Barreto 3104CMS Owner's Manual

Chipper mulcher shredder
Source: barretomfg.com
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CONGRATULATIONS!
You are now the proud owner of the BARRETO 3104 Chipper Mulcher Shredder (CMS). The
OPERATOR'S MANUAL is attached to the machine. Please study it and this manual to become familiar
with the CMS, its characteristics, and method of operation. Pay particular attention to the safety and
operating instructions to prevent personal injury or equipment damage.
If you have any questions or need any replacement parts in the future, please contact us at your
convenience. Our toll-free phone number, fax and email are listed below.
THANK YOU for your patronage and confidence in BARRETO equipment.
Barreto Manufacturing, Inc.
Innovative Equipment Engineered to Last
66498 Hwy 203, La Grande, OR 97850
(800) 525-7348 (541) 963-7348
FAX (541) 963-6755
E-Mail:
info@barretomfg.com
Web Site:
http://www.barretomfg.com
Machine Identification Record
Machine model number
Machine serial number
Engine manufacturer
Engine model number
Engine serial number
3104CMS OWNER'S MANUAL
MODEL 3104CMS
CHIPPER MULCHER SHREDDER
OWNER'S MANUAL
________________________
________________________
________________________
________________________
________________________
THE
9/5/18
Page 1 of 18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3104CMS and is the answer not in the manual?

Questions and answers

Summary of Contents for Barreto 3104CMS

  • Page 1 OWNER’S MANUAL CONGRATULATIONS! You are now the proud owner of the BARRETO 3104 Chipper Mulcher Shredder (CMS). The OPERATOR’S MANUAL is attached to the machine. Please study it and this manual to become familiar with the CMS, its characteristics, and method of operation. Pay particular attention to the safety and operating instructions to prevent personal injury or equipment damage.

  • Page 2: Table Of Contents

    INDEX ..............................18 WARRANTY OF BARRETO MANUFACTURING EQUIPMENT Barreto Manufacturing, Inc. warrants all BARRETO equipment to be free of defects in material and workmanship for a period of one (1) year, dating from the delivery to the original user. This warranty is in lieu of all other warranties, whether written or implied, and is limited to: 1.

  • Page 3: Safety Messages

    USA & CANADA: Emergency dial 911 USA & CANADA: American Association of Poison Control Centers: 1-800-222-1222 Outside the USA & Canada (Please fill in the appropriate number) National Emergency number:_______________ Poison Control Center:____________________ Other:_________________________________ 3104CMS OWNER’S MANUAL 9/5/18 Page 3 of 18...

  • Page 4: Cms Assembly Instructions

    There is a pre-shipping inspection sheet and /or a packing slip included, review these to make sure that all components have arrived. If there is damage or missing components notify the carrier and Barreto Manufacturing immediately. AT THE TIME OF WRITING, CRATING / SHIPPING METHODS HAVE NOT BEEN FINALIZED.

  • Page 5: Operator Training

    Replacement parts and decals can be purchased from Barreto Manufacturing, Inc. When attaching decals, the temperature of the mounting surface must be at least 40°F (5°C) and must be clean and dry.

  • Page 6: Maintenance Preparation

    This is a recommended lockout procedure in accordance with OSHA 1910.147(a)(3)(i) it is your responsibility to establish and utilize procedures for affixing appropriate lockout/tagout devices. For more information on developing vehicle maintenance lockout/tagout procedures refer to OSHA, DIRECTIVE NUMBER: CPL 02-00-147. 3104CMS OWNER’S MANUAL 9/5/18 Page 6 of 18...

  • Page 7: Hour Meter

    Your DGI® hour meter is pre-set at the DGI® factory to go into Flash Alert mode at 25-hour intervals. Although the engine manufacturer does not require changing engine oil this often, due to heavy-duty use and extreme conditions inherent to CMS use, Barreto Manufacturing strongly recommends frequent oil changes.

  • Page 8: Engine Maintenance

    Follow the instructions provided in your engine operator’s manual for all engine maintenance and procedures. Barreto Manufacturing has added an engine oil drain hose to your engine to facilitate easier oil changes. Due to heavy duty use inherent to CMS operation Barreto Manufacturing recommends that you change your engine oil every 25 hours.

  • Page 9: Belt Installation / Replacement

    The belts on the CMS have been designed for heavy duty use, high shock loads and smooth clutching. It is recommended that you replace your belts with belts from Barreto Manufacturing. WARNING: The CMS must be rendered inoperable before removing the belt cover or beginning any work on the belts.

  • Page 10: Chipper Blade Inspection And Replacement

    When reinstalling the chipper blade use high strength red threadlocker and torque bolts to 102 lb-ft. NOTICE: DO NOT drop bolts or tools into the chipper disk area; it will be difficult to remove. 3104CMS OWNER’S MANUAL 9/5/18 Page 10 of 18...

  • Page 11: Mulcher Hammer Checking And Replacement

    5. Push the rotor pin in (towards the chipper disk) and remove the shaft locking flange. 6. Slowly pull the rotor pin out (away from the chipper disk) 7. Carefully remove the hammers and spacers. The hammers and spacers nearest the chipper disk will come out first. 3104CMS OWNER’S MANUAL 9/5/18 Page 11 of 18...
  • Page 12 The mulching hammers cannot be sharpened. After all four corners of the hammers have dulled they must be replaced. Clearances in the mulching hammer are tight, disassembly and assembly can be difficult. BE PATIENT. 3104CMS OWNER’S MANUAL 9/5/18 Page 12 of 18...

  • Page 13: Anvil Inspection And Replacement

    WARNING: Exercise extreme caution while measuring the gap between the chipper blade and the anvil. The chipper disk does not lock in a position to easily allow the measurement of the gap between the blade and the anvil. Wear gloves and all appropriate personal protective equipment. 3104CMS OWNER’S MANUAL 9/5/18 Page 13 of 18...

  • Page 14: Battery Safety Instructions

    USA & CANADA: Emergency dial 911 USA & CANADA: American Association of Poison Control Centers: 1-800-222-1222 Outside the USA & Canada (Please fill in the appropriate number) National Emergency number:_______________ Poison Control Center:____________________ Other:_________________________________ 3104CMS OWNER’S MANUAL 9/5/18 Page 14 of 18...

  • Page 15: Battery Maintenance

    • Clean CMS components near the battery with baking soda and water. DO NOT use a wire brush. • Rinse with clean water and allow enough time for water to dry. • Coat terminals and wire lugs with dielectric grease. • Connect your battery. See: To install your battery: 3104CMS OWNER’S MANUAL 9/5/18 Page 15 of 18...
  • Page 16 Interstate Batteries recommend using a 3-stage automatic 12 volt/10 amp charger for automotive batteries such as the MT-34 battery, no Interstate Batteries charger type recommendation has been found for lawn and garden batteries such as the SP-35 battery. 3104CMS OWNER’S MANUAL 9/5/18 Page 16 of 18...

  • Page 17: Cms Troubleshooting Guide

    CMS TROUBLESHOOTING GUIDE At Barreto Manufacturing we take pride in our machines and our customer service. If you are having difficulty with your machine please call us at the number listed on the front page of this manual. WARNING: Always use extreme care when troubleshooting or making adjustments. Stay clear of all moving parts or parts capable of moving while the engine is running or capable of running.

  • Page 18: Specifications

    LUBRICATION, GREASE, 5, 8, 16, 18 LUBRICATION, OIL, 4, 6, 7, 8, 18 MAINTENANCE, 2, 5, 6, 7, 8, 14, 15, 18 MULCHER HAMMER, 11 OPERATOR TRAINING, 5 SPECIFICATIONS, 18 TROUBLE SHOOTING, 17 WARRANTY, 2 3104CMS OWNER’S MANUAL 9/5/18 Page 18 of 18...
