierced above the water line and preferably using A4 / 316L stainless steel fittings. The Swimeo is then fitted and mounted to at least two of the 4 studs, positioning it in relation to the water level. 4 x A4 stainless steel M8 dowels with crimped ends 8/20... -
Page 10: Step 2 Routing The Turbine Cable
3.3. Step 2 Routing the turbine cable: The cable routing solution chosen depends on your installation (type of swimming pool, water level, surrounding layout, etc.) and must be defined by a swimming pool specialist. After mounting the support (see paragraphs 3.1 and 3.2), lower the turbine into the pool using the castors to avoid scraping the pool wall and then route the cable through the defined location. -
Page 11: Step 3 Adjusting The Height Of The Turbine
3.4. Step 3 Adjusting the height of the turbine: A (mm) B (mm) C (mm) D (mm) Distance from top of Adjustment Min. wall Recommended wall to water height height flow depth line 1057 1077 1097 1117 1137 1157 1177 1197 1217 1237... -
Page 12: Step 4 Final Installation In The Pool
3.5. Step 4 Final installation in the pool: Secure with the 2 nuts then (SWIMEOS101 only) clip the plastic screw cover into the notches in the stainless steel frame 11/20 03/11/2021 Ind. 00 NT-5222-1-01... -
Page 13: Installation And Connection Of The Electrical Box
4. Installation and connection of the electrical box Before installing, refer to the safety instructions in 1.1 In order to ensure that the box operates correctly, the physical integrity of the box must be preserved. Existing cable glands must be used. 4.1. -
Page 14: Connection To The Mains
4.4. Connection to the mains Installation and commissioning must only be carried out by qualified and specialised electricians. They must comply with all the standards in force for the electrical installation. The connection to the mains is made on terminal block (4) and must comply with the colour code. The box will be connected to a 30mA residual current device. -
Page 15: Connecting The Remote Control Unit Terminal Block
4.8. Connecting the remote control unit terminal block An optional SWIMEORK01 remote control kit is supplied with the Swimeo kit. Its specific instructions must be followed when installing and programming it. In order to have the best possible signal, the receiver unit must be placed in the immediate vicinity of the swimming pool (max. - Page 16 It must be placed within range of the pool and connected to the box via the connector (9). Check that the Bluetooth signal can be received from the pool. The antenna must be placed outside the equipment room pointing towards the pool: Equipment room Range 15m...
-
Page 17: Use
5. Use Once the turbine and the box have been installed and the wiring is complete, the power is switched on via the switch (2). The turbine is then ready for use. Before installation refer to the safety instructions in 1.2 Controlling the turbine 5.1. -
Page 18: Environment
7. Environment 7.1. Water characteristics SWIMEO should be used in water with the following characteristics: Water characteristics Value Between 6.9 and 7.7 Between 0.4 mg/l and 1.4 mg/l (non-stabilised chlorine) Concentration of active free chlorine* Between 2 mg/l and 4 mg/l (stabilised chlorine) Total chlorine concentration* 0.6 mg/l greater than the free chlorine content Bromine concentration*... -
Page 19: Removing The Turbine
8.3. Removing the turbine If the above conditions cannot be met, the turbine must be removed from the pool. The installation in the pool must take this into account. Before winterizing: Switch off the power supply at the electrical box Remove the turbine (unplug from the connector box, see 4.6) Rinse the turbine in clear water Store the turbine in a dry, dark place. -
Page 20: Ec - Declaration Of Conformity
EC – Declaration of conformity SIREM Located at, 3 Chemin du Pilon CS 40303 01700 - Saint-Maurice-de-Beynost FRANCE Declare as the product manufacturer, and in our sole responsibility, that the following product, SWIMEO Part Number, SWIMEOXXXX Is in conformity with the requirements of the following regulations... -
Page 21: Declaration Of Conformity
UK – Declaration of conformity SIREM Located at, 3 Chemin du Pilon CS 40303 01700 - Saint-Maurice-de-Beynost FRANCE Declare as the product manufacturer, and in our sole responsibility, that the following product, SWIMEO Part Number, SWIMEOXXXX Is in conformity with the requirement of the following regulations...
