ZRS-2D User Manual ENGLISH - IMPORTANT USER INFORMATION This ZYPAD Ring Scanner manual is divided in two parts: The first part contains information relevant to safety and environment protection written in the languages of the Countries where the product is distributed. The second part contains a start guide written in English only.
33020 AMARO (Udine) ITALY Eurotech shall not be liable for the use of our products with equipment (i.e., power supplies, personal computers, etc.) that are not CE marked and do not comply with the Low Voltage Directive. The equipment is designed as a ring scanner.
ZRS-2D User Manual Tested to Comply with FCC Standards The ZRS-2D has been tested to, and complies with, part 15 of the FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation.
ZRS-2D User Manual ITALIANO - IMPORTANTI INFORMAZIONI PER L’UTILIZZATORE Questo manuale è diviso in due parti: La prima parte contiene informazioni sulla sicurezza e sulla salvaguardia dell’ambiente scritte nelle lingue dei Paesi in cui il prodotto viene commercializzato. La seconda parte contiene informazioni sulle operazioni iniziali per poter mettere in funzione l’apparecchiatura ed è...
Via Fratelli Solari, 3/a 33020 AMARO (Udine) ITALY Eurotech non può essere ritenuto responsabile dell’uso dei propri prodotti insieme con apparati (es: alimentatori, personal computers, ecc.) che non siano marchiati CE o non siano conformi alla direttiva Direttiva Bassa Tensione.
ZRS-2D User Manual Test per la conformità agli standard FCC Questo dispositivo è conforme alla Sezione 15 delle Regole FCC. Il funzionamento è soggetto alle due seguenti condizioni: Questo apparecchio non può causare interferenze dannose Questo dispositivo deve accettare qualsiasi interferenza ricevuta, compresa un’interferenza che può...
ZRS-2D User Manual FRANÇAIS - INFORMATION IMPORTANTE POUR L’UTILISATEUR Les précautions d’utilisation du ZRS-2D se composent de 2 parties: ère La 1 partie contient des informations concernant la sécurité et la protection de l’environnement, rédigées dans la langue des pays dans lesquels le produit est commercialisé. La 2 partie contient des informations sur les opérations de mise en route, rédigées exclusivement en englais.
équipements insuffisamment protégés. Eurotech ne peut être tenu pour responsable de toute interférence radio causée par le produit ou par des modifications non autorisées de l’appareil ou encore par la substitution ou l’ajout de câble de connectique et de composants autres que spécifiés par Eurotech.
ZRS-2D User Manual Testé en conformité avec les standards FCC Le ZRS-2Da passé de manière positive les tests de conformité en rapport avec l’article 15 du règlement FCC. Cet agrément est soumis à deux conditions: L’équipement ne doit causer aucune interférence nuisible. L’équipement doit accepter la réception de toute interférence, dont celles pouvant être la source d’opérations indésirables.
ZRS-2D User Manual DEUTSCH - WICHTIGE INFORMATIONEN FÜR ANWENDER Dieses ZYPAD Ring Scanner (ZRS-2D) Handbuch besteht aus zwei Teilen: Der erste Teil enthält Informationen bezüglich Sicherheit und Umweltschutz in der Sprache derjenigen Länder, in denen das Produkt vertrieben wird. Der zweite Teil enthält Informationen über die Inbetriebnahme und steht nur in Englisch zur Verfügung.
Eurotech übernimmt keine Verantwortung für Funk- oder Gerätestörungen, die bei diesen Geräten entstehen oder die durch nicht autorisierte Veränderungen an diesen Geräten oder den Austausch bzw. den Anschluss von Verbindungskabeln und Geräten, die nicht von Eurotech spezifiziert sind, verursacht werden. Die Behebung der Störungen fällt in die Verantwortlichkeit des Benutzers.
ZRS-2D User Manual Geprüft auf Einhaltung der FCC-Normen Dem ZRS-2D wurde nach Tests, die Einhaltung der Bestimmungen laut Teil 15 der FCC-Vorschriften bescheinigt. Der Betrieb unterliegt beiden folgenden Bedingungen: Dieses Gerät darf keine schädlichen Funkstörungen verursachen und dieses Gerät muss Funkstörungen (Interferenz) vertragen können. Dies gilt auch für Funkstörungen, die unerwünschte Betriebsweisen verursachen.
ZRS-2D User Manual ROHS Dieses Gerät, einschließlich all seiner Komponenten, Baugruppen und Verbrauchs-materialien, die ein integraler Bestandteil des Produktes sind, wurde gemäß den Bestimmungen der EU-Richtlinie 2002/95/EC, bekannt als RoHS-Richtlinie (Restrictions on the use of certain Hazardous Substances) hergestellt. Diese Richtlinie zielt auf die Reduzierung bestimmter Gefahrenstoffe ab, die bisher in elektrischen und elektronischen Geräten (EEE) verwendet wurden.
ZRS-2D User Manual 欲了解更详细的信息, 请随时联系: Eurotech S.p.A. A member of the Eurotech Group Via Fratelli Solari, 3/a 33020 AMARO (Udine) ITALY 对于搭配使用非CE认证或不符合Low Voltage Directive规范的产品(例如:电源,个人计算机等)的行为,Eurotech集团将不承担任何法律责任。 该设备被作为手指式扫描仪而设计。 符合欧洲R&TTE规范 该设备将可能在以下地区应用: 安全注释和警告 规范信息 ZRS-2D 已经通过测试并确认符合FCC规范第15部分中对于电子设备的B级要求。产品的设计能够为设备提供在 严重干扰下的有效保护。若没有按照产品说明正确使用或安装,ZRS-2D 将有可能产生,使用并辐射出无线电频率功耗,这可能会严重影响无线电通讯或影响那些没有完善屏蔽 设施的设备。 对于在没有得到官方授权就擅自对设备进行改造,零件更换或对设备连接各种非Eurotech指定的线缆与 天线而对其他设备造成的任何干扰与影响,Eurotech将不承担任何责任。...
Chapter 1 Caution CAUTION LASER PRODUCT CAUTION: CDRH Class II/IEC Class 1 laser light. Do not stare into beam ATTENZIONE: Laser CDRH Classe II/IEC Classe 1. Non fissare il raggio ATTENTION: CDRH Classe II/IEC de classe 1 lumière laser. Ne pas regarder le faisceau VORSICHT: CDRH Klasse II/IEC Klasse 1 Laserlicht.
Chapter 2 Technical specifications Features Wearable Users can scan bar codes while keeping their hands free since the device can be worn on the finger of the left or right hand even when wearing gloves. High Accuracy Scanning performance Accurate reading of 1D and 2D bar codes even when poorly printed or damaged. Rugged Design Rugged case stands up to everyday indoor and outdoor environments.
Page 30
ZRS-2D User Manual Physical Characteristics Dimensions Length 73.22 mm (2,88") Width 36.50 mm (1,43") Height 55.35 mm (2,18") Weight 66 g (2,12 oz) Material Anti-shock plastic Mini USB type A plug...
Chapter 3 Knowing the Zypad Ring Scanner ZRS-2D Verify the contents of the box The box should contain the following items: One Zypad Ring Scanner (ZRS-2D) One miniCD-ROM with software, utilities, and documentation One printed Quick Reference Guide One auxiliary protective cover for the I/O interfaces of WL11xx to be used together with the ZRS-2D ring scanner The Zypad Ring Scanner ZRS-2D The ZRS-2D Ring Scanner combined with the Zypad wearable computer gives users a hands-free,...
Chapter 4 Wearing and working with the ZRS-2D Wearing the ZRS-2D on the right or left index finger Thanks to the integrated swivel system, the Zypad Ring Scanner allows the user to rotate the scanning head. In this way the Ring Scanner can be worn on the right or left index finger. The Ring Scanner’s default configuration is for users who wear the Ring Scanner on the left index finger, as in the following figure: Execute the following steps with care.
ZRS-2D User Manual Stop the rotation when the head and the base are aligned and the unit clicks. Do not rotate further or the swivel mechanism will be permanently damaged. The Ring Scanner can now be worn on the right index finger. Limit of rotation 180°...
ZRS-2D User Manual Connecting the ZRS-2D to the WL11xx series Turn on the Zypad WL11xx. Connect the ZRS-2D to the WL11xx by inserting the free USB end of the stretchable-coiled cable into the “USB host” port of the WL11xx (located on the bottom side, under the protective rubber cover). The ZRS-2D Ring Scanner will be automatically recognized: no drivers need to be installed...
ZRS-2D User Manual The Software Two programs are available on the supplied CD-ROM in path \Software\WL11xx as follows: ZyBar2D.exe The ZyBar2D program, once installed and set up, emulates manual keystrokes and provides the scanned data for any active application. ScanSet2D.exe The ScanSet2D program allows the user to setup the ring scanner with some useful options that can make barcode acquisition easier and more efficient.
ZRS-2D User Manual THE ZYBAR2D SOFTWARE Double-tap on the ZyBar2D software icon: The program will start and a circle will appear on the application task bar: • If the ZRS-2D is disconnected from the WL11xx, the circle will be red •...
ZRS-2D User Manual THE SCANSET2D SOFTWARE Double tap on the ScanSet2D software icon The program will start and the following tabs will become available, these are used to configure the parameters used for the scanning procedure: Symbologies Prefixes-Suffixes Sounds Info Transmit Imager User...
Page 39
ZRS-2D User Manual Prefixes/Suffixes tab The user can: Add/Remove Prefixes/Suffixes Allow bar-code transmission By using these options, the user does not have to place the cursor on the right place since the prefixes/suffixes can be easily programmed to perform these tasks. Prefixes/suffixes such as carriage return and line feed will allow users to easily place the scanned data in the correct place on the window.
Page 40
ZRS-2D User Manual Info tab This tab allows the user to view information about the software Transmit tab This tab allows the user to set the transmission parameters of the ZRS-2D and to: Upload the parameters to the ring scanner Download the parameters from the ring scanner Imager tab The imager tab allows the user to configure the parameters of the micro camera that acquires the...
Page 41
ZRS-2D User Manual User tab This tab allows the user to configure the scanner parameters. Clone tab This tab allows the user to export the settings to other devices. This is the procedure to follow: Tap the “Change Device” button and follow the instructions that will appear Change the device Tap the button “CLONE”...
ZRS-2D User Manual Acquiring a bar code Aim the finger at the bar code and Press the trigger button. The red laser beam that is emitted should cover the entire width of the bar code. If the acquisition is good, the LED of the ZRS-2D will emit a green light and the WL11xx will produce a “beep”...
