  • Page 1 TM63 LED TM68 TM69 TM69 LED Válvulas TM63 / TM63 LED / TM68 / TM69 / TM69 LED MANUAL DE USUARIO...

  • Page 2: Table Of Contents

    Presentation | Introduction | Recommendations....................Technical sheet | Fast programming........................ TM68 / TM69 / TM69 LED installation diagram....................Components of softening equipment....................... Maintenance..............................Water softener installation..........................Spare parts valve............................. TM68 / TM69 water softener start-up....................... TM69 LED water softener start-up........................Manual regeneration............................

  • Page 3: Presentation | Introduction | Recommendations

    PRESENTATION Congratulations for having purchased the water softener valve. Read and follow all steps and guides carefully before installing and using your water softener system. Before use, check the box and the valve to ensure that it has not suffered any damage during transport. Any claim for handling damage must be submitted, along with the name of the carrier (such must also be communicated to the carrier), within 24 hours maximum, after having received the goods.
  • Page 4 FEEDBACK: This cycle occurs when brine or regenerant passed through the resin bed, producing an exchange of calcium and magnesium ions by sodium. This process will be more or less efficient in function of the regeneration chosen. For our low-power equipment, the type of feedback is "upstream", so that fluid flow during the regeneration cycle is produced from the resins bajad and "the less saturated", towards the upper thereof, so that the period of exchange of calcium and magnesium ions for sodium ions, is carried out more efficiently and quic- kly.

  • Page 5: Technical Sheet | Fast Programming

    TECHNICAL SHEET - Control 4 regeneration cycles. - LED display technology, with 4 digits and pictograms computer. - Dual ceramic disk for service and regeneration. - Interlock Function: System Interconnect with Bottles MULTIPLEX installation in parallel. - Automatic valve top mount. - Types volumetric regeneration / clockwork CONTRACORRIENTE electronically controlled.

  • Page 6: Tm68/Tm69/Tm69 Led Installation Diagram

    TM68/TM69/TM69 LED INSTALLATION DIAGRAM Municipal water Water soft 6. BY-PASS 8. FLOW 7. PRESSURE GAUGES CONTROL VALVE 1. SEDIMENT 5. SEDIMENT FILTER (RECOMMENDED) FILTER (OPTIONAL) 9. TAKING 9. TAKING OF SAMPLES OF SAMPLES 10. ANTI RETURN 2. VALVE (inside the case) Drainage exit Overflow 3.

  • Page 7: Components Of Softening Equipment

    COMPONENTS OF THE SOFTENING EQUIPMENT Softening equipment is made up of the following elements (see installation scheme in fig. 1): 1. Sediment Filter (optional): This element containing a water filtering cartridge, which has the purpose of retaining particles larger than 20 microns in suspension. 2.

  • Page 8: Maintenance

    MAINTENANCE PRACTICAL TIPS: VERY IMPORTANT: Periodically check the clock water softening coincides with the official time of the country. Periodically check the level of salt in the tank. USE ONLY SALT IN PILLS, ESPECIALLY FOR DESCALERS (VACUUM). - Periodically clean or replace the sediment filter. - To change the sediment filter and the silico-phosphate filter, follow these steps: The sediment filter must be replaced when it becomes dark brown.

  • Page 9: Water Softener Installation

    WATER SOFTENER INSTALLATION Installation of this dishwasher is to be performed by authorized service and following the instructions that the country's legislation. Then follow the steps below for proper installation: 1. Check the water pressure of the network: it must be at least 2.5 bar and maximum 6 bar. Remember that water temperature must be between 5 °...
  • Page 10 9. Connect the valve to the transformer, and the transfor- mer to the power supply cord: 10. Turn the valve by-pass by-pass position: By-pass position 11. Connect the softener drain outlet to drain the network where you are performing the installation. Never install the Air space drain line directly into a grid, sewer or sump.

  • Page 11: Spare Parts Valve

    SPARE PARTS VALVE Main features: - Electronic programmer with graphic display, LED technology. - Retention of data in non-volatile memory. - Electromagnetic positioning assistance. - Automatic keypad lock. Technical data: - Inlet / outlet / drain connections: 1 "or ¾" (depending on model). - Bottle connection: 2 "- ½".

  • Page 12: Tm68 / Tm69 Water Softener Start-Up

    TM63 / TM68 / TM69 WATER SOFTENER START-UP Steps for correct programming: 1. Program indicator 7. Service 13. Block 2. Minutes indicator 8. Backwash 14. Programming mode 3. Seconds indicator 9. Aspiration brine 15. Menu / confirmation 4. Days / gallons 10.
  • Page 13 Button “MENU” Button “UP” Button “DOWN” Button “MENU” 3. Set the type of regeneration: Press the button DOWN to set the type of regeneration: · A-01 = Delayed downflow volumetric regeneration · A-02 = Regeneration instant volumetric downflow · A-03 = Delayed regeneration downflow volumetric intelligent (not to use) ·...
  • Page 14 Select the desired option using the UP and DOWN keys and press the "MENU" key to confirm. Button “MENU” Button “UP” Button “DOWN” Button “MENU” 5. Setting the regeneration time: This option is only editable if you have chosen a type of regeneration delayed in point 3 (A-01, A-03). Press the DOWN key again to display the regeneration time.
  • Page 15 Button “MENU” Button “UP” Button “DOWN” Button “MENU” Press "menu / confirmation" again to confirm the setting. Set the appropriate amount according to the amount (liters) of resin and the hardness of the water. Refer to the corresponding value in Table 1. Where: A: resine amount (liters) B: French degrees hardness (ºF)
  • Page 16 With the help of the UP and DOWN keys, indicate the duration of the back-up of your water softener (Table 2 shows the corresponding value for each model). Press "menu / confirmation" to confirm. 9. Second cycle regulation (aspiration of brine): Press the "DOWN"...
  • Page 17 Regeneration times according to liters of resin in the bottle First cycle: Second cycle: Third cycle: Fourth cycle: Liters of Injector according backwash aspiration of brine brine load Quick wash Bottle resin to bottle Ø Program 2 Program 3 Program 4 Program 5 3 min.
  • Page 18 13. External signal mode: Finally, pressing DOWN, the screen will show b-01 (external signal mode). This option has two choice: b-01: For connect an additional pump or electrovalve. Useful in installations with insufficient pressure or with external by-pass management (it requires additionals components). b-02: For connect an additional electrovalve to despresurize during the placement of the ceramics discs.

  • Page 19: Tm69 Led Water Softener Start-Up

    TM63 LED / TM69 LED WATER SOFTENER START-UP Pasos para una correcta programación: 1. Program indicator 7. Service 13. Block 2. Minutes indicator 8. Backwash 14. Programming mode 3. Seconds indicator 9. Aspiration brine 15. Menu / confirmation 4. Days / gallons 10.
  • Page 20 Button “MENU” Button “UP” Button “DOWN” Button “MENU” 3. Set the type of regeneration: Press the button DOWN to set the type of regeneration: · A-01 = Delayed downflow volumetric regeneration · A-02 = Regeneration instant volumetric downflow To change it press the UP key, and confirm with the "menu / confirmation" key: A-01 = delayed regeneration (regeneration will always be done at a preset time, once the volume of water is exhausted).
  • Page 21 5. Set the water volume to be treated: Press the button DOWN. The screen will show the program 1, wich corresponds to the backwash interval, that is, the number of regenerations in which the valve does not make a backwash. For up flow valves is not necessary to perform a backwash in each regeneration.
  • Page 22 HARDNESS Fº 10º 15º 20º 25º 30º 40º 50º 60º 70º 80º 90º 100º 3.150 2.100 1.575 1.260 1.050 Gal. 3,15 2,10 1,58 1,26 1,05 0,79 0,63 0,53 0,45 0,39 0,35 0,32 6.300 4.200 3.150 2.520 2.100 1.575 1.260 1.050 14 L Gal.
  • Page 23 With the help of the UP and DOWN keys, indicate the brine suction time of your water softener (table 2). Press "menu / confirmation" to confirm. 9. Regulation of the third cycle (brine load): Press the DOWN key for the third cycle setting. The indicator light will mark program 4, which corresponds to the brine charge time (in minutes).
  • Page 24 Regeneration times according to liters of resin in the bottle First cycle: Second cycle: Third cycle: Fourth cycle: Liters of Injector according backwash aspiration of brine brine load Quick wash Bottle resin to bottle Ø Programa 2 Programa 3 Programa 4 Programa 5 3 min.
  • Page 25 12. External signal mode: Finally, pressing DOWN, the screen will show b-01 (external signal mode). This option has two choice: b-01: For connect an additional pump or electrovalve. Useful in installations with insufficient pressure or with external by-pass management (it requires additionals components). b-02: For connect an additional electrovalve to despresurize during the placement of the ceramics discs.

  • Page 26: Manual Regeneration

    MANUAL REGENERATION To force a manual regeneration of the equipment, proceed as follows. 1. Unlock and access to programmation: To unlock and enter the manual mode and program changes, press the UP and DOWN buttons simulta- neously until the key icon desappears and appears the tool icon (setting mode). Button “UP”...

  • Page 27: Duplex Operation (Interconnection)

    DUPLEX OPERATION (INTERCONNECTION) To use the valve in INTERLOCK (DUPLEX system) only the two valves must be connected with the corres- ponding cable for this purpose. If the terminal of the BLOCK interlock cable on CN8 on the other valve is connected to one valve, the termi- nal BLACK will be connected to CN7.
  • Page 28 The following is a schematic diagram of a two-bottle installation in duplex mode: Municipal water Water soft 6. BY-PASS 8. FLOW 7. PRESSURE GAUGES CONTROL VALVE 1. SEDIMENT 5. SEDIMENT FILTER (RECOMMENDED) FILTER (OPTIONAL) 9. TAKING 9. TAKING OF SAMPLES OF SAMPLES 7.

  • Page 29: Operating Requirements

    OPERATING REQUIREMENTS 1. Typs: Regularly check the equipment’s clock matches the real time. In case of softening, it is recommended wash and sanitize the resine once a month by products specially designed for softener maintenance. Regularly check the softener performs a regeneration. Clean or replace the sediment filter (optional) perio- dically.

  • Page 30: Troubleshooting

    TROUBLESHOOTING...
  • Page 31 TROUBLESHOOTING PROBLEM ORIGIN SOLUTION 6. Chlorides in Inadequate regeneration. Increase the quick wash duration. outlet water Resin dirty. Sanitize tank. Contact with TS. (salty taste). 7. Iron in the Check regeneration cycles. Increase the quick Resin dirty. outgoing water. wash duration. Sanitize. Contact with TS. Excessive refill time.

  • Page 32: Warranty

    WARRANTY Customer name and address: Mr. / Mrs.: ..................................Address: ................................... ZIP code and Town: ................................Phone: ..............E-mail: ....................Deadler details: Compnay name: ................................Address: ................................... ZIP Code and Town: ................................Phone: ..........FAX: ..........E-mail: ............The warranty period is TWO YEARS from the date of purchase, valid in Spain and the countries of the EEC. The warranty covers manufacturing defects and assumes “resposability of the dealer and consumer rights”, in accordan- de with Article 4 of Law 23/2003 of July 10th of Guarantees of Consumption Goods Sale, and in addition it does not affect the consumer’s right in accordance with the law.

  • Page 33: Equipment Control And Monitoring

    EQUIPMENT CONTROL AND MONITORING PURPOSE OF THE NOTICE DATE TECHNICAL DATA Installation Name:........... Maintenance Signature or seal: Warranty Review Repair Installation Name:........... Maintenance Signature or seal: Warranty Review Repair Installation Name:........... Maintenance Signature or seal: Warranty Review Repair Installation Name:........... Maintenance Signature or seal: Warranty...
