Supplied Items
1 x RGB Uplighter Unit
•
Instruction Leaflet
•
Battery Charger
•
Mains Lead
•
Aerial
•
Introduction
The RGB battery uplighter with wireless DMX is a
stand alone light source.
controlled by DMX transmitted wirelessly and in stand alone operation using 50 preset
colours and 20 preset fade and snap sequences.
Features
• Full RGB with 16 bit dimming curve
• Wireless DMX Control
• Up to 24 hour runtime from fully charged battery (12 hours full white)
• 50 preset colours
• 20 preset colour chases
• Charging Cycle Approximately 8 hours
• Wireless Firmware Update
Conformity
The RGB Uplighter conforms to the following standards:
EN 61000-6-3
Light Industrial Emissions
EN 61000-4-2
Heavy Industrial Immunity
Further information can be obtained from
Manufactured in the UK by Global Design Solutions
RGB Battery Uplighter
The unit can be
technical@gds.uk.com
www.gds.uk.com info@gds.uk.com
with Wireless DMX
Advertisement
Table of Contents
Summary of Contents for GDS LiteWare
- Page 1 • Wireless Firmware Update Conformity The RGB Uplighter conforms to the following standards: EN 61000-6-3 Light Industrial Emissions EN 61000-4-2 Heavy Industrial Immunity Further information can be obtained from technical@gds.uk.com Manufactured in the UK by Global Design Solutions www.gds.uk.com info@gds.uk.com...
- Page 2 Normal Operation DMX mode To turn the unit ON or OFF, the Top Button needs to be held for 1.5 Seconds. The button LED will illuminate to show the unit is awake. In Stand Alone Mode To turn the unit ON or OFF, the button needs to be held for 1.5 Seconds. The button LED will illuminate to show the unit is awake.
- Page 3 Stand-Alone Mode (Address 600+) 601-650 FIXED COLOURS Detailed in table on page 4 651-655 COLOUR FADE SEQUENCE 1 A colour fade sequence with 5 different speeds of transition 656-660 COLOUR FADE SEQUENCE 2 A colour fade sequence with 5 different speeds of transition 661-665 COLOUR SNAP SEQUENCE 1 A colour snap sequence with 5 different speeds of transition 666-670 COLOUR SNAP SEQUENCE 2...
- Page 4 Fixed Colour Table ADDRESS COLOUR LEE Ref ROSCO Ref GREEN BLUE YELLOW CYAN MAGENTA ORANGE GOLD PINK VIOLET AQUA SKY BLUE FULL WHITE COOL WHITE WARM WHITE YELLOW LEE 101 STRAW LEE 103 ORANGE LEE 105 PRIMARY RED LEE 106 LIGHT ROSE LEE 107 DARK PINK...
