1A3900
Brandon
Lightweight 4 Wheel Rollator
Max User Weight
19st (120kg)
General Safety Warning
Please make sure that you read and follow
these instructions carefully. Keep these
instructions in a safe place for future reference.
1. INTENDED USE
The Lightweight 4 Wheel Rollator is designed
to provide support and assistance to those
unable to, or who lack the confi dence, to walk
without some level of support. This rollator
is intended for indoor and outdoor use, and
folds away for easy storage or transportation.
2. SAFETY
Warning: The maximum user weight must not
be more than 19st (120kg). Do not adjust the
rollator while in use. Only use as a walking
aid in the forward direction. Do not use the
rollator on stairs or escalators and take care
on steep hills. Do not sit on the seat without
locking the brakes fi rst. Do not use the seat
to transport people or objects. Do not use
the seat without the backrest in place. Do not
hang items from the handles as this will affect
the stability of the rollator. Make sure the rol-
lator is locked in the open position before use.
Check the brakes before use. Make sure that
all parts are secure and that moving parts are
in good working order.
Item Colour
Red
Loads should only be transported using the
basket supplied (maximum load 5kg).
Handle Height Range: 825 - 950mm
Length: 915mm (folded) - 1110mm (Unfolded).
3. UNPACKING
Remove the packaging and check all parts
carefully. Contact your supplier immediately if
parts are missing or damaged and do not try
and assemble.
3.1 Contents:
1. Rollator assembly
2. Storage Basket (fi tted to frame)
3. Hand-wheel Bolt x 2
4. Backrest
5. Front wheels set
6. Rear wheel with brake handle and cable
assembly x 2
7. C-clip x 2
8. User instructions
Advertisement
Summary of Contents for Clearwell Mobility Brandon
- Page 1 1A3900 Brandon Lightweight 4 Wheel Rollator Max User Weight Item Colour 19st (120kg) General Safety Warning Please make sure that you read and follow Loads should only be transported using the these instructions carefully. Keep these basket supplied (maximum load 5kg).
- Page 2 4. ASSEMBLY Fit the back rest into the frame and secure Insert the front wheel assembley into the the with 2x snap clips on both sides. front frame tubes and secure with the c-clips. 4.1 Handle Height Adjustment Adjust the Rollator handle height so that when the user’s arm is down to their side, the hand-grip is at wrist height.
- Page 3 5. USING THE ROLLATOR 5.1 Brake Operation Tightening the Brakes To slow down or stop the rollator, pull both Loosen the lock nut (A), turn the adjuster (B) brake handles up. anticlockwise, then re-tighten the locknut. Note: There must be a gap of 2-3 mm be- tween the brake mechanism and the wheel, when the brake lever is released.
- Page 4 6. MAINTENANCE Check both hand-wheels are secure. Check all wheels can rotate freely. Regularly check for wear and damage. Any suspected faults or damage should be reported immediately to your supplier and the product taken out of use. Check brakes regularly in accordance with Section 5.1 before use.
