Summary of Contents for Spectrum Technologies WatchDog 3388BGU
- Page 1 ® Bi-Directional GPRS / CDMA Modems & Solar Panels PRODUCT MANUAL Item 3388BGU, 3388BGE, 3388BC, 3388SP5...
- Page 2 CONTENTS Configuration Assembly Operation Warranty CE Declaration of Conformity Thank you for purchasing the WatchDog Bi-Directional GPRS or CDMA modem with solar power. Please read this manual thoroughly before assembling and using your modem. Components WatchDog Modem The modem is packed in a single box containing the waterproof enclosure. The modem, cables, and electronics come pre-assembled within the enclosure.
- Page 3 Configuration The WatchDog Modems are designed for use with the WatchDog 2000 Series Mini and Full Weather Stations. If you are adding the modem to an existing station, the station microcontroller may need to be upgraded to operate with the WatchDog modem. You must configure your WatchDog 2000 Series Station to work with the WatchDog Modem.
- Page 4 The WatchDog Mini Stations have two “Repeat-” “Format” options: • Format “3 Text” sends 64 bytes of text information at a time. This format is currently required for use with SpecWeather.com. • Formats “H Binary E” and “G Binary M” are shorter forms that compress the data into a 24 byte record.
- Page 5 • Within the Spectrum Cellular Configuration screen you will have the following options: URL: The “Url” should only be changed if data will be sent to your own server, otherwise keep the de- fault setting “gprs.meteodata.info.” Page: The “Page” should only be changed if data will be sent to your own server, otherwise keep the default setting “default.aspx.”...
- Page 6 Assembly Note: If the station is going to be permanently located at the measurement site, it is recommended that the mounting pole be installed in the ground before attaching any components. Attaching the Solar Panel 1. Align the Angle Bracket with the two 2.
- Page 7 Connecting the GPRS modem to the battery and solar panel Before connecting the solar panel to the modem, temporarily cover the panel with cardboard to prevent any current from being generated during the installation. 1. Feed the black cable from the solar panel through the strain relief on the bottom of the Modem Enclosure.
- Page 8 If not, it will be listed on the modems white sticker. 5. If you have a GPRS modem and subscribe to a Spectrum Technologies data plan (US mar- ket only), the SIM card may already be installed. Insert your SIM card according to the image below with the metallic circle towards the bottom of the holder.
- Page 9 Deploying the weather station Attach the WatchDog Weather Station to the pole (See the instructions in the WatchDog Weather Gray Cable Station manual provided with your station). Remove the far-right gland (cap and strain relief) from the bottom of the station. Remove the top nut and washer from the RJ12 (telephone), now feed the end of the gray cable with the RJ12 connector (it is...
- Page 10 Warranty This product is warranted to be free from defects in material or workmanship for one year from the date of pur- chase. During the warranty period Spectrum will, at its option, either repair or replace products that prove to be defective.
