Page 1 EB-X6 Skylark...
Page 2 Fully Assembled Skylark Black, Skylark Yellow, Skylark Red, Skylark White. Skylark Black Skylark Yellow Skylark Red Skylark White...
Page 3 Assembly Instructions: Skylark Tools included: Screwdriver, Phillips & Slotted 2 in 1 Double open-end wrench, 13mm/15mm Allen wrench, 5mm Allen wrench, 6mm Tools needed: Scissor Bike pump Let’ s start assembling your Skylark ebike! (Please read this entire assembly manual before assembly as it will save you a lot of time!) Step One:Unpack the ebike.
Page 4 2.Now stand the bike upright. Place some foam padding under the front fork if placed on the ground or put it on bike assembly/repair stand if you have one. We want to keep your bike looking new! Step Two:Unfolding the Fashion Frame. 1.Unfold the frame.
Page 5 (3).Fold the quick release lever upward to securely lock the frame hinge. The quick release lever should have enough resistance when closing to leave an imprint on your thumb. Notice: Test the bike fully after unfolding the frame and before riding. Step Three: Install the handlebar.
Page 6 (2).Turn the plastic clasp anticlockwise to unlock the quick release lever. (3).Unfold the quick release lever downward to open the stem.
Page 7 (4).Tighten the bolt in the center of the stem with the supplied allen wrench. (5).Close the quick release lever to secure the stem.
Page 8 (6).Turn the plastic clasp clockwise to secure the quick release lever. 2.Install the handlebar onto the stem. (1).Open the quick release lever by hinging it open fully.
Page 9 (2).Insert the handlebar stem into the stem tube. (3).Set the handlebar to the desired height but not exceed max height or minimum insertion.
Page 10 (4).Align the stem so the handlebar is perpendicular to the front wheel. (5).Close the quick release lever to secure the handlebar.
Page 11 3.Perform a twist test. (1).Brace the front wheel between your legs. (2).Switch hands so the opposite hands are pushing and pulling with about 20 pounds of force make sure the handlebar and front wheel are still properly aligned. (3).Repeat the twist test pulling/pushing with the opposite hands.
Page 12 Step Four: Center the headlight and adjust the angle slightly downwards to illuminate the road ahead and not blind oncoming traﬃc. Use the supplied Phillips-head screwdriver to loosen the headlight angle adjustment bolt, tilt the headlight to the optimal position, and then tighten in place securely.
Page 13 Step Five: Install the seat. 1.Open the quick release lever by hinging it open fully. 2.Insert seat post into seat tube. Adjust the seat post up or down to a comfortable height, while ensuring the seat post is inserted into the frame past the minimum insertion point.
Page 14 Step Six: Install the pedals. 1. Locate the pedal with an “R” stamped into the end of the pedal axle, which indicate it is the right pedal. The right pedal goes on the crank on the right side of the bike. The remaining pedal with an “L” stamped into the end of the axle, is the left pedal.
Page 15 2. The right pedals threaded to tighten by turning clockwise. The left pedals reverse-threaded and tightens counterclockwise. Carefully thread the pedal onto the crank by hand slowly. 3.Further tighten with the supplied double open-end wrench. Do not cross thread or damage the threads.
Page 16 Step Seven: Inﬂate the tires. Check that the tire beads and tires are evenly seated around the rims. Use a pump with a Schrader valve and pressure gauge to inﬂate each tire to the recommended pressure indicated on the tire sidewall. Do not overin- ﬂate or underinﬂate tires.
Page 17 Torque Required Hardware Loca�on Hardware (Nm) Brakes Caliper Adapter to Frame 8-10 Brakes Pad to Caliper Arm Brakes Brake Cable to Caliper Clamp All Fender Moun�ng Bolts Fenders and Hardware Headlight Angle Adjustment Headlight Bolt Seatpost Area Seat Angle Adjustment Bolt Rear Dropout Area Rear Axle Nuts Rear Dropout Area...
Page 18 Quick Start Guide This ebike is equipped with two ways for a rider to use power assistance from the motor to propel the bike forward: The pedal assist system (PAS) ⸺The rider can engage the pedal assist system (PAS) while pedaling, and it will call up assistance from the motor to help propel the bike forward.
Page 19 2.Sit on the bike. 3.Activate the pedal assistance system⸺Press the red button on the right side of the handlebar. 4.Turn on the headlight if needed or desired. Turn on the headlight by sliding the light button to right. Turn on the headlight by sliding the light button to left.
Page 20 5.Begin riding carefully⸺Hold handlebars and start pedaling on a ﬂat surface, in a low gear (1 or 2), most riders should be able to begin pedal- ing the bike with pedal assist. You may also use the throttle to accelerate and maintain your desired speed.
Page 21 Do not use the throttle while dismounted. Avoid accidental application of the throttle while dismounted; anytime you are moving the bike while dismounted, ensure the bike is powered oﬀ to prevent accidental applica- tion of the throttle. 7.Brake⸺Brake the bike by squeezing the brake lever (Notice: as a safety feature applying either front or rear brake will disengage the motor.) 8.Deactivate the pedal assistance system⸺Press the red button on...
Page 22 WARING We recommend that you always wear protective gear when cycling such as a helmet, gloves, elbow pads and goggles. When riding, obey the same road laws as all other road vehicles as appli- cable by law in your area. Best to charge the battery during the day when someone is around.
Page 23 Glare Technology USA Inc Phone: 951-521-1888 E-mail: info@glaretechusa.com Website: www.RideGlareWheel.com Adress:30898 Wealth St Murrieta,CA 92563...
