THE EASY WAY TO RAISE & LOWER YOUR ANTENNA
DO NOT ERECT ANY ANTENNA OR MAST NEAR ANY OVERHEAD WIRES, UNDER ANY
CIRCUMSTANCES. READ AND FOLLOW THESE INSTRUCTIONS CAREFULLY:
1) Do not erect ANYTHING near any overhead wires. Assume all such wires to be power lines and
deadly.
2) Request advice from your local power company, if power wires are anywhere near the proposed
installation.
3) If the antenna or mast falls, do not try to stop it. Get out of the way.
4) If any part should touch overhead wiring, DO NOT TOUCH IT! Call the power company
immediately for help.
5) In the event of an accident involving power wiring:
DO NOT TOUCH THE VICTIM DIRECTLY. Send someone for help.
6) Select a site which limits public access to the antenna or your mast. If any possibility exists that people
or pets could touch the antenna, place a small wooden fence around the site after installation.
7) Choose a calm (no wind), dry day to erect the antenna.
8) Always enlist the aid of at least one person in erecting the antenna.
9) Do not use or stand on a ladder in the process of erecting your antenna or mast. A ladder is not needed
and could be dangerous.
10) Do not connect the antenna coax until the antenna is firmly mounted.
11) Completely read the entire instruction manual before preceding with the assembly.
SAFETY NOTICE
WARNING!
POWER LINES CAN KILL.
1
QUICK
MOUNTS
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for GAP Quick-Tilt
Summary of Contents for GAP Quick-Tilt
- Page 1 QUICK MOUNTS THE EASY WAY TO RAISE & LOWER YOUR ANTENNA SAFETY NOTICE WARNING! POWER LINES CAN KILL. DO NOT ERECT ANY ANTENNA OR MAST NEAR ANY OVERHEAD WIRES, UNDER ANY CIRCUMSTANCES. READ AND FOLLOW THESE INSTRUCTIONS CAREFULLY: 1) Do not erect ANYTHING near any overhead wires. Assume all such wires to be power lines and deadly.
- Page 2 Loosen and remove the small wing nut on the ¼" bolt found at the top of your Quick-Tilt mount. This bolt will be used to hold two spacers that will prevent your antenna or mast from moving side to side.
- Page 3 5" PVC separators in the hole. Mix up two 80 lb bags of concrete according to the directions on the bag and pour it into the hole. Using a level, set the Quick-Tilt mount so it is plumb. Reassembling your Quick-Tilt With The Supplied PVC Pipe Remove the 5"...
- Page 4 TEL. (772) 571-9922 WARRANTY GAP Antenna Products, Inc. provides a limited warranty on its products against any defects in material and workmanship for a period of 90 days after date of purchase/shipment. This warranty applies to the original purchaser only. Purchaser should not return defective product freight prepaid. GAP reserves the right to repair or replace product , at its discretion.
