Summary of Contents for NPZ UM8-2
- Page 1 COMPACT HANDHELD MONOCULAR UM8-2 SERVICE MANUAL...
- Page 3 INTRODUCTION This Service Manual is intended for study of the design and maintenance rules of the niversal prism monocular UM8-2. The manual includes technical specifications and information on design and operation of the sight required for its correct use, storage, and servicing.
- Page 4 UM8-2 COMPACT HANDHELD MONOCULAR...
-
Page 5: Table Of Contents
CONTENT ..........1. GENERAL INSTRUCTIONS .............. 2. SPECIFICATIONS ..............3. COMPLETE SET ................. 4. STORAGE ..........5. ACCEPTANCE CERTIFICATE... -
Page 6: General Instructions
With an operating temperature range from +40 to -40 °C the UM8-2 can handle winter and summer with ease. A clear crisp image can be provided by a simple turn of the objective lens. -
Page 7: Specifications
2 SPECIFICATIONS Table1 parameter Value Magnification, x, Field of view 5° Resolution 13" Exit pupil, mm, Eye relief, mm Diopter adjustment, D 10 to -10 Overall dimensions, mm 100x45x45 Weight, kg 0,12 SpECIfICATIONS... -
Page 8: Complete Set
3 COMPLETE SET Table 2 Name Quantity Monocular UM8-2 Service manual COmpLETE SET... -
Page 9: Storage
Store the monocular inside with relative humidity not over 80% and air temperature from +40 to -40 °C. Impacts and strong vibrations can be harmful to the UM8-2. Avoid external damage to the body and optics. Reactive chemicals and moisture can damage the UM8-2. -
Page 10: Acceptance Certificate
5 ACCEPTANCE CERTIFICATE Universal prism monocular UM8-2 serial № ____________, is manufactured and accepted in accordance with the requirements of effective standards, effective technical documentation and found fit for operation. Date of issue ___________________ Signatures_____________________ JSC «Novosibirsk Instrument – making plant»... - Page 12 www.npzoptics.com...
