Rutland County Garden Furniture Wall Mounted Double Premium Pergola Assembly Instructions Manual

Before you commence the assembly process, we recommend that you read these instructions thoroughly beforehand to
familiarise yourself with the assembly process and to also check that you have the correct components. If for any reason you
need assistance, you can find our contact details on the final page of these instructions.
We highly recommend that any assembly is carried out on an open flat, level surface if possible, with sufficient space. You
will also require the assistance of up to 2 adults to complete assembly safely.
Please note: 1) You can remove up to 600mm from the bottom of each post prior to commencing
construction. Remember to also adjust the height of your wall plate accordingly.
2) Wall fixings are not included.
Tools required:
The components listed below are those required to build a Double Premium pergola of 3M in size or larger. For the 2.4M
version there are only 3 rafters and 28 x 120mm coachscrews. *An extra post is included in the 3-post version.
32 x Short Green 16 x Long Green
woodscrews
4 x Pre-drilled 2 x Pre-drilled
end Rafters
Assembly Instructions
10mm socket, No2 Pozidriv screwdriver (or electric driver), step ladder or
platform.
16 x 70mm
woodscrews coachscrews
1 x wall plate
Runners
Wall Mounted Double Premium
Components
16 x 120mm
coachscrews
2 x Posts*
1
Pergola
8 x Post cladding
panels
4 x Braces
4 x Rafters
