- Page 1 AURORA OPERATION AND INSTALLATION MANUAL FRANKFORD UMBRELLAS NORTH AMERICAN HEADQUARTERS 110 Gaither Drive Mount Laurel, New Jersey 08054 856-222-4134 Info@frankfordumbrellas.com frankfordumbrellas.com...
-
Page 2: Table Of Contents
BEFORE INSTALLING GRUB-SCREWS HARDWARE AND CORRESPONDING BASES GUIDELINES TO CONSIDER BEFORE INSTALLING ALIGNMENT AND SPIGOT INFORMATION GENERAL OPERATION INFORMATION & CARE GENERAL OPERATION INFORMATION SIMPLE MAINTENANCE PROCEDURES FABRIC CARE FABRIC CARE / LONGEVITY CASUAL / INTENSIVE FABRIC CARE & CLEANING UMBRELLA OPERATIONS OPENING AURORA CANTILEVER UMBRELLA CLOSING AURORA CANTILEVER UMBRELLA... -
Page 3: Before Installing
CORROSION RESISTANT AND WILL RUST IF EXPOSED TO THE ELEMENTS. Wind ratings do NOT form part of, nor fall under, any Frankford Umbrellas’ warranties. Wind ratings are intended as a guide to the relative strength of the umbrellas only and tested at their optimal 90° and non- tilted positions. -
Page 4: Hardware And Corresponding Bases
INSTALLATION OF ANY UMBRELLA. • IG (IN-GROUND MOUNTING) • ARU-480 ROLLING BASE GUIDE PINS SCAN THE QR-CODE FOR VIDEO TUTORIAL SCAN THE QR- CODE FOR THE VIDEO TUTORIAL ON HOW TO PROPERLY AND EFFICIENTLY STACK THE G-PLATES USING FRANKFORD GUIDE PINS. - Page 5 • Always secure your umbrella to a Frankford base that is appropriate to the environment in which it is • Should the 16 rotating mechanisms stop pin holes become filled with sand or dust etc., lifting your going to be used.
- Page 6 FABRIC CARE CASUAL CARE & CLEANING • Brush off dust and dirt with a soft brush. NEVER brush with stiff brushes since this can damage the fabric Recacril® Marine Grade Acrylic Fabric Infinity Process is a highly technological finish, providing Recacril with finish.
-
Page 7: Guidelines To Consider Before Installing
GUIDELINES TO CONSIDER BEFORE INSTALLING Your Aurora Cantilever Umbrella is delivered fully assembled. There are four different ways to install your Aurora Cantilever Umbrella: 1. Installing on a wooden deck using a Deck Plate. 2. Installing on an existing concrete slab or pavers using a Deck Plate. 3. -
Page 8: Opening Aurora Cantilever Umbrella
OPENING AURORA CANTILEVER UMBRELLA CLOSING AURORA CANTILEVER UMBRELLA Remove the protective cover by unzipping Loosen the Infinity Tilt Knob (27) and let the from the front. There will be two rods inserted Slider Car (26) free float. into the cover, use the rods to lift up and over towards the back (mast) of the umbrella. -
Page 9: Rotating The Aurora Cantilever Umbrella
ROTATING THE AURORA CANTILEVER UMBRELLA INSTALLING THE WIND STABILIZER KIT IMPORTANT: • NOTE: There are 16 rotational-locking holes in the spigot. These location holes are found at • The Wind Stabilizer Kit can ONLY be used every 22.5° intervals around the spigot plate while the umbrella is at it’s optimal 90°... -
Page 10: Aurora Parts Key
MAST WALL PULLEY AURORA PARTS KEY TOP HUB PULLEY MAST CAP MAST TOP BRACKET When the Aurora canopy is closed, the stainless steel cable pulley (30), are near the top of the most. When Aurora canopy is open, the pulley (30) are lower down the mast towards the mid point. -
Page 11: In-Ground
AURORA GRUB-SCREWS ARE IN PLACE TO PROTECT THE THREADED HOLES ON BASES Remember the depth of the hole is more important than width, and it is much easier to make the hole larger at the DURING SHIPPING AND STORAGE. THEY MUST BE REMOVED AND DISCARDED time of installation than to try and re-stabilize the in-ground mount should it start to move at a later date. - Page 12 AURORA GRUB-SCREWS ARE IN PLACE TO PROTECT THE THREADED HOLES ON BASES DURING SHIPPING AND STORAGE. THEY MUST BE REMOVED AND DISCARDED FIGURE 1 BEFORE THE INSTALLATION OF ANY UMBRELLA. DECK SURFACE INSTALLATION Your Aurora Cantilever comes with the Spigot already inserted in the mast of your umbrella. Once you have properly installed your Deck Plate, FIGURE 2-A remove the Spigot from your umbrella and you can begin to mount your Spigot to the Deck Plate, and then the umbrella.
- Page 13 IMPORTANT: You will need at least 3 1/2” of solid depth for a sufficient installation. Any shallower than 3” the integrity of AURORA GRUB-SCREWS ARE IN PLACE TO PROTECT THE THREADED HOLES ON BASES the install may be compromised causing catastrophic failure to your surface, the umbrella and surrounding property. Always DURING SHIPPING AND STORAGE.
-
Page 14: 40G+36G Round Galvanized Plate Stack
SCAN THE QR-CODE FOR VIDEO TUTORIAL AURORA FIGURE 1 40G+36G ROUND GALVANIZED PLATE STACK “NAKED” THREADLESS HOLES Your Aurora Cantilever comes with the Spigot already inserted in the mast of your umbrella. Once you have properly stacked your G-Plate, GRUB-SCREW (THREADED HOLES) remove the Spigot from your umbrella and you can begin to mount your Spigot to the plate stack, and then the umbrella. -
Page 15: 36Gx2 Square Galvanized Plate Stack
AURORA GRUB-SCREWS ARE IN PLACE TO PROTECT THE THREADED HOLES ON BASES DURING SHIPPING AND STORAGE. THEY MUST BE REMOVED AND DISCARDED BEFORE THE INSTALLATION OF ANY UMBRELLA. GRUB-SCREW (THREADED HOLES) FIGURE 1 - (BOTTOM PLATE / “THREADED HOLES”) 36Gx2 SQUARE GALVANIZED PLATE STACK Your Aurora Cantilever comes with the Spigot already inserted in the mast of your umbrella. -
Page 16: Aru-480 Rolling Base
AURORA GRUB-SCREWS ARE IN PLACE TO PROTECT THE THREADED HOLES ON BASES DURING SHIPPING AND STORAGE. THEY MUST BE REMOVED AND DISCARDED BEFORE THE INSTALLATION OF ANY UMBRELLA. ARU-480 ROLLING BASE Your Aurora comes with the Spigot (35) already inserted in the mast of your umbrella. Once you have properly leveled your base (If FIGURE 1 adjustable feet used) or have installed the caster wheels and have them in the locked position, you can begin to mount your Spigot (35) and then umbrella. - Page 17 AURORA CROSS BASE Your Aurora comes with the Spigot (35) already inserted in the mast of your umbrella. Once you have properly leveled your base (If adjustable feet used) or have installed the caster wheels and have them in the locked position, you can begin to mount your Spigot (35) and then umbrella.
- Page 18 AURORA CROSS BASE COVER (+C) The Aurora Cross Base Cover ships flat and is easy to assemble. It is specifically designed for the Cross Base with 8 pavers and seamlessly fits over the Cross Base creating a more aesthetically pleasing look. IMPORTANT: Avoid using a hammer or other hard materials when assembling.
- Page 19 Frankford warrants the frame structure for a period of 5 Frankford warrants the frame structure for a period of 3 years from the original date of purchase. This warranty years from the original date of purchase.
- Page 20 FRANKFORD UMBRELLAS NORTH AMERICAN HEADQUARTERS 110 Gaither Drive Mount Laurel, New Jersey 08054 856-222-4134 Info@frankfordumbrellas.com frankfordumbrellas.com...
