- Page 1 LVDS to RGB Signal Converter for QVI Installation Guide...
- Page 2 •NAVI5CH-TO RGB Product Components NAVI5CH-TORGB-V2.0SET COMPONENTS QCPASS1351 : TEST : NAVI5CH-TORGB-V2.0 HPOWER0227 : NAVI5CH TO RGB POWER CABLE HRGBCA0024 : RGB UART CABLE TOTAL...
- Page 3 •NAVI5CH-TO RGB power cable pin map...
- Page 4 •NAVI5CH-TO RGB RGB UART cable pin map...
- Page 5 •Installation Diagram with QROIX...
- Page 6 •Installation Diagram with Carplay box RGB Cable tagged HRGCA0024 Power (Acc, GND)
- Page 7 •Installation Diagram with Carplay box Supplied 4Pin Touch between PCM3.1 interface and Carplay HTOUCH0049 Carplay 4Pin Touch port RGB Cable tagged HRGCA0024 LVDS TO RGB Sub board...
- Page 8 •Installation Diagram with Carplay box 4Pin Touch between CDR31 and Carplay Carplay 4Pin Touch port UART Connection RGB Cable tagged HRGCA0024...
- Page 9 •In case uart_tx wire in interface power connector Please wire it with another Please remove the yellow ② ③ Please find the Pin No.4 ① one. *Please make sure that pin from RGB cable tagged tagged PB12 of Power cable on the opposite side of the wire HRGCA0024 the interface.
- Page 10 •In case uart_tx wire in interface rgb-in connector Please make sure that the yellow pin of No.7 should be placed to the last on RGB cable. (This wire is for Uart touch. If it is wrongly placed, touch will not work.)
- Page 11 •In case uart_tx wire in interface ts_out connector ① ② ③ Please find Uart wire on the ① board above. And pin map is as below. No use ① ② ③ Please use TX wire for use of Please wire it with ②...
- Page 12 •In case uart_tx wire in interface debug_test connector Please find the Pin No.2 on ① the rest port and please connect one wire as same as above picture. Please remove the ② yellow pin No.6 from RGB cable tagged HRGCA0024 Please insert the wire from ③...
