Huish Outdoors 330-0233 Service Manual

Isolator valve

Hide thumbs

330-0233 ISOLATOR VALVE SERVICE

1. Disassembly Of The Isolator Valve ............................................................... 2

2. Cleaning The Isolator Valve Components.................................................... 3

3. Assembly and Testing of the Isolator Valve ................................................ 3

Service Interval: 1 Year regardless of use

Tools and Items Required:

1. Adjustable Wrench

2. 5/32" Allen Wrench

3. Sonic Cleaner (blue gold)

4. O-ring Pick

5. LP hose assembly

6. Water Bucket/Tank

7. LP Air Source

8. Cristo Lube 111®

9. Torque Wrench

Parts Requied

1. Isolator Valve Assembly 330-0233

2. O-ring 160-0010-N7 (Parker Size 2-010 Nitrile 70 Shore)

3. O-ring 160-0011-N7 (Parker Size 2-011 Nitrile 70 Shore)

4. O-ring 160-0016-N7 (Parker Size 2-016 Nitrile 70 Shore)

Torque Specifications:

1. Isolator Valve Insert into Isolator Valve Body 10 in-lbs

2. Isolator Valve Assembly to Low Pressure Hose 24 in-lbs

3. Isolator Valve Assembly to Second Stage Regulator Inlet Tube 24 in-lbs.

Revision History

Revision

First Issue Rev 0

This document is valid on date printed only 6/27/2016

MANUAL

TABLE OF CONTENTS

Change

Approved by

Samer Khalil

APPROVAL AUTHORITY

QMS Lead

Last Revised: 06-26-16

Date

12-7-15

Page 1 of 6
