Power Supplies
SCS2ENMD48.3x30
Modular Version
Input 230 Vac
Output 48 Vdc
90 A
Sinercom S.r.l.
Headquarter: Via G. Cappalonga 9/A - 00043 Ciampino (RM) - Italy
tel. +39.06.79800323 fax +39.06.79814644
Factory: Via Cascina Secchi 247/4b - 24040 Isso (BG) - Italy
tel. +39.0363.938231 fax +39.0363.998235
USER MANUAL
Advertisement
Summary of Contents for sinercom SCS2ENMD48.3x30
- Page 1 Power Supplies SCS2ENMD48.3x30 Modular Version Input 230 Vac Output 48 Vdc 90 A Sinercom S.r.l. Headquarter: Via G. Cappalonga 9/A - 00043 Ciampino (RM) - Italy tel. +39.06.79800323 fax +39.06.79814644 Factory: Via Cascina Secchi 247/4b - 24040 Isso (BG) - Italy tel.
- Page 2 TABLE OF CONTENTS WARNINGS AND SAFETY REGULATIONS ………………………………………………….… DECLARATION OF COMFORMITY ……………………………………………………. IMPORTANT SAFETY ISTRUCTION ………………………………………………………. IDENTIFICATION OF DANGERS AND MEASURES FOR PREVENTION ………………. 1.3.1 Electricity Risks ……………………………………………………………….. 1.3.2 Fire Risks …………………………………………………………………….. 1.3.3 Mechanical Risks …………………………………………………………… INTRODUCTION …………………………………………………………………………………………. AN OVERALL VIEW ………………………………………………………………………………...
- Page 3 SAFETY REGULATIONS DECLARATION OF COMFORMITY This device has been produced in such a way as to guarantee a safe functioning provided that it is utilized for the purposes it was made for and that the regulations, instructions for use and installation provided by the manufacturer are followed.
- Page 4 2.0 INTRODUCTION SCS2ENMD48 is an apparatus suitable for food systems in DC-48VDC Universal Input, typically used in the field of telecommunication (e.g. telephone communication station). SCS2ENMD48 It can be configured by two to three rectifiers model ENR44830AL with hot swappable function. It’s guarantees supply continuity even in the case of an electrical black out, thanks to the batteries connected to the system.
- Page 5 TECHNICAL INFORMATION SCS2ENMD48 technical information : POWER SYSTEM CHARACTERISTICS SCS2MD48.3X30 System configuration Monofase - 3 module INPUT Rated input voltage range 230Vac +15% -20% (1F+N) Input voltage range 175 – 276Vac Input voltage frequency 47-63Hz (typical 50/60) Nominal input current 23 A Max input current 27 A...
- Page 6 SYSTEM 5.1 System configuration : Product composing Item Option Quantity Remarks Power system cabinet SCS2MD48 Must w/monitor display Rectifier module 30 A Must 1 or 2 or 3 Single rectifier max output is 1500W 5.2 Front and back view of the system: Front view (Figure1) Rear view (Figure2) Rear DC Output...
- Page 7 5.3 Synoptic panel A synoptic panel is located on the front of the energy station. This is used to visualize the various alarms, the state of functioning and the measurements. It provides immediate signals, either illuminated or acoustic, which illustrate the general condition of the machine and more detailed information, including various measurements, which the operator can consult by using the keyboard and the display.
- Page 8 6.0 FUNCTIONING Hardware information : The functioning of the energy station is based on an electronic converter which transforms the line voltage into a isolated stabilised voltage while all the total running of ENERGY is carried out by an electronic circuit which shows, through a display and control buttons, the functioning state of the system in real time.
- Page 9 7.2 Display menù Display Menù Primary menù Secondary menù Explanation SYSTEMS OK The energy station is operative. V:xx,x I:xx,x Iload Ibatt Information about current absorbed by Xx,xA xx,xA charge and batteries. M1 : Information general to single module M2 : rectifier.
- Page 10 8.0 INSTALLATION Packing Case SCS2ENMD48’s packing case contains: the energy station; battery and load fuses; this instruction manual. ATTENTION: The energy stations are very fragile electronic devices. Be very careful when unpacking and transporting. Preliminary Controls Before proceeding with the installation of SCS2ENMD48, check if the device has been damaged during delivery.
- Page 11 SWITCHING OFF Turn the line switch to the “0” position for all modules, the "POWER" green leds turn off. The “BATTERY MODE” red led will light up on the synoptic panel and the display will read: and the acoustic signal will activate; BATTERY MODE Enters to menu display by press and visualize this menu .
