QUATROS QS19122 Owner's Manual

OWNER'SMANUAL
HYDRAULIC TROLLEY JACK 2T
QS19122

DESCRIPTION

Hydraulic Trolley Jack 2T QS19122:

SAFETY INSTRUCTIONS

WARNING
- This jack is a lifting device, designed ONLY for lifting part of the total vehicle (i.e one wheel). Do not move or dolly the
vehicle while itis on the jack. Never use lift device to raise any others load.
- Position this jack to ONLY lift on the areas of the vehicle as specified by the vehicle manufacturer.
- After lifting the vehicle, ALWAYS support the load with appropriately rated vehicle support stands BEFORE working on the
vehicle.
- Do not overload this jack beyond its rated capacity. Overloading can cause damage to or failure of the jack.
- This jack is designed ONLY for use on hard level surfaces capable of sustaining the load. Use on other than hard level
surfaces can result in jack instability and possible loss of load.
- Center load on jack saddle BEFORE lifting vehicle. Off-center loads and loads lifted when the jack is not level can cause loss
of load or damage to the jack.
- Study, understand and follow all instructions in this manual BEFORE operating the jack.
- Failure to heed this warning may result in loss of load, damage to the jack and/or jack failure resulting in personal injury or
property damage.

OPERATION

WARNING! Ensure that you read, understand and apply the safety instructions.
OPERATING INSTRUCTIONS
1. Assemble handle front section to larger section using pin provided.
2. When this jack leaves the factory for shipment. The vent plug on top of the oil chamber is closed to prevent the oil from
being spilled. Also, the oil chamber contains the right amount of oil before shipment. Before using for the first time,
remove cover plate, unscrew vent plug until there is 1/16" gap. If oil spill is evident. Or if vent plug was found open it is
necessary to check oil level before pumping.
3. With release valve open, pump handle about 6 full strokes to assure complete distributor of oil.
4. Close release valve and jack is ready to use.
5. Always center the load on a saddle of jack. Off-center loads and loads lifted while jack is not sitting level may damage the
jack.

BEFORE USE

During shipment or handling air in jack can become trapped in the hydraulic system causing jack to malfunction. To release air from
the hydraulic system:
1. Turn release valve counter-clockwise with handle no more than two full turns.
2. Remove oil fill plug.
3. Pump jack handle quickly in several full strokes.
4. Repeat above steps as needed. Remember to replace oil fill plug.
IMPORTER
Capacity: 2T | Min. height: 125mm
:
PW TECHSAM Woch Sp. J.
ul. Warszawska 131
20-824 Lublin
www.quatros.eu
a
a
| Max. height: 300mm | Weight: 6,5kg
tel. 81 444-63-73
tel. 81 443-08-12
fax 81 458-38-19
e-mail: techsam@quatros.pl
