- Page 1 20220307 TBB9 User Manual...
-
Page 2: Table Of Contents
TBB9 User Manual ................................... 2 1. Warning ................................3 2. Introduction ................................4 3. Specifications ..............................5 4. 2D Drawings ................................. 6 5. Installations................................8 Mounting position..................................8 Assembly ....................................9 6. Capacity Status and LED Indications ........................10 7. Charging ................................11 Via control box .................................. -
Page 3: Warning
Don’t discard or expose the products to water or heat sources. Recycle with certified depots. 10. The battery needs to be repaired by the original manufacturer or an authorized maintenance center. 11. Always use a Movetec charger. Version C March 2022... -
Page 4: Introduction
TBB9 User Manual 2. Introduction The TBB9 is a rechargeable battery that provides mobility to height-adjustable desk applications. ON / OFF Button Operation: ON: Press continuously for 2 seconds, and there will be a short beep. OFF: Press continuously for 2 seconds. -
Page 5: Specifications
TBB9 User Manual 3. Specifications Model name TBB9 Capacity 2.5Ah / 63Wh Rated output voltage 25.2V DC Rated output current Max. output current Rated input voltage 32V DC (charging cradle) / 5V DC (Micro USB) 1A (charging cradle) / 1~2A (Micro USB) -
Page 6: D Drawings
TBB9 User Manual 4. 2D Drawings TBB9 Charging cradle Version C March 2022... - Page 7 TBB9 User Manual TBB9 with charging cradle Version C March 2022...
-
Page 8: Installations
TBB9 User Manual 5. Installations 5.1 Mounting position Version C March 2022... -
Page 9: Assembly
Use M4 screws (3 pieces) to fix the charging cradle into the desired position on the desk. (PIC1) Connect the charging cradle and the control box. (PIC 2) Put the TBB9 into the charging cradle. (PIC 3) Turn on the TBB9. -
Page 10: Capacity Status And Led Indications
Four LED shine Fully charged >90% Four LED shine Shine continuously Discharging >75% Four LED shine When the TBB9 is in operation, (when using) continuously we can press the ON/OFF button for 0.5 seconds to check 50%~75% Three LED shine the battery capacity status. -
Page 11: Charging
The TBB9 can be charged directly from the control box or via the standard Micro USB. 7.1 Via control box If the control box is connected to the AC power and the TBB9, the TBB9 will charge via the control box. ... -
Page 12: Via Micro Usb
TBB9 User Manual 7.2 Via Micro USB The TBB9 can be charged independently via the Micro USB. It takes about 16 hours to charge fully. Recommendations for the Micro USB charger specifications: Voltage: 5V DC Current: 2A (Note: A charger with an output greater than 2A can be used, but the input current on the TBB9 end will remain 2A. -
Page 13: Remarks
To avoid losing battery life, charge to 75% (4 LED lights) before storing. The battery will display 2 LED lights when lower than 50% capacity. When the TBB9 is not in use, please charge it every six (6) months. The battery life will be affected by use and the working environment. After recharging 300 times, the battery may only support 60% capacity. -
Page 14: Protections
Voltage <19~20V voltage protection warnings Turn on the TBB9 after a full charge. The output of TBB9 or Turn on the TBB9 after a Short circuit protection control box has short full charge. circuit problems The operation will ... -
Page 15: Storage
<1month 45~60 3 months 20~45 12 months -20~20 9.2 Self-Discharging When the TBB9 is packed independently, the storage period and capacity will display as below (90% capacity when shipped out from the factory): Period Capacity Status (including shipping) 3 months... -
Page 16: Packaging And Transportation
TBB9 User Manual 9.3 Packaging and Transportation The TBB9 is packed according to the 2017 Lithium Battery Guidance Document by IATA. The packaging is supplied with a label (see image below) stating the package contains lithium-ion batteries. All packaging and transportation must comply with the regulations within the 2017 Lithium Battery ... -
Page 17: Appendix
TBB9 User Manual 10. Appendix 10.1 Discharge Voltage - Time Curve Discharge time(minute) Discharge current TBB9 (2.5A/25.2V/63W) discharge time Discharge current Discharge time (minute) 2.5A 7.50 12.5A Version C March 2022...
