Light Touch LT1020 Series – Quick Start Guide
1.

Remove from packaging and peel off protective films

Check package contents against packing list

2. Fit base-plate

Fit the base-plate to the unit using the M5 screws provided, as shown in Figure 1.
Only use the M5 flat
head screws provided

3. Unscrew battery bay and remove

See Figure 3 and 4. The label on the battery bay shows which screws to remove
NOTE: The Light Touch unit has no user-serviceable parts and should not be disassembled except by
qualified service personnel. Please return to Light Blue Optics for servicing.
bbb
5000 0040
Figure 1
Fitting the
baseplate
Figure 2
(A) DC power
input (B)
on/off button
Figure 3
Unit with
battery bay
closed.
Arrows show
which screws to
remove
Figure 4
Unit with
battery bay
open
Light Touch LT1020 Series – Quick Start Guide v2.1 | Page 1
A
B
