EZ OS-5100RA Operation Manual

Analog readout oscilloscope
Hide thumbs
Table of Contents

Advertisement

Quick Links

Analog Readout Oscilloscope
Operation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OS-5100RA and is the answer not in the manual?

Questions and answers

Summary of Contents for EZ OS-5100RA

  • Page 1 Analog Readout Oscilloscope Operation Manual...
  • Page 2 Analog Readout Oscilloscope Operation Manual...

  • Page 3: Declaration Of Conformity

    DECLARATION OF CONFORMITY according to ISO/IEC Guide 22 and EN 45014 Manufacturer’s Name: EZ Digital Co., Ltd. Manufacturer’s Address: 222-28, Nae-dong, Ojeong-gu, Bucheon-si, Gyeonggi-do R. O. K, 421-160 Declares that the product: Product Name: OSCILLOSCOPE Model Numbers: OS-5100RA OS-5100RB Date: Feb.

  • Page 4: Warranty

    WARRANTY Warranty service covers a period of one year from the date of original purchase. In case of technical failure within a year, repair service will be provided by our service center or sales outlet free of charge. We charge customers for repairs after the one year warranty period has been expired. Provided that against any failure resulted from the user’s negligence, natural disaster or accident, we charge you for repairs regardless of the warranty period.
  • Page 5 3. This equipment should be used with a triple line power cord for safety. 4. For quality improvement the exterior design and specifications of the product can be changed without prior notice. 5. If you have further questions concerning use, please contact the EZ Digital service center or sales outlet.
  • Page 6 Safety Summary Safety Precautions Please take a moment to review these safety precautions. They are provided for your protection and to prevent damage to the oscilloscope. This safety information applies to all operator and service personnel. Caution and warning statements. CAUTION : Is used to indicate correct operating or maintenance procedures in order to prevent damage to destruction of the equipment or other property.
  • Page 7 SPEC MODEL OS-5100SRS * Environmental Charac. 1) Temperature range for +10℃ to +35℃ (+50℉ to +95℉) rated operation 2) Max. ambient operating 0℃ to +40℃ (+32℉ to +104℉) temperature -20℃ to +70℃ (-4℉ to + 158℉) Max. storage temperature 4) Humidity range for 45% to 85% RH rated operation 5) Max.
  • Page 8 1-3-2. Installation and Handling Precautions when placing the OS-5100RA(RB) in service at your workplace, observe the following precautions for best instrument performance and longest service life. Avoid placing this instrument in an extremely hot or cold place. Specifically, don? leave this instrument in a close car, exposed to sunlight in midsummer, or next to a space heater.
  • Page 9 Do not place heavy objects on the case, or block the ventilation holes. Do not use this oscilloscope in strong magnetic fields, such as near motors. Do not insert wires, tools, etc. through the ventilation holes. Do not leave a hot soldering iron near the instrument. 10.
  • Page 10 1-4. ACCESSORY The following accessaries are included in the packing of this product : 1. Operating manual : 1 copy 2. AC power cord : 1 EA 3. Probe : 2 EA (option) 4. Fuse : 2 EA 1-5. SYMBOL Caution : refer to accompanying documents.
  • Page 11 1-7. EMC This instrument conforms to the European standards regarding the electromagnetic compatibility. The applied standards are : Generic immunity standard EN50082-1, (for residential, commercial and light industry environment) Emission standard EN55011 (for ISM Equipment), EN61000-3-2, EN61000-3-3.

  • Page 12: Front Panel Function

    OPERATING INSTRUCTIONS 2-1. FRONT PANEL FUNCTION OS-5100RA OS-5100RB...

  • Page 13: Trace Rotation

    1. INTENSITY : Clockwise rotation increases sweep brightness. 2. TEXT INTENSITY : Clockwise rotation increases character brightness. 3. FOCUS : To obtain maximum trace sharpness. 4. SCALE ILLUMINATION : To adjust graticule illumination for photographing the CRT display. 5. TRACE ROTATION : Allows screwdriver adjustment of trace alignment with regard to the horizontal graticule lines of the CRT.

  • Page 14: Miscellaneous Features

    14. HORIZONTAL BLOCK a. POSITION : Moves the X-axis position of sweep. b. TIME/DIV : Changes the time of sweep from 50ns to 5s with 1- 2-5 step. c. X 10 MAG : Amplifies the X side of sweep 10 times. d.

  • Page 15: Trace Separation

    e. HOLD OFF : This key is adjusted for the stable synchronism of waveform. This is used at the position 0% usually. Allows triggering on certain complex signals by changing the holdoff time of the main A sweep. The avoids triggering on intermediate trigger points within the repetition cycle of the desired display.

  • Page 16: Rear Panel Function

    2-2. REAR PANEL FUNCTION REAR 1. AC INLET : Connection and removal can be easy with the using of AC power cord. 2. FUSE 3. CH1 OUTPUT : Amplifies some part of signal which was input to CH1, and provides it for frequency counter or the other equipments.

  • Page 17: Installation And Basic Operation

    2-3. INSTALLATION AND BASIC OPERATION 2-3-1. Character Display 1. Description of each position a. When cursor is displayed, ∆TA(TB), ∆V1 (V2, V3) are marked here. b. When cursor is displayed, ∆1/TA, and Auto Setup frequency are marked here. c. ‘MG’ is marked here on X 10 MAG. d.
  • Page 18 2-3-2. Initial Display 1. Setting at the power on a. VERT MODE b. HORI DISPLAY c. TRIGGER MODE AUTO d. TRIGGER SOURCE e. TRIGGER COUPLING f. TIME / DIV g. VOLTS / DIV h. CURSOR ∆V1 i. AC/DC/ GND j. HOLD OFF k.

  • Page 19: Probe Compensation

    2-3-3. Probe Adjustment When applying the external signal to measure using oscilloscope, use probe. The applied waveform is displayed on the CRT of oscilloscope. The product has two points : × 1 (direct connection) and × 10 (attenuation). At × 10 point, the input impedance of oscilloscope increases, which attenuates the input signal by 1/10.
  • Page 20 2-3-4. Vertical Mode 1. Menu Selection a. CH1 : When the first of select key is pressed, ▶ sign is displayed beside CH1 of screen and the content is displayed at the position of 3. only the signal which input to CH1 is displayed on CRT. b.
  • Page 21 f. QUAD : When the 6th of select key is pressed, ▶ sign is displayed beside QUAD of screen and the content is displayed at the position of 1, 2, 3, 4. All signal which are input to CH1, 2, 3, 4 are displayed on CRT (only for 5100RA).
  • Page 22 2-3-5. Channel Connections 1. Connect the signal to CH1 connector. <Note> Do not apply power voltage (DC + PEAK AC) higher than 400V. 2. Adjust CH1 VOLTS/DIV switch and vertical position terminal to place the signal in the measurable area. 3.
  • Page 23 2-3-6. Horizontal Display 1. Menu Selection a. A : Sweep Time of main time axis is displayed. (position ‘e’ fig. 2-3-1) : Sweep Time of delayed time axis is displayed. (position ‘s’ fig. 2-3-1) b. B Modelated brightness part is displayed on the whole screen with amplified state.
  • Page 24 2-3-7. Trigger Mode 1. Menu Selection a. AUTO : AUTO position selects free-running sweep where a baseline is displayed in the absence of a signal. This condition automatically reverts to triggered sweep when a trigger signal of 25Hz or higher is received and other trigger controls are properly set.
  • Page 25 2-3-8. Trigger Source 1. Menu Selection a. CH1 : When the signal is on CH1, the stable waveform can be observed by the selection of CH1 with TRIGGER SOURCE. b. CH2 : When the signal is on CH2, the stable waveform can be observed by the selection of CH2 with TRIGGER SOURCE.
  • Page 26 2-3-9. Trigger Coupling 1. Menu Selection a. AC : Signal passes through capacitor and connects with the input terminal of trigger generator circuit. At this time, the DC signal is screened off, and AC signal with frequency below 30Hz is attenuated. b.
  • Page 27 2-3-10. Auto setup Press Autoset key when the user does not know the present setting condition of oscilloscope, or the amplitude and frequency of input signal. This sets amplitude, frequency, and waveform automatically, sometimes the option state may not be set because of the difference of amplitude, frequency, duty ratio.
  • Page 28 c. HORIZONTAL PART (1) HORI DISPLAY (2) TIME/DIV : Set this so that the cycle can be displayed from 2 to 5. (3) VARIABLE : CAL (4) POSITION : CENTER (5) X 10MAG : This becomes ON when 10MHz or more waveform is input.
  • Page 29 2-3-11. Cursor 1. Sound ON / OFF. When press Cursor key, Sound is ON/OFF. 2. ∆V1(∆V2, ∆V3) On DUAL, ADD, QUAD, ∆V cursor is operated on the basic of CH1, so the expression becomes ∆V1. 3. ∆TA(∆TB), 1/∆TA(1/∆TB) CURSOR When HORI Display is A(B), ∆TA(TB) is displayed and when HORI Display is ALT, the display of the previous level does not change, ∆TA(TB) is changed with conversion of A/B terminal.
  • Page 30 2-3-12. X-Y Cursor 1. ∆V1 (∆V2) CURSOR On DUAL, ADD, QUAD, ∆V cursor is operated on the basic of CH1, so the expression becomes ∆V1, On X-Y, CH3 does not operate alone. 2. ∆V1 CURSOR On X-Y, ∆TA is expressed as ∆V1 and change to VOLTS/DIV of CH1. Though the channel of VERT MODE is changed, the value is operated on the basis of CH1.

  • Page 31: Measurement Applications

    2-4. MEASUREMENT APPLICATIONS This section contains instructions for using your Oscilloscope for specific measurement procedures. However, this is but a small sampling of the many applications possible for this oscilloscope. These particular applications were selected to demonstrate certain controls and features not fully covered in BASIC OPERATING PROCEDURES, to clarify certain operations by example, or for their importance and universality.
  • Page 32 d. Count the number of division from the graticule line touching the negative signal peaks to the intersection of the positive signal peak with the central vertical graticule line. Multiply this number by the VOLTS/DIV switch setting to get the peak-to-peak voltage of the waveform.
  • Page 33 d. Flip the AC/DC/GND switch to DC. The polarity of all points above the ground-reference line is positive ; all points below the ground-reference line are negative. <Caution> Make certain the waveform is not riding on a high-amplitude DC voltage before flipping the AC/DC/GND switch. e.
  • Page 34 e. Count the number of horizontal graticule divisions between the Step ‘d’ graticule line and the second measurement point. Measure to a tenth a major division. Note that each minor division of the central horizontal graticule line is 0.2 major division.
  • Page 35 2-4-3. Frequency measurement When a precise determination of frequency is needed, a frequency counter is obviously the first choice. A counter can be connected to the CH1 OUTPUT connector for convenience when both oscilloscope and frequency counter are used. However, and oscilloscope alone can be used to measure frequency when a frequency counter is not available, or modulation and/or noise makes a counter unusable.
  • Page 36 2-4-4. Phase difference measurements Phase difference in phase angle between two signals can be measured using the dual- trace feature of the oscilloscope, or by operation the oscilloscope in the X-Y mode. Dual-trace Method This method works with any type of waveform. In fact, it will often work even if different waveforms are being compared.
  • Page 37 The horizontal distance between corresponding points on the waveform is the phase difference. For example, the phase difference is 1.2 major divisions, or 60°. If the phase difference is less than 50°(one major division) it is possible to conduct a finer measurement with 10 × magnification, each major division is 5° and each minor divison is 1°.
  • Page 38 Precisely center the trace horizontally with the Horizontal POSITION control. Count the number of divisions along the central vertical graticule line. You can now shift the trace vertically with CH2 POSITION control to a major division line for easier counting. The phase difference (angle) between the two signals is equal to the arcsine of dimension A, B (the Step ‘g’...
  • Page 39 b. Adjust the A TIME/DIV switch to display about 2 cycles of the pulse. Make certain the A VARIABLE control is rotated fully clockwise and pushed in. c. Center the pulse vertically with the channel 1 Vertical Position control. d. Adjust the channel VOLTS/DIV switch to make the positive pulse peak exceed the 100% graticule line, and the negative pulse peak exceed the 0% line, rotate the VARIABEL control counterclockwise until the positive and negative pulse peaks rest exactly on the 100% and 0% graticule line.

  • Page 40: Calibration Interval

    Maintenance routines performable by the operator are listed in this section. More advanced routines (i.e., procedures involving repairs of adjustments within the instrument) should be referred to EZ service personnel. 3-1. CLEANING If the outside of the case becomes dirty or stained, carefully wipe out the soiled surface with a cloth moistened with detergent, then wipe out the cleaned surface with a dry cloth.
  • Page 41 4. DIAGRAMS 4-1. EXTERNAL VIEWS (OS-5100RA)
  • Page 42 4-2. BLOCK DIAGRAM (OS-5100RA)
  • Page 43 The specifications are subjected to change without notice.

This manual is also suitable for:

Os-5100rb
