Olarm PRO Nemtek Installation Manual

The manual focuses on Nemtek
• Druid 13LCD, 15LCD, 18LDC, 25LCD & 28LCD
• Merlin M4i - Coming soon
• Merlin Stealth M18S & M28X - Coming
soon
STEP 1 - Locate your Nemtek electric fence
energizer
Druid 18LCD
Druid 13LCD & 15LCD
Coming soon
Merlin M4i Merlin Stealth M18S & M28X
STEP 2 - Unbox your Olarm PRO
The Olarm PRO box includes the following:
• 1x Olarm PRO device
• 1x Connector cable
• 1x Drill hole template and LED colour legend
• 2x Screws and wall plugs
STEP 3 - Download the Olarm mobile app &
register your device
Scan the QR code (left), or navigate to your App store
on your device and search for 'Olarm'. This Olarm PRO
will require an active subscription to function. Please
contact your installer or speak to
more information.
Nemtek Energizer Installation Guide
Druid 25LCD & 28LCD
sales@olarm.co for
+27 21 009 0911 | support@olarm.co | www.olarm.co
E & OE. Terms & conditions may apply.
Druid
Druid: You will be prompted to enter your Master PIN
and Reset PIN. These are by default 1234 and 5555
respectively. Please contact the Nemtek installer
should these not work.
Merlin: You will be prompted to enter your Master
PIN and User PIN. These are by default 1234 and 5555
respectively. Please contact the Nemtek installer
should these not work.
STEP 4 - Power down the electric fence
energizer
Disconnect both the mains and battery power from
the electric fence energizer before continuing.
STEP 5 - Connect your Olarm PRO device to
your electric fence energizer
Connect the 4-pin connector to the Universal port on
the Olarm PRO. Cut the 5-pin plug off the cable and
strip the wires so you can insert them. Wire the Olarm
PRO into the keybus according to the diagram below.
Nemtek panel labels
Olarm cable wire colour
Red
Black
Green
Note: The Druid only supports two keypads
& Olarm PRO counts as Keypad #2. You may
therefore need to forfeit a keypad if you already
have two connected.
www.olarm.co/start
Merlin 4 Merlin Stealth
+
-
D
Page 1
2022-02-14
