Summary of Contents for Eye Lighting Iwasaki Electric ESS0460-H119
- Page 1 F08-064 Operating Manual ESS0460-H119 PV Module Solar Soaking Chamber 12/19/2008...
-
Page 2: Table Of Contents
Thank you for your purchase. We are confident you will be completely satisfied with your new system. If for any reason you need assistance, please contact us: EYE Lighting International / Iwasaki Electric 9150 Hendricks Road Mentor, OH 44060 888-665-2677 support@eyeappliedoptics.com... -
Page 3: System Components
1. System Components: ① Solar Lighting Array Housing – (60) 400W solar lamp array ② Solar Lamp Power / Inverter Cabinet – includes (5) inverter units (12 modules per unit; one module per lamp) and solar lamp starters (60 units; one starter per lamp) ③... -
Page 4: Installation
2. Installation A. When installing this chamber, please avoid placing it in any area where corrosive gas or explosive gas is present. It is also highly recommended that the area be as dust free as possible with controlled humidity. B. The chamber should be placed as close to the mains power source (power transformer) and mains breaker as possible. -
Page 5: Control Panel
3. Control Panel ① ② ③ ④ ⑥ ⑧ ⑪ ⑦ ⑨ ⑤ ⑩ ① MAIN POWER INDICATOR LAMP Indicator lamp will illuminate when the Main Power Breaker is ON and power is supplied to the system ② IRRADIATION AREA ZONE SWITCHES The solar array is arranged in 5 zones of 12 lamps each. - Page 6 ⑤ TEST START SWITCH This button initiates the programmed test period. When initiated, this switch will be illuminated. At the conclusion of the programmed test time, the alarm buzzer will sound and the solar lamps will be turned off. The buzzer will turn off automatically after one (1) minute or you can turn the buzzer off manually by pressing the buzzer stop switch.
-
Page 7: System Operation
4. System Operation Full Chamber Manual Operation a) Ensure main power breaker is ON (Main Power Lamp will be illuminated). b) Turn cooling fans ON (solar array lamps will not function until fans are turned on). c) Turn on solar array by pressing LIGHTING AREA ZONE switches 1-5 sequentially. Allow ten (10) minutes for solar lamps to reach full power and spectrum stabilization. -
Page 8: Irradiation Intensity Control
6. Irradiation Intensity Control The system irradiation intensity was set to an average 1000W/m (+/-15%; class C uniformity) at the time of installation. This intensity distribution test is included in Section 3 of this manual. We recommend that the irradiation intensity is verified approximately every 500 hours of operation or once per month. -
Page 9: Troubleshooting
(power, lamps, fans, STOP position. etc.). Troubleshoot any specific failures that are identified. If no failure mode is identified by control circuits, please contact EYE Lighting technical support. Cooling Fan Thermal relay or abnormal current error Ensure there are no obstructions restricting rotation of fan blowers.
