OPERATION MANUAL
SINGLE BELT ROUND ROD SANDER
WINTER FS-80B
WARNING!
The operator must thoroughly read this manual before operation.
Keep this manual for future reference.
Henrik Winter Holztechnik GmbH
Druckereistr. 8
04159 Leipzig
Tel: +49 (0)341/ 4619021 Fax: +49 (0)341/4618358 Funk: +49 (0)171/2820443
Em@il: info@winter-holztechnik.de Internet: www.winter-holztechnik.de
Advertisement
Related Manuals for H. Winter WINTER FS-80B
Summary of Contents for H. Winter WINTER FS-80B
- Page 1 OPERATION MANUAL SINGLE BELT ROUND ROD SANDER WINTER FS-80B WARNING! The operator must thoroughly read this manual before operation. Keep this manual for future reference. Henrik Winter Holztechnik GmbH Druckereistr. 8 04159 Leipzig Tel: +49 (0)341/ 4619021 Fax: +49 (0)341/4618358 Funk: +49 (0)171/2820443...
-
Page 2: Specifications
HIGH-SPEED ROUNDED WOOD ROD POLISHING MACHINE FS-80B is a precise SINGLE BELT ROUND ROD SANDER. We believe that if you operate it normally and make a good maintenance on time，the machine will stay in a perfect condition. Before operating the machine，please read the instruction carefully. -
Page 3: Operation Steps
OPERATION STEPS： 1、 Put machine in a steady position， and then check whether the power is suitable to motor voltage. Turn on the electricity supply and examine whether the revolution of main shaft follows the arrows. If not， turn off the power and switch the two wire lines. - Page 4 Fig 2 5、 The adjustment of proceeding speed of sand belt： If you put the pressing wheel right at the center, the speed will turn slow. On the contrast, the sander the wheel is, the faster the speed occurs. Adjust the screw according to what you what you need.
- Page 5 Fig 4 MAINTENANECE: 1、 Fill in grease to the oil intake before operation every day. 2、 Add the grease to the moving shaft. During the operation, neither let other things except the materials needed stay between the working table and sand belt nor use anything sharp for finding.
- Page 6 ROD MILLING MACHINE PART Unit PART NAME QUANTITY Body Motor Spring washer Hexagon Screw Kery Sand Belt Drum Spring washer Pulley Spring washer Sub Worktable Spring washer Hexagon Screw Hanging Brocket Spring washer Hexagon Screw Round head Screw Hanging Hexagon Screw Spring Seat Idel Seat Shaft of Seat...
- Page 7 ROD MILLING MACHINE PART Unit PART NAME QUANTITY Movable handle Hexagon Screw Spring washer Protection Uses Cover Bracket Setting Rule Brocking Hexagon Screw Workpiece Size Adjusting Handle Grease Nipple Setting Rule Ball Bearing Rubber Wheel Guard Bracket Drive Wheel Rubber Wheel Guard Snap Ring Ball Bearing Rubber Wheel...
- Page 8 ROD MILLING MACHINE PART Unit PART NAME QUANTITY Movable Handle Spring Handle Handle Spring Seat Protection Uses Cover Bracket Protection Uses Cover Bracket Drive wheel shaft Ball Bearing Adjusting Disk of Spring Loose & Tight Pulley Hexagon Screw Pulley Hanging Hexagon Screw Spring Handle Spring Sleeve...
- Page 9 ROD MILLING MACHINE PART Unit PART NAME QUANTITY Crank Handle Crank Handle Spring pin Washer Back Drum Becket Ball Bearing Sand Belt Back Drum Shaft Sand Belt Back Drum Socket Head Screw Sub Worktable Washer Hexagon Screw Worktable Worktable Bracket Hanging Hanging...
