FOLKSAFE FS-HD2103E-KVM Manual

Model: FS-HD2103E-KVM

Features

HDMI & KVM Extender
•FS-HD2103E-KVM-TX/RX consists of a transmitter and a receiver, it's used in pairs
•Support HDMI signal up to 1080p@60Hz
•Transmit HDMI signal through Cat5e/6 or above cable, extend distance up to 100meters
•Support infrared transmission, realize remote control function
•Support USB2.0 Mouse, realize KVM remote control function
•UTP cable transmitting power are supported. When used in pairs, only need to power for TX side,
the RX side starts working automatically after connection
•Support PoE power supply, no need extra power at RX side
•Easy to operate, plug and play, no need to configure

Overview

The FS-HD2103E-KVM is a HDMI cable extender with the new generation of the extension technology. By using FS-HD2103E-KVM, the HDMI Signal and KVM controlling Signal can be
extended to 100 meters over Cat5e/6 or above. Consisting of FS-HD2103E-KVM-TX as transmitter and FS-HD2103E-KVM-RX as receiver are used in pairs. The FS-HD2103E-KVM
supports hot-plug and transmits the optimizing HDMI signal to the display device after matching with the relative display device automatically. Supporting
and USB2.0 Keyboard Mouse remote controlling function which can extend the distance by connecting the HDMI signal source. As the FS-HD2103E-KVM supports PoE power supply,
you do not need extra power at the RX side, which simplified the progress, saved the cost of the connection and solved the wrong-connection problem that may cause any abnormal
thing or waste in electricity, and surely improved the efficiency of the product. FS-HD2103E-KVM is widely used in the situations such as Home Theater, Exhibition, Multimedia
classrooms, Large Internet cafes, etc. It will lead a broad market demand and prospects in the public information field which has protection requirements for HDMI video source
devices.
infrared remote controlling
