Summary of Contents for Augury SimuCUBE

  • Page 1 support@augurysimulations.com...
  • Page 2 Congratulations !!!!! Here you have your AUGURY, We thank you most sincerely for placing your confidence in this team. In this Getting Started guide we aim to show you step by step how to use your Augury with the SimuCUBE Software.
  • Page 3 2. Content of the box : Servomotor and Cotter (with this cotter we will be able to set our QR or ring adapter) 3.We have to set up the cotter in this position :...
  • Page 4 4. Use a nylon hammer or a similar tool to hit carefully the cotter till it fits like in the picture (It’s very important to avoid hard hits) : 5. Setting up the Stainless Steel mounting and screws : The conections of the servomotor can be in the side of the motor we prefer. Just rotate the motor before setting up the frontal Stainless Steel mounting (In the picture it appears in the left side)
  • Page 5 6. Use a M8 Allen key to set the 4 long screws and their nuts :...
  • Page 6 7. Rotate the servomotor like in the picture so you can engage the lateral mounting parts. Parts will support and fix the servomotor in the surface of our cockpit, chassis, table or similar: It is important to remember that the lateral support parts should be placed in the inner part of the frontal mounting, so they are close to the servomotor :...
  • Page 7 8. Allign the holes of the both parts, the lateral and the frontal support and put the short M8 screws with their nuts like it’s showed in the picture : The whole should look be like in the picture:...
  • Page 8 9. Finally we set an additional nut (also included) in the screw we prefer. Later it will be used to connect the ground wire and prevent EMIs (ElectroMagnetic Interferences):...
  • Page 9 Ensure the red button is up. Rotate it clockwise, to set it in the standard position. The Augury box supply wire should be connected to mains in a plug with ground pin. In the picture an example of that is showed.
  • Page 10 Connect the EMIs-Suppressing wire (both ends) We should set one of the ends of the wire in the additional nut of our servomotor: The other end should be connected in any screw of our cockpit. If you don’t have a cockpit or metal chassis, you can put it in any other screw of the servomotor.
  • Page 11  The Augury (OSW) is already flashed está flasheado on both the SimuCUBE and the IONI servo driver (YOU WILL NOT HAVE TO RECORD ANY PARAMETER)  In this guide you only need to center your steering wheel with respect to the axis of the servo motor in a few simple steps that we indicate below.
  • Page 12 At the end a small beep will sound indicating that the test has finished. It is important to indicate that the steering wheel does not have to be centered.  We will open the folder where we have saved the SimuCUBE Software and execute the SimuCUBE Configuration Tool.exe file:...
  • Page 13 In case this window does not appear, we must disconnect and reconnect the usb of the GAME port of the Augury (with the Augury plugged in). This is a small glitch that the SimuCUBE firmware currently has on some PCs.
  • Page 14  Select the option “Use existing IONI configuration as-is….” (Default option). Click Next:...
  • Page 15  Choose the option “Automatic, in reference to position after Initilization” (Default option). Click Next:...
  • Page 16  Once again, Click Next:...
  • Page 17  We should center our steering Wheel and click Next:...
  • Page 18  Wait till this prompt appears and click Next:...
  • Page 19  Set again the steering Wheel in the center point and Click Next:...
  • Page 20  Done !!!, Finally click Finish:...
  • Page 21 Working with SimuCUBE Software In this final part we will explain some basic notions to get started with the SimuCUBE Software : Attached a Link where they explain in more detail all the functions: https://granitedevices.com/wiki/SimuCUBE_Firmware_User_Guide  Upper tab Profiles: If we want to change some values, first of all we have to click Copy.
