AM200 User's Guide
STANDARD FIXED HEAD
SELF LEVELING HEAD
130'
512hz Built in Sonde

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AM200 and is the answer not in the manual?

Questions and answers

Summary of Contents for Amazing Machinery AM200

  • Page 1 AM200 User’s Guide 130’ STANDARD FIXED HEAD 512hz Built in Sonde SELF LEVELING HEAD...
  • Page 2 www.amazingmachinery.com...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Diagram & Equipment Specifications...4 Equipment Specifications & Safety Instructions........5 Control Panel..........6 Control Panel cont. with Diagram....7 AM200............8 AM200 with Diagram........9 Trouble Shooting........10-16 Removing the Camera Head......17 Warranty Information........18 www.amazingmachinery.com...
  • Page 4: Diagram & Equipment Specifications

    DIAGRAM & SPECIFICATIONS A. Camera Head Included Not Pictured B. Cable Guide - 7” LCD Color Monitor C. Powder Coated Frame - 512 hz Built in Sonde D. Heat Treated Epoxy Sealed SV Cable E. Rubber Feet F. Control Box www.amazingmachinery.com...
  • Page 5: Equipment Specifications

    EQUIPMENT SPECIFICATIONS • AM200 Standard Fixed Head Dimension: 1.29” Diameter Pipe Size: 2“ Pipe + (2” Pipe Depends on Condition of Pipe) • AM200 Self Leveling Head Dimension: 1.95” Diameter Pipe Size: 3“ Pipe + (3” Pipe Depends on Condition of Pipe) •...
  • Page 6: Control Panel

    CONTROL PANEL Please view diagram 1.a on page 7 for control panel. Main Controls: Dimmer Control – Dim LED Lights as Needed Video Out Put Sonde – Turn on to activate 512 Hz Sonde (optional) (2) 12 Volt Power inputs Digital Footage Counter Controls (optional depending on model purchased) www.amazingmachinery.com...
  • Page 7: Control Panel Cont. With Diagram

    CONTROL PANEL sonde video output dimmer control www.amazingmachinery.com...
  • Page 8: Am200

    AM200 AM200 Inspection Camera Once you have inspected all components to make sure that they are not damaged or broken plug in the (2) 12 volt transformers into an outlet. At that time plug in the other end of the transformer into the control box power jack (see diagram 1a on page 7).
  • Page 9: Am200 With Diagram

    AM200 Option: At this point you will plug the free end of your yellow video cable located inside the control box into the video jack on the control panel. If your camera model came equipped with a 512 Hz transmitter built inside the camera head please see the diagram below to activate the built in transmitter.
  • Page 10: Trouble Shooting

    TROUBLE SHOOTING The trouble shooting guide lines below are designed to help you out in the field. If you cannot figure out the problem or fix it without voiding your warranty, please call the number listed in the back of your manual to speak with a repair technician.
  • Page 11 TROUBLE SHOOTING VIDEO WORKS–LIGHTS DON’T TURN ON Possible Problems: -Lights Burnt out -Dimmer Control Switch Turned Down -Dimmer Control Switch Broken -Broken or loose connection in Camera Head. TRY THIS: Turn dimmer control all the way down and then all the way back up.
  • Page 12 TROUBLE SHOOTING TRY THIS: First check to see if your GFCI is tripping. Try to plug the unit into another location with different electricity. If GFCI will not re-set it is not working and will prevent the camera system from turning on. IF GFCI IS REMOVED FROM UNIT AND THEN CAMERA SYSTEM IS USED WITH OUT IT, WARRANTY WILL BE VOID.
  • Page 13 If the suggestions above have not eliminated the problem there is a possibility that your MONITOR or RECORDING DEVICE is dirty and needs to be cleaned. See Monitor Instruction Booklet for cleaning instructions. If problem persists please contact a repair technician at Amazing Machinery. www.amazingmachinery.com...
  • Page 14 TROUBLE SHOOTING “NO SIGNAL” FLASHING ON MONITOR Possible Problems: -Wrong setting set on Monitor or Recording Device -Faulty Video Cable -Broken or damaged monitor or recording device -Broken or loose connection in camera head or control box. TRY THIS: Read Monitor or Recording Device instruction manual to make sure you are on the proper settings.
  • Page 15 TROUBLE SHOOTING BLURRY OR SCRAMBLED PICTURE Possible Problems: -Monitor Broken or Damaged -Seal broken or compromised -Moisture in head -Camera Head Fried -Faulty Video Cable TRY THIS: First plug the camera system into another monitor or standard television that accepts standard RCA connections.
  • Page 16 TROUBLE SHOOTING COLORFUL IMAGES DISTORTED COLORS Possible Problems: -Monitor Broken or Damaged -Seal broken or compromised -Moisture in head -Camera Head Fried -Faulty Video Cable TRY THIS First plug the camera system into another monitor or standard television that accepts standard RCA connections.
  • Page 17: Removing The Camera Head

    STANDARD FIXED SELF LEVELING NOTE: Amazing Machinery recommends that you send your equipment to an authorized service center and have an authorized repair technician work on the product. Please contact the service department for further diagnosis and instructions regarding your product.
  • Page 18: Warranty Information

    WARRANTY INFORMATION For warranty or service work please contact Amazing Machinery. Read the following information for contact details. Amazing Machinery 2288 Gunbarrell Road Suite 154-151 Chattanooga, TN 37421 1 (800) 504-7435 www.amazingmachinery.com...
