- Page 1 Optical Fiber Camera System Center Communication Unit E-1040P Camera Adaptor Power Supply Unit E-2010P E-4020A/S User Manual Ver: V1.0.0V01 Please read this User Manual throughout before using.
- Page 2 All internal technologies of this product are protected, including device, software and trademark. ． Reproduction in whole or in part without written permission is prohibited. All brands and trademarks of SWIT Electronics Co., Ltd. are protected and other relative trademarks ． in this user manual are the property of their respective owners.
- Page 3 1. System Connection Note: (1) Only CCU, Camera Adapter and Power Supply Unit are included in this user manual. (2) LEMO (3K.93C) or NEUTRIK (NO2-4FDW-A) cable socket is optional and NEUTRIK cable socket is compatible with Pure fiber cable connection.
- Page 4 2. Center Communication Unit Features 19” 1U includes 4 camera channels ◆ ◆ Allow cascading for more channels Offer Lemo or Neutrik input for option ◆ SONY/Panasonic Camera Remote input ◆ ◆ TALLY and return SDI input Build-in Intercom control panel ◆...
- Page 5 ⑽ Number Key 1-4: Channel select button Press the button, the indicator turns yellow, the communication between CCU and Camera Adaptor is established. Support multiple camera channels simultaneous operation. ⑾ Speaker Rear View ⑴ ⑶ ⑷ ⑹ ⑼ ⑿ ⒂ ⑵...
- Page 6 3. Camera Optical Fiber Adaptor Features ◆ Convert Camera SDI and control signal to Optical and interconnect with CCU Lemo / Neutrik connection optional ◆ ◆ Camera SDI input and loop output Switcher Return SDI output ◆ ◆ Return SDI on/off control TALLY display and output to monitor ◆...
- Page 7 RETURN BUTTON: External Return SDI on/off button connection (4-pin) ⒂ When work with SWIT S-1071F(EFP) monitor, you can switch on/off the return SDI window on the monitor by pressing the provided external Return SDI on/off button . * Remote Control Protocol Setting: The Camera Adaptor supports SONY, Panasonic and JVC camera remote protocol.
- Page 8 4. Power Supply Unit Features 19” 1U standard rack mount ◆ ◆ AC 100-240V or DC 120-370V input Main and Back Up power input ◆ DC 48V 9A power output to CCU ◆ ◆ Build-in multiple power protection ⑴ ⑵ ⑶...
- Page 9 5. Specifications The Center Communication Unit (CCU) ⑴ Model E-1040P Main power Backup power Working Voltage ～ 4 8V 7~17V Max. Power Consumption 13.0W Working Temperature 0°C ～ + 40°C Working Humidity Working ～ 9 0%RH Environment Storage Temperature -20°C + 55°C...
- Page 10 6. Trouble-Shooting Problems Trouble shooting 1. Check if CCU is powered up and the power indicator goes on CCU Intercom channel buttons 2. Check if it is in Volume Setup mode, when SET indicator is blinking could not light up 3.
- Page 11 7. Packing List The 4-ch Package includes the following items in package: Description Quantity E-1040P 4-channel CCU Main Device (LEMO/NEUTRIK optional) Headset Gooseneck microphone 10-pin to 8-pin(SONY) RCU cable (1.5m) or Accessories 10-pin to 10-pin (Panasonic) RCU cable (1.5m) Intercom cascading cable...
- Page 12 Product Registration Link...
